Pump Selector - Calpeda Spa

Model GMVM 50/CE-60

Family GM 50

Code 70U20091002

Speed Fixed speed

Max Flow Rate 31,00 m³/h

H max 8,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,00 m³/h

Min head 1,00 m

kW 0,75 kW

Power consumption

Efficiency ---

Model GMVM 50/BE-60

Family GM 50

Code 70U20111002

Speed Fixed speed

Max Flow Rate 35,00 m³/h

H max 9,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,00 m³/h

Min head 1,00 m

kW 1,10 kW

Power consumption

Efficiency ---

Model GMC 50/CE-60

Family GM 50

Code 70T20100002

Speed Fixed speed

Max Flow Rate 36,00 m³/h

H max 10,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,00 m³/h

Min head 1,00 m

kW 0,75 kW

Power consumption

Efficiency ---

Model GMV 50/AE-60

Family GM 50

Code 70T20141005

Speed Fixed speed

Max Flow Rate 39,00 m³/h

H max 11,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,00 m³/h

Min head 1,00 m

kW 1,50 kW

Power consumption

Efficiency ---

Model GMCM 50/CE-60

Family GM 50

Code 70U20090003

Speed Fixed speed

Max Flow Rate 36,00 m³/h

H max 10,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,00 m³/h

Min head 1,00 m

kW 0,75 kW

Power consumption

Efficiency ---

Model GMC 50/BE-60

Family GM 50

Code 70T20120001

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 13,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,00 m³/h

Min head 1,00 m

kW 1,10 kW

Power consumption

Efficiency ---

Model GMC 50/AE-60

Family GM 50

Code 70T20140003

Speed Fixed speed

Max Flow Rate 48,00 m³/h

H max 16,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,00 m³/h

Min head 1,00 m

kW 1,50 kW

Power consumption

Efficiency ---

Model GMCM 50/BE-60

Family GM 50

Code 70U20110003

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 13,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,00 m³/h

Min head 1,00 m

kW 1,10 kW

Power consumption

Efficiency ---

Model GMVM 50/BE

Family GM 50

Code 70U20111000

Speed Fixed speed

Max Flow Rate 35,00 m³/h

H max 9,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,00 m³/h

Min head 1,00 m

kW 1,10 kW

Power consumption

Efficiency ---

Model GMCM 50/CE

Family GM 50

Code 70U20090000

Speed Fixed speed

Max Flow Rate 36,00 m³/h

H max 9,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,00 m³/h

Min head 1,00 m

kW 0,75 kW

Power consumption

Efficiency ---

Model GMV 50/AE

Family GM 50

Code 70T20141000

Speed Fixed speed

Max Flow Rate 39,00 m³/h

H max 11,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,00 m³/h

Min head 1,00 m

kW 1,50 kW

Power consumption

Efficiency ---

Model GMV 50/BE

Family GM 50

Code 70T20121000

Speed Fixed speed

Max Flow Rate 35,00 m³/h

H max 9,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,00 m³/h

Min head 1,00 m

kW 1,10 kW

Power consumption

Efficiency ---

Model GMV 50/CE

Family GM 50

Code 70T20101000

Speed Fixed speed

Max Flow Rate 31,00 m³/h

H max 8,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,00 m³/h

Min head 1,00 m

kW 0,75 kW

Power consumption

Efficiency ---

Model GMC 50/CE

Family GM 50

Code 70T20100000

Speed Fixed speed

Max Flow Rate 36,00 m³/h

H max 9,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,00 m³/h

Min head 1,00 m

kW 0,75 kW

Power consumption

Efficiency ---

Model GMCM 50/BE

Family GM 50

Code 70U20110000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 12,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,00 m³/h

Min head 1,00 m

kW 1,10 kW

Power consumption

Efficiency ---

Model GMC 50/BE

Family GM 50

Code 70T20120000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 12,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,00 m³/h

Min head 1,00 m

kW 1,10 kW

Power consumption

Efficiency ---

Model GMC 50/AE

Family GM 50

Code 70T20140000

Speed Fixed speed

Max Flow Rate 48,00 m³/h

H max 14,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,00 m³/h

Min head 1,00 m

kW 1,50 kW

Power consumption

Efficiency ---

Model GMVM 50/CE

Family GM 50

Code 70U20091000

Speed Fixed speed

Max Flow Rate 31,00 m³/h

H max 8,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,00 m³/h

Min head 1,00 m

kW 0,75 kW

Power consumption

Efficiency ---

Model GMV 50/CE-60

Family GM 50

Code 70T20101007

Speed Fixed speed

Max Flow Rate 31,00 m³/h

H max 8,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,00 m³/h

Min head 1,00 m

kW 0,75 kW

Power consumption

Efficiency ---

Model GMV 50/BE-60

Family GM 50

Code 70T20121006

Speed Fixed speed

Max Flow Rate 35,00 m³/h

H max 9,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,00 m³/h

Min head 1,00 m

kW 1,10 kW

Power consumption

Efficiency ---

Model GMV 50-65A-60

Family GM 50

Code 70T30251001

Speed Fixed speed

Max Flow Rate 39,00 m³/h

H max 11,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,00 m³/h

Min head 1,00 m

kW 1,50 kW

Power consumption

Efficiency ---

Model GMVM 50-65B-60

Family GM 50

Code 70U30221001

Speed Fixed speed

Max Flow Rate 35,00 m³/h

H max 9,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,00 m³/h

Min head 1,00 m

kW 1,10 kW

Power consumption

Efficiency ---

Model GMC 50-65B-60

Family GM 50

Code 70T30230002

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 12,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,00 m³/h

Min head 1,00 m

kW 1,10 kW

Power consumption

Efficiency ---

Model GMV 50-65B-60

Family GM 50

Code 70T30231001

Speed Fixed speed

Max Flow Rate 35,00 m³/h

H max 9,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,00 m³/h

Min head 1,00 m

kW 1,10 kW

Power consumption

Efficiency ---

Model GMC 50-65B

Family GM 50

Code 70T30230000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 12,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,00 m³/h

Min head 1,00 m

kW 1,10 kW

Power consumption

Efficiency ---

Model GMC 50-65A-60

Family GM 50

Code 70T30250001

Speed Fixed speed

Max Flow Rate 48,00 m³/h

H max 16,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,00 m³/h

Min head 1,00 m

kW 1,50 kW

Power consumption

Efficiency ---

Model GMVM 50-65C

Family GM 50

Code 70U30201000

Speed Fixed speed

Max Flow Rate 31,00 m³/h

H max 8,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,00 m³/h

Min head 1,00 m

kW 0,75 kW

Power consumption

Efficiency ---

Model GMV 50-65C

Family GM 50

Code 70T30211000

Speed Fixed speed

Max Flow Rate 31,00 m³/h

H max 8,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,00 m³/h

Min head 1,00 m

kW 0,75 kW

Power consumption

Efficiency ---

Model GMV 50-65B

Family GM 50

Code 70T30231000

Speed Fixed speed

Max Flow Rate 35,00 m³/h

H max 9,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,00 m³/h

Min head 1,00 m

kW 1,10 kW

Power consumption

Efficiency ---

Model GMC 50-65A

Family GM 50

Code 70T30250000

Speed Fixed speed

Max Flow Rate 48,00 m³/h

H max 14,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,00 m³/h

Min head 1,00 m

kW 1,50 kW

Power consumption

Efficiency ---

Model GMV 50-65A

Family GM 50

Code 70T30251000

Speed Fixed speed

Max Flow Rate 39,00 m³/h

H max 11,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,00 m³/h

Min head 1,00 m

kW 1,50 kW

Power consumption

Efficiency ---

Model GMVM 50-65B

Family GM 50

Code 70U30221000

Speed Fixed speed

Max Flow Rate 35,00 m³/h

H max 9,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,00 m³/h

Min head 1,00 m

kW 1,10 kW

Power consumption

Efficiency ---

Model GMC 50-65C

Family GM 50

Code 70T30210000

Speed Fixed speed

Max Flow Rate 36,00 m³/h

H max 9,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,00 m³/h

Min head 1,00 m

kW 0,75 kW

Power consumption

Efficiency ---

Model GMCM 50-65C

Family GM 50

Code 70U30200000

Speed Fixed speed

Max Flow Rate 36,00 m³/h

H max 9,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,00 m³/h

Min head 1,00 m

kW 0,75 kW

Power consumption

Efficiency ---

Model GMCM 50-65B

Family GM 50

Code 70U30220000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 12,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,00 m³/h

Min head 1,00 m

kW 1,10 kW

Power consumption

Efficiency ---

Model GMV 50-65C-60

Family GM 50

Code 70T30211001

Speed Fixed speed

Max Flow Rate 31,00 m³/h

H max 8,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,00 m³/h

Min head 1,00 m

kW 0,75 kW

Power consumption

Efficiency ---

Model GMCM 50-65C-60

Family GM 50

Code 70U30200004

Speed Fixed speed

Max Flow Rate 36,00 m³/h

H max 10,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,00 m³/h

Min head 1,00 m

kW 0,75 kW

Power consumption

Efficiency ---

Model GMVM 50-65C-60

Family GM 50

Code 70U30201004

Speed Fixed speed

Max Flow Rate 31,00 m³/h

H max 8,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,00 m³/h

Min head 1,00 m

kW 0,75 kW

Power consumption

Efficiency ---

Model GMCM 50-65B-60

Family GM 50

Code 70U30220003

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 13,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,00 m³/h

Min head 1,00 m

kW 1,10 kW

Power consumption

Efficiency ---

Model GMC 50-65C-60

Family GM 50

Code 70T30210003

Speed Fixed speed

Max Flow Rate 36,00 m³/h

H max 10,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,00 m³/h

Min head 1,00 m

kW 0,75 kW

Power consumption

Efficiency ---
