Pump Selector - Calpeda Spa

Model MXH 802-60/B

Family MXH

Code 6222020001000

Speed Fixed speed

Max Flow Rate 15,00 m³/h

H max 31,30 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 5,00 m³/h

Min head 15,00 m

kW 1,50 kW

Power consumption

Efficiency ---

Model MXH 804/B

Family MXH

Code 6222040000000

Speed Fixed speed

Max Flow Rate 13,00 m³/h

H max 42,50 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 5,00 m³/h

Min head 19,50 m

kW 1,50 kW

Power consumption

Efficiency ---

Model MXH 804-60/C

Family MXH

Code 6222040001000

Speed Fixed speed

Max Flow Rate 15,00 m³/h

H max 63,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 5,00 m³/h

Min head 31,00 m

kW 2,20 kW

Power consumption

Efficiency ---

Model MXH 805/C

Family MXH

Code 6222050000000

Speed Fixed speed

Max Flow Rate 13,00 m³/h

H max 54,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 5,00 m³/h

Min head 24,00 m

kW 1,80 kW

Power consumption

Efficiency ---

Model MXHM 801-60/B

Family MXH

Code 6232010001000

Speed Fixed speed

Max Flow Rate 15,00 m³/h

H max 15,60 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 5,00 m³/h

Min head 5,60 m

kW 0,55 kW

Power consumption

Efficiency ---

Model MXHM 802/B

Family MXH

Code 6232020000000

Speed Fixed speed

Max Flow Rate 13,00 m³/h

H max 20,50 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 5,00 m³/h

Min head 8,50 m

kW 0,75 kW

Power consumption

Efficiency ---

Model MXHM 802-60/A

Family MXH

Code 6232020001000

Speed Fixed speed

Max Flow Rate 15,00 m³/h

H max 31,30 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 5,00 m³/h

Min head 15,00 m

kW 1,50 kW

Power consumption

Efficiency ---

Model MXHM 803/A

Family MXH

Code 6232030000000

Speed Fixed speed

Max Flow Rate 13,00 m³/h

H max 32,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 5,00 m³/h

Min head 14,00 m

kW 1,10 kW

Power consumption

Efficiency ---

Model MXHM 804/A

Family MXH

Code 6232040000000

Speed Fixed speed

Max Flow Rate 13,00 m³/h

H max 42,50 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 5,00 m³/h

Min head 19,50 m

kW 1,50 kW

Power consumption

Efficiency ---

Model MXHM 805/B

Family MXH

Code 6232050000000

Speed Fixed speed

Max Flow Rate 13,00 m³/h

H max 54,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 5,00 m³/h

Min head 24,00 m

kW 1,80 kW

Power consumption

Efficiency ---

Model MXHL 801-60/B

Family MXH

Code 6322010001000

Speed Fixed speed

Max Flow Rate 15,00 m³/h

H max 15,60 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 5,00 m³/h

Min head 5,60 m

kW 0,55 kW

Power consumption

Efficiency ---

Model MXHL 802/C

Family MXH

Code 6322020000000

Speed Fixed speed

Max Flow Rate 13,00 m³/h

H max 20,50 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 5,00 m³/h

Min head 8,50 m

kW 0,75 kW

Power consumption

Efficiency ---

Model MXHL 802-60/B

Family MXH

Code 6322020001000

Speed Fixed speed

Max Flow Rate 15,00 m³/h

H max 31,30 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 5,00 m³/h

Min head 15,00 m

kW 1,50 kW

Power consumption

Efficiency ---

Model MXHLM 801-60/B

Family MXH

Code 6332010001000

Speed Fixed speed

Max Flow Rate 15,00 m³/h

H max 15,60 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 5,00 m³/h

Min head 5,60 m

kW 0,55 kW

Power consumption

Efficiency ---

Model MXHLM 802-60/A

Family MXH

Code 6332020001000

Speed Fixed speed

Max Flow Rate 15,00 m³/h

H max 31,30 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 5,00 m³/h

Min head 15,00 m

kW 1,50 kW

Power consumption

Efficiency ---

Model MXHLM 803/A

Family MXH

Code 6332030000000

Speed Fixed speed

Max Flow Rate 13,00 m³/h

H max 32,00 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 5,00 m³/h

Min head 14,00 m

kW 1,10 kW

Power consumption

Efficiency ---

Model MXHLM 804/A

Family MXH

Code 6332040000000

Speed Fixed speed

Max Flow Rate 13,00 m³/h

H max 42,50 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 5,00 m³/h

Min head 19,50 m

kW 1,50 kW

Power consumption

Efficiency ---

Model MXH 202-60/B

Family MXH

Code 6220020001000

Speed Fixed speed

Max Flow Rate 5,00 m³/h

H max 31,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 1,00 m³/h

Min head 16,00 m

kW 0,55 kW

Power consumption

Efficiency ---

Model MXH 203/A

Family MXH

Code 6220030000000

Speed Fixed speed

Max Flow Rate 4,80 m³/h

H max 31,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 1,00 m³/h

Min head 9,00 m

kW 0,37 kW

Power consumption

Efficiency ---

Model MXH 203-60/C

Family MXH

Code 6220030001000

Speed Fixed speed

Max Flow Rate 5,00 m³/h

H max 47,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 1,00 m³/h

Min head 24,00 m

kW 0,75 kW

Power consumption

Efficiency ---

Model MXH 204/B

Family MXH

Code 6220040000000

Speed Fixed speed

Max Flow Rate 4,80 m³/h

H max 42,50 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 1,00 m³/h

Min head 14,80 m

kW 0,55 kW

Power consumption

Efficiency ---

Model MXH 204-60/D

Family MXH

Code 6220040001000

Speed Fixed speed

Max Flow Rate 5,00 m³/h

H max 63,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 1,00 m³/h

Min head 33,00 m

kW 1,10 kW

Power consumption

Efficiency ---

Model MXH 205/C

Family MXH

Code 6220050000000

Speed Fixed speed

Max Flow Rate 4,80 m³/h

H max 53,50 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 1,00 m³/h

Min head 19,00 m

kW 0,75 kW

Power consumption

Efficiency ---

Model MXH 206/D

Family MXH

Code 6220060000000

Speed Fixed speed

Max Flow Rate 4,80 m³/h

H max 65,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 1,00 m³/h

Min head 25,00 m

kW 1,10 kW

Power consumption

Efficiency ---

Model MXH 209

Family MXH

Code 6220090000000

Speed Fixed speed

Max Flow Rate 4,80 m³/h

H max 97,10 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 1,00 m³/h

Min head 32,30 m

kW 1,50 kW

Power consumption

Efficiency ---

Model MXH 402-60/C

Family MXH

Code 6221020001000

Speed Fixed speed

Max Flow Rate 9,00 m³/h

H max 29,50 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 2,50 m³/h

Min head 12,50 m

kW 0,75 kW

Power consumption

Efficiency ---

Model MXH 403/B

Family MXH

Code 6221030000000

Speed Fixed speed

Max Flow Rate 8,00 m³/h

H max 30,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 2,25 m³/h

Min head 9,50 m

kW 0,55 kW

Power consumption

Efficiency ---

Model MXH 403-60/D

Family MXH

Code 6221030001000

Speed Fixed speed

Max Flow Rate 9,00 m³/h

H max 45,50 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 2,50 m³/h

Min head 20,00 m

kW 1,10 kW

Power consumption

Efficiency ---

Model MXH 404/C

Family MXH

Code 6221040000000

Speed Fixed speed

Max Flow Rate 8,00 m³/h

H max 40,50 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 2,25 m³/h

Min head 12,50 m

kW 0,75 kW

Power consumption

Efficiency ---

Model MXH 404-60/B

Family MXH

Code 6221040001000

Speed Fixed speed

Max Flow Rate 9,00 m³/h

H max 60,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 2,50 m³/h

Min head 26,00 m

kW 1,50 kW

Power consumption

Efficiency ---

Model MXH 405/D

Family MXH

Code 6221050000000

Speed Fixed speed

Max Flow Rate 8,00 m³/h

H max 52,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 2,25 m³/h

Min head 16,50 m

kW 1,10 kW

Power consumption

Efficiency ---

Model MXH 406/B

Family MXH

Code 6221060000000

Speed Fixed speed

Max Flow Rate 8,00 m³/h

H max 63,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 2,25 m³/h

Min head 23,00 m

kW 1,50 kW

Power consumption

Efficiency ---

Model MXH 407

Family MXH

Code 6221070000000

Speed Fixed speed

Max Flow Rate 8,00 m³/h

H max 73,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 2,25 m³/h

Min head 28,40 m

kW 1,50 kW

Power consumption

Efficiency ---

Model MXH 409

Family MXH

Code 6221090000000

Speed Fixed speed

Max Flow Rate 8,00 m³/h

H max 95,60 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 2,25 m³/h

Min head 36,50 m

kW 2,20 kW

Power consumption

Efficiency ---

Model MXH 807

Family MXH

Code 6222070000000

Speed Fixed speed

Max Flow Rate 13,00 m³/h

H max 75,40 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 5,00 m³/h

Min head 37,60 m

kW 3,00 kW

Power consumption

Efficiency ---

Model MXH 808

Family MXH

Code 6222080000000

Speed Fixed speed

Max Flow Rate 13,00 m³/h

H max 86,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 5,00 m³/h

Min head 43,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model MXHM 201-60/A

Family MXH

Code 6230010001000

Speed Fixed speed

Max Flow Rate 5,00 m³/h

H max 15,20 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 1,00 m³/h

Min head 7,00 m

kW 0,25 kW

Power consumption

Efficiency ---

Model MXHM 202/A

Family MXH

Code 6230020000000

Speed Fixed speed

Max Flow Rate 4,80 m³/h

H max 20,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 1,00 m³/h

Min head 5,50 m

kW 0,25 kW

Power consumption

Efficiency ---

Model MXHM 202-60/B

Family MXH

Code 6230020001000

Speed Fixed speed

Max Flow Rate 5,00 m³/h

H max 31,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 1,00 m³/h

Min head 16,00 m

kW 0,55 kW

Power consumption

Efficiency ---

Model MXHM 203/A

Family MXH

Code 6230030000000

Speed Fixed speed

Max Flow Rate 4,80 m³/h

H max 31,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 1,00 m³/h

Min head 9,00 m

kW 0,37 kW

Power consumption

Efficiency ---

Model MXHM 203-60/B

Family MXH

Code 6230030001000

Speed Fixed speed

Max Flow Rate 5,00 m³/h

H max 47,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 1,00 m³/h

Min head 24,00 m

kW 0,75 kW

Power consumption

Efficiency ---

Model MXHLM 204/B

Family MXH

Code 6330040000000

Speed Fixed speed

Max Flow Rate 4,80 m³/h

H max 42,50 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 1,00 m³/h

Min head 14,80 m

kW 0,55 kW

Power consumption

Efficiency ---

Model MXHM 204/B

Family MXH

Code 6230040000000

Speed Fixed speed

Max Flow Rate 4,80 m³/h

H max 42,50 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 1,00 m³/h

Min head 14,80 m

kW 0,55 kW

Power consumption

Efficiency ---

Model MXHLM 204-60/A

Family MXH

Code 6330040001000

Speed Fixed speed

Max Flow Rate 5,00 m³/h

H max 63,00 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 1,00 m³/h

Min head 33,00 m

kW 1,10 kW

Power consumption

Efficiency ---

Model MXHM 204-60/A

Family MXH

Code 6230040001000

Speed Fixed speed

Max Flow Rate 5,00 m³/h

H max 63,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 1,00 m³/h

Min head 33,00 m

kW 1,10 kW

Power consumption

Efficiency ---

Model MXHM 205/B

Family MXH

Code 6230050000000

Speed Fixed speed

Max Flow Rate 4,80 m³/h

H max 53,50 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 1,00 m³/h

Min head 19,00 m

kW 0,75 kW

Power consumption

Efficiency ---

Model MXHM 205-60/A

Family MXH

Code 6230050001000

Speed Fixed speed

Max Flow Rate 5,00 m³/h

H max 80,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 1,00 m³/h

Min head 40,40 m

kW 1,50 kW

Power consumption

Efficiency ---

Model MXHM 206/A

Family MXH

Code 6230060000000

Speed Fixed speed

Max Flow Rate 4,80 m³/h

H max 65,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 1,00 m³/h

Min head 25,00 m

kW 1,10 kW

Power consumption

Efficiency ---

Model MXHM 206-60

Family MXH

Code 6230060001000

Speed Fixed speed

Max Flow Rate 5,00 m³/h

H max 96,60 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 1,00 m³/h

Min head 50,10 m

kW 1,50 kW

Power consumption

Efficiency ---

Model MXHM 207

Family MXH

Code 6230070000000

Speed Fixed speed

Max Flow Rate 4,80 m³/h

H max 75,30 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 1,00 m³/h

Min head 24,70 m

kW 1,10 kW

Power consumption

Efficiency ---

Model MXHM 208

Family MXH

Code 6230080000000

Speed Fixed speed

Max Flow Rate 4,80 m³/h

H max 84,90 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 1,00 m³/h

Min head 27,20 m

kW 1,50 kW

Power consumption

Efficiency ---

Model MXHM 401-60/A

Family MXH

Code 6231010001000

Speed Fixed speed

Max Flow Rate 9,00 m³/h

H max 14,50 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 2,50 m³/h

Min head 4,00 m

kW 0,33 kW

Power consumption

Efficiency ---

Model MXHM 402/A

Family MXH

Code 6231020000000

Speed Fixed speed

Max Flow Rate 8,00 m³/h

H max 20,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 2,25 m³/h

Min head 6,00 m

kW 0,37 kW

Power consumption

Efficiency ---

Model MXHM 402-60/B

Family MXH

Code 6231020001000

Speed Fixed speed

Max Flow Rate 9,00 m³/h

H max 29,50 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 2,50 m³/h

Min head 12,50 m

kW 0,75 kW

Power consumption

Efficiency ---

Model MXHM 403/B

Family MXH

Code 6231030000000

Speed Fixed speed

Max Flow Rate 8,00 m³/h

H max 30,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 2,25 m³/h

Min head 9,50 m

kW 0,55 kW

Power consumption

Efficiency ---

Model MXHM 403-60/A

Family MXH

Code 6231030001000

Speed Fixed speed

Max Flow Rate 9,00 m³/h

H max 45,50 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 2,50 m³/h

Min head 20,00 m

kW 1,10 kW

Power consumption

Efficiency ---

Model MXHM 404/B

Family MXH

Code 6231040000000

Speed Fixed speed

Max Flow Rate 8,00 m³/h

H max 40,50 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 2,25 m³/h

Min head 12,50 m

kW 0,75 kW

Power consumption

Efficiency ---

Model MXHM 404-60/A

Family MXH

Code 6231040001000

Speed Fixed speed

Max Flow Rate 9,00 m³/h

H max 60,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 2,50 m³/h

Min head 26,00 m

kW 1,50 kW

Power consumption

Efficiency ---

Model MXHM 405/A

Family MXH

Code 6231050000000

Speed Fixed speed

Max Flow Rate 8,00 m³/h

H max 52,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 2,25 m³/h

Min head 16,50 m

kW 1,10 kW

Power consumption

Efficiency ---

Model MXHM 406/A

Family MXH

Code 6231060000000

Speed Fixed speed

Max Flow Rate 8,00 m³/h

H max 63,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 2,25 m³/h

Min head 23,00 m

kW 1,50 kW

Power consumption

Efficiency ---

Model MXHM 407

Family MXH

Code 6231070000000

Speed Fixed speed

Max Flow Rate 8,00 m³/h

H max 73,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 2,25 m³/h

Min head 28,40 m

kW 1,50 kW

Power consumption

Efficiency ---

Model MXHM 408

Family MXH

Code 6231080000000

Speed Fixed speed

Max Flow Rate 8,00 m³/h

H max 84,80 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 2,25 m³/h

Min head 32,70 m

kW 1,80 kW

Power consumption

Efficiency ---

Model MXHL 201-60/A

Family MXH

Code 6320010001000

Speed Fixed speed

Max Flow Rate 5,00 m³/h

H max 15,20 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 1,00 m³/h

Min head 7,00 m

kW 0,25 kW

Power consumption

Efficiency ---

Model MXHL 202/A

Family MXH

Code 6320020000000

Speed Fixed speed

Max Flow Rate 4,80 m³/h

H max 20,00 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 1,00 m³/h

Min head 5,50 m

kW 0,25 kW

Power consumption

Efficiency ---

Model MXHL 202-60/B

Family MXH

Code 6320020001000

Speed Fixed speed

Max Flow Rate 5,00 m³/h

H max 31,00 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 1,00 m³/h

Min head 16,00 m

kW 0,55 kW

Power consumption

Efficiency ---

Model MXHL 203/A

Family MXH

Code 6320030000000

Speed Fixed speed

Max Flow Rate 4,80 m³/h

H max 31,00 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 1,00 m³/h

Min head 9,00 m

kW 0,37 kW

Power consumption

Efficiency ---

Model MXHL 203-60/C

Family MXH

Code 6320030001000

Speed Fixed speed

Max Flow Rate 5,00 m³/h

H max 47,00 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 1,00 m³/h

Min head 24,00 m

kW 0,75 kW

Power consumption

Efficiency ---

Model MXHL 204/B

Family MXH

Code 6320040000000

Speed Fixed speed

Max Flow Rate 4,80 m³/h

H max 42,50 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 1,00 m³/h

Min head 14,80 m

kW 0,55 kW

Power consumption

Efficiency ---

Model MXHL 204-60/D

Family MXH

Code 6320040001000

Speed Fixed speed

Max Flow Rate 5,00 m³/h

H max 63,00 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 1,00 m³/h

Min head 33,00 m

kW 1,10 kW

Power consumption

Efficiency ---

Model MXHL 205/C

Family MXH

Code 6320050000000

Speed Fixed speed

Max Flow Rate 4,80 m³/h

H max 53,50 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 1,00 m³/h

Min head 19,00 m

kW 0,75 kW

Power consumption

Efficiency ---

Model MXHL 206/D

Family MXH

Code 6320060000000

Speed Fixed speed

Max Flow Rate 4,80 m³/h

H max 65,00 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 1,00 m³/h

Min head 25,00 m

kW 1,10 kW

Power consumption

Efficiency ---

Model MXHL 207

Family MXH

Code 6320070000000

Speed Fixed speed

Max Flow Rate 4,80 m³/h

H max 75,30 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 1,00 m³/h

Min head 24,70 m

kW 1,10 kW

Power consumption

Efficiency ---

Model MXHL 208

Family MXH

Code 6320080000000

Speed Fixed speed

Max Flow Rate 4,80 m³/h

H max 84,90 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 1,00 m³/h

Min head 27,20 m

kW 1,50 kW

Power consumption

Efficiency ---

Model MXHL 209

Family MXH

Code 6320090000000

Speed Fixed speed

Max Flow Rate 4,80 m³/h

H max 97,10 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 1,00 m³/h

Min head 32,30 m

kW 1,50 kW

Power consumption

Efficiency ---

Model MXHL 401-60/A

Family MXH

Code 6321010001000

Speed Fixed speed

Max Flow Rate 9,00 m³/h

H max 14,50 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 2,50 m³/h

Min head 4,00 m

kW 0,33 kW

Power consumption

Efficiency ---

Model MXHL 402/A

Family MXH

Code 6321020000000

Speed Fixed speed

Max Flow Rate 8,00 m³/h

H max 20,00 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 2,25 m³/h

Min head 6,00 m

kW 0,37 kW

Power consumption

Efficiency ---

Model MXHL 402-60/C

Family MXH

Code 6321020001000

Speed Fixed speed

Max Flow Rate 9,00 m³/h

H max 29,50 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 2,50 m³/h

Min head 12,50 m

kW 0,75 kW

Power consumption

Efficiency ---

Model MXHL 403/B

Family MXH

Code 6321030000000

Speed Fixed speed

Max Flow Rate 8,00 m³/h

H max 30,00 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 2,25 m³/h

Min head 9,50 m

kW 0,55 kW

Power consumption

Efficiency ---

Model MXHL 403-60/D

Family MXH

Code 6321030001000

Speed Fixed speed

Max Flow Rate 9,00 m³/h

H max 45,50 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 2,50 m³/h

Min head 20,00 m

kW 1,10 kW

Power consumption

Efficiency ---

Model MXHL 404/C

Family MXH

Code 6321040000000

Speed Fixed speed

Max Flow Rate 8,00 m³/h

H max 40,50 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 2,25 m³/h

Min head 12,50 m

kW 0,75 kW

Power consumption

Efficiency ---

Model MXHL 404-60/B

Family MXH

Code 6321040001000

Speed Fixed speed

Max Flow Rate 9,00 m³/h

H max 60,00 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 2,50 m³/h

Min head 26,00 m

kW 1,50 kW

Power consumption

Efficiency ---

Model MXHL 405/D

Family MXH

Code 6321050000000

Speed Fixed speed

Max Flow Rate 8,00 m³/h

H max 52,00 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 2,25 m³/h

Min head 16,50 m

kW 1,10 kW

Power consumption

Efficiency ---

Model MXHL 405-60

Family MXH

Code 6321050001000

Speed Fixed speed

Max Flow Rate 9,00 m³/h

H max 77,30 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 2,50 m³/h

Min head 38,20 m

kW 1,80 kW

Power consumption

Efficiency ---

Model MXHL 406/B

Family MXH

Code 6321060000000

Speed Fixed speed

Max Flow Rate 8,00 m³/h

H max 63,00 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 2,25 m³/h

Min head 23,00 m

kW 1,50 kW

Power consumption

Efficiency ---

Model MXHL 406-60

Family MXH

Code 6321060001000

Speed Fixed speed

Max Flow Rate 9,00 m³/h

H max 91,80 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 2,50 m³/h

Min head 43,40 m

kW 2,20 kW

Power consumption

Efficiency ---

Model MXHL 407

Family MXH

Code 6321070000000

Speed Fixed speed

Max Flow Rate 8,00 m³/h

H max 73,00 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 2,25 m³/h

Min head 28,40 m

kW 1,50 kW

Power consumption

Efficiency ---

Model MXHL 408

Family MXH

Code 6321080000000

Speed Fixed speed

Max Flow Rate 8,00 m³/h

H max 84,80 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 2,25 m³/h

Min head 32,70 m

kW 1,80 kW

Power consumption

Efficiency ---

Model MXHL 409

Family MXH

Code 6321090000000

Speed Fixed speed

Max Flow Rate 8,00 m³/h

H max 95,60 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 2,25 m³/h

Min head 36,50 m

kW 2,20 kW

Power consumption

Efficiency ---

Model MXHL 803-60/C

Family MXH

Code 6322030001000

Speed Fixed speed

Max Flow Rate 15,00 m³/h

H max 47,00 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 5,00 m³/h

Min head 22,50 m

kW 1,80 kW

Power consumption

Efficiency ---

Model MXHL 804/B

Family MXH

Code 6322040000000

Speed Fixed speed

Max Flow Rate 13,00 m³/h

H max 42,50 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 5,00 m³/h

Min head 19,50 m

kW 1,50 kW

Power consumption

Efficiency ---

Model MXHL 804-60/C

Family MXH

Code 6322040001000

Speed Fixed speed

Max Flow Rate 15,00 m³/h

H max 63,00 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 5,00 m³/h

Min head 31,00 m

kW 2,20 kW

Power consumption

Efficiency ---

Model MXHL 805-60

Family MXH

Code 6322050001000

Speed Fixed speed

Max Flow Rate 15,00 m³/h

H max 79,40 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 5,00 m³/h

Min head 41,70 m

kW 3,00 kW

Power consumption

Efficiency ---

Model MXHL 807

Family MXH

Code 6322070000000

Speed Fixed speed

Max Flow Rate 13,00 m³/h

H max 75,40 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 5,00 m³/h

Min head 37,60 m

kW 3,00 kW

Power consumption

Efficiency ---

Model MXHL 808

Family MXH

Code 6322080000000

Speed Fixed speed

Max Flow Rate 13,00 m³/h

H max 86,00 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 5,00 m³/h

Min head 43,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model MXHLM 201-60/A

Family MXH

Code 6330010001000

Speed Fixed speed

Max Flow Rate 5,00 m³/h

H max 15,20 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 1,00 m³/h

Min head 7,00 m

kW 0,25 kW

Power consumption

Efficiency ---

Model MXHLM 202/A

Family MXH

Code 6330020000000

Speed Fixed speed

Max Flow Rate 4,80 m³/h

H max 20,00 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 1,00 m³/h

Min head 5,50 m

kW 0,25 kW

Power consumption

Efficiency ---

Model MXHLM 202-60/B

Family MXH

Code 6330020001000

Speed Fixed speed

Max Flow Rate 5,00 m³/h

H max 31,00 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 1,00 m³/h

Min head 16,00 m

kW 0,55 kW

Power consumption

Efficiency ---

Model MXHLM 203/A

Family MXH

Code 6330030000000

Speed Fixed speed

Max Flow Rate 4,80 m³/h

H max 31,00 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 1,00 m³/h

Min head 9,00 m

kW 0,37 kW

Power consumption

Efficiency ---

Model MXHLM 203-60/B

Family MXH

Code 6330030001000

Speed Fixed speed

Max Flow Rate 5,00 m³/h

H max 47,00 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 1,00 m³/h

Min head 24,00 m

kW 0,75 kW

Power consumption

Efficiency ---

Model MXHLM 205/B

Family MXH

Code 6330050000000

Speed Fixed speed

Max Flow Rate 4,80 m³/h

H max 53,50 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 1,00 m³/h

Min head 19,00 m

kW 0,75 kW

Power consumption

Efficiency ---

Model MXHLM 205-60/A

Family MXH

Code 6330050001000

Speed Fixed speed

Max Flow Rate 5,00 m³/h

H max 80,00 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 1,00 m³/h

Min head 40,40 m

kW 1,50 kW

Power consumption

Efficiency ---

Model MXHLM 206/A

Family MXH

Code 6330060000000

Speed Fixed speed

Max Flow Rate 4,80 m³/h

H max 65,00 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 1,00 m³/h

Min head 25,00 m

kW 1,10 kW

Power consumption

Efficiency ---

Model MXHLM 206-60

Family MXH

Code 6330060001000

Speed Fixed speed

Max Flow Rate 5,00 m³/h

H max 96,60 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 1,00 m³/h

Min head 50,10 m

kW 1,50 kW

Power consumption

Efficiency ---

Model MXHLM 207

Family MXH

Code 6330070000000

Speed Fixed speed

Max Flow Rate 4,80 m³/h

H max 75,30 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 1,00 m³/h

Min head 24,70 m

kW 1,10 kW

Power consumption

Efficiency ---

Model MXHLM 208

Family MXH

Code 6330080000000

Speed Fixed speed

Max Flow Rate 4,80 m³/h

H max 84,90 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 1,00 m³/h

Min head 27,20 m

kW 1,50 kW

Power consumption

Efficiency ---

Model MXHLM 209

Family MXH

Code 6330090000000

Speed Fixed speed

Max Flow Rate 4,80 m³/h

H max 97,10 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 1,00 m³/h

Min head 32,30 m

kW 1,50 kW

Power consumption

Efficiency ---

Model MXHLM 401-60/A

Family MXH

Code 6331010001000

Speed Fixed speed

Max Flow Rate 9,00 m³/h

H max 14,50 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 2,50 m³/h

Min head 4,00 m

kW 0,33 kW

Power consumption

Efficiency ---

Model MXHLM 402/A

Family MXH

Code 6331020000000

Speed Fixed speed

Max Flow Rate 8,00 m³/h

H max 20,00 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 2,25 m³/h

Min head 6,00 m

kW 0,37 kW

Power consumption

Efficiency ---

Model MXHLM 402-60/B

Family MXH

Code 6331020001000

Speed Fixed speed

Max Flow Rate 9,00 m³/h

H max 29,50 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 2,50 m³/h

Min head 12,50 m

kW 0,75 kW

Power consumption

Efficiency ---

Model MXHLM 403/B

Family MXH

Code 6331030000000

Speed Fixed speed

Max Flow Rate 8,00 m³/h

H max 30,00 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 2,25 m³/h

Min head 9,50 m

kW 0,55 kW

Power consumption

Efficiency ---

Model MXHLM 403-60/A

Family MXH

Code 6331030001000

Speed Fixed speed

Max Flow Rate 9,00 m³/h

H max 45,50 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 2,50 m³/h

Min head 20,00 m

kW 1,10 kW

Power consumption

Efficiency ---

Model MXHLM 404/B

Family MXH

Code 6331040000000

Speed Fixed speed

Max Flow Rate 8,00 m³/h

H max 40,50 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 2,25 m³/h

Min head 12,50 m

kW 0,75 kW

Power consumption

Efficiency ---

Model MXHLM 404-60/A

Family MXH

Code 6331040001000

Speed Fixed speed

Max Flow Rate 9,00 m³/h

H max 60,00 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 2,50 m³/h

Min head 26,00 m

kW 1,50 kW

Power consumption

Efficiency ---

Model MXHLM 405/A

Family MXH

Code 6331050000000

Speed Fixed speed

Max Flow Rate 8,00 m³/h

H max 52,00 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 2,25 m³/h

Min head 16,50 m

kW 1,10 kW

Power consumption

Efficiency ---

Model MXHLM 406/A

Family MXH

Code 6331060000000

Speed Fixed speed

Max Flow Rate 8,00 m³/h

H max 63,00 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 2,25 m³/h

Min head 23,00 m

kW 1,50 kW

Power consumption

Efficiency ---

Model MXHLM 407

Family MXH

Code 6331070000000

Speed Fixed speed

Max Flow Rate 8,00 m³/h

H max 73,00 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 2,25 m³/h

Min head 28,40 m

kW 1,50 kW

Power consumption

Efficiency ---

Model MXHLM 408

Family MXH

Code 6331080000000

Speed Fixed speed

Max Flow Rate 8,00 m³/h

H max 84,80 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 2,25 m³/h

Min head 32,70 m

kW 1,80 kW

Power consumption

Efficiency ---

Model MXHLM 802/B

Family MXH

Code 6332020000000

Speed Fixed speed

Max Flow Rate 13,00 m³/h

H max 20,50 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 5,00 m³/h

Min head 8,50 m

kW 0,75 kW

Power consumption

Efficiency ---

Model MXHM 209

Family MXH

Code 6230090000000

Speed Fixed speed

Max Flow Rate 4,80 m³/h

H max 97,10 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 1,00 m³/h

Min head 32,30 m

kW 1,50 kW

Power consumption

Efficiency ---

Model MXH 202/A

Family MXH

Code 6220020000000

Speed Fixed speed

Max Flow Rate 4,80 m³/h

H max 20,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 1,00 m³/h

Min head 5,50 m

kW 0,25 kW

Power consumption

Efficiency ---

Model MXHL 205-60

Family MXH

Code 6320050001000

Speed Fixed speed

Max Flow Rate 5,00 m³/h

H max 80,00 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 1,00 m³/h

Min head 40,40 m

kW 1,50 kW

Power consumption

Efficiency ---

Model MXH 806

Family MXH

Code 6222060000000

Speed Fixed speed

Max Flow Rate 13,00 m³/h

H max 63,10 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 5,00 m³/h

Min head 28,10 m

kW 2,20 kW

Power consumption

Efficiency ---

Model MXHL 806

Family MXH

Code 6322060000000

Speed Fixed speed

Max Flow Rate 13,00 m³/h

H max 63,10 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 5,00 m³/h

Min head 28,10 m

kW 2,20 kW

Power consumption

Efficiency ---

Model MXHL 803/B

Family MXH

Code 6322030000000

Speed Fixed speed

Max Flow Rate 13,00 m³/h

H max 32,00 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 5,00 m³/h

Min head 14,00 m

kW 1,10 kW

Power consumption

Efficiency ---

Model MXH 405-60

Family MXH

Code 6221050001000

Speed Fixed speed

Max Flow Rate 9,00 m³/h

H max 77,30 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 2,50 m³/h

Min head 38,20 m

kW 1,80 kW

Power consumption

Efficiency ---

Model MXH 205-60

Family MXH

Code 6220050001000

Speed Fixed speed

Max Flow Rate 5,00 m³/h

H max 80,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 1,00 m³/h

Min head 40,04 m

kW 1,50 kW

Power consumption

Efficiency ---

Model MXH 402/A

Family MXH

Code 6221020000000

Speed Fixed speed

Max Flow Rate 8,00 m³/h

H max 20,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 2,25 m³/h

Min head 6,00 m

kW 0,37 kW

Power consumption

Efficiency ---

Model MXH 201-60/A

Family MXH

Code 6220010001000

Speed Fixed speed

Max Flow Rate 5,00 m³/h

H max 15,20 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 1,00 m³/h

Min head 7,00 m

kW 0,25 kW

Power consumption

Efficiency ---

Model MXH 401-60/A

Family MXH

Code 6221010001000

Speed Fixed speed

Max Flow Rate 9,00 m³/h

H max 14,50 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 2,50 m³/h

Min head 4,00 m

kW 0,33 kW

Power consumption

Efficiency ---

Model MXH 406-60

Family MXH

Code 6221060001000

Speed Fixed speed

Max Flow Rate 9,00 m³/h

H max 91,80 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 2,50 m³/h

Min head 43,40 m

kW 2,20 kW

Power consumption

Efficiency ---

Model MXH 208

Family MXH

Code 6220080000000

Speed Fixed speed

Max Flow Rate 4,80 m³/h

H max 84,90 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 1,00 m³/h

Min head 27,20 m

kW 1,50 kW

Power consumption

Efficiency ---

Model MXH 207

Family MXH

Code 6220070000000

Speed Fixed speed

Max Flow Rate 4,80 m³/h

H max 75,30 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 1,00 m³/h

Min head 24,70 m

kW 1,10 kW

Power consumption

Efficiency ---

Model MXH 801-60/B

Family MXH

Code 6222010001000

Speed Fixed speed

Max Flow Rate 15,00 m³/h

H max 15,60 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 5,00 m³/h

Min head 5,60 m

kW 0,55 kW

Power consumption

Efficiency ---

Model MXH 805-60

Family MXH

Code 6222050001000

Speed Fixed speed

Max Flow Rate 15,00 m³/h

H max 79,40 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 5,00 m³/h

Min head 41,70 m

kW 3,00 kW

Power consumption

Efficiency ---

Model MXH 408

Family MXH

Code 6221080000000

Speed Fixed speed

Max Flow Rate 8,00 m³/h

H max 84,80 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 2,25 m³/h

Min head 32,70 m

kW 1,80 kW

Power consumption

Efficiency ---

Model MXH 803-60/C

Family MXH

Code 6222030001000

Speed Fixed speed

Max Flow Rate 15,00 m³/h

H max 47,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 5,00 m³/h

Min head 22,50 m

kW 1,80 kW

Power consumption

Efficiency ---

Model MXHM 405-60

Family MXH

Code 6231050001000

Speed Fixed speed

Max Flow Rate 9,00 m³/h

H max 77,30 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 2,50 m³/h

Min head 38,20 m

kW 1,80 kW

Power consumption

Efficiency ---

Model MXHM 803-60/A

Family MXH

Code 6232030001000

Speed Fixed speed

Max Flow Rate 15,00 m³/h

H max 47,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 5,00 m³/h

Min head 22,50 m

kW 1,80 kW

Power consumption

Efficiency ---

Model MXHLM 405-60

Family MXH

Code 6331050001000

Speed Fixed speed

Max Flow Rate 9,00 m³/h

H max 77,30 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 2,50 m³/h

Min head 38,20 m

kW 1,80 kW

Power consumption

Efficiency ---

Model MXHLM 803-60/A

Family MXH

Code 6332030001000

Speed Fixed speed

Max Flow Rate 15,00 m³/h

H max 47,00 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 5,00 m³/h

Min head 22,50 m

kW 1,80 kW

Power consumption

Efficiency ---

Model MXH 2001-60

Family MXH

Code 6224010001000

Speed Fixed speed

Max Flow Rate 25,00 m³/h

H max 22,70 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 9,00 m³/h

Min head 12,40 m

kW 1,50 kW

Power consumption

Efficiency ---

Model MXH-F 2001-60

Family MXH

Code 6224010001002

Speed Fixed speed

Max Flow Rate 25,00 m³/h

H max 22,70 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 9,00 m³/h

Min head 12,40 m

kW 1,50 kW

Power consumption

Efficiency ---

Model MXH 2001/A

Family MXH

Code 6224010000000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 15,60 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 8,00 m³/h

Min head 5,20 m

kW 1,10 kW

Power consumption

Efficiency ---

Model MXH-F 2001/A

Family MXH

Code 6224010000002

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 15,60 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 8,00 m³/h

Min head 5,20 m

kW 1,10 kW

Power consumption

Efficiency ---

Model MXH 2002/A

Family MXH

Code 6224020000000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 31,40 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 8,00 m³/h

Min head 13,60 m

kW 1,80 kW

Power consumption

Efficiency ---

Model MXH-F 2002/A

Family MXH

Code 6224020000002

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 31,40 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 8,00 m³/h

Min head 13,60 m

kW 1,80 kW

Power consumption

Efficiency ---

Model MXH 2002-60

Family MXH

Code 6224020001000

Speed Fixed speed

Max Flow Rate 25,00 m³/h

H max 47,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 9,00 m³/h

Min head 29,60 m

kW 3,00 kW

Power consumption

Efficiency ---

Model MXH-F 2002-60

Family MXH

Code 6224020001002

Speed Fixed speed

Max Flow Rate 25,00 m³/h

H max 47,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 9,00 m³/h

Min head 29,60 m

kW 3,00 kW

Power consumption

Efficiency ---

Model MXH 2003

Family MXH

Code 6224030000000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 48,50 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 8,00 m³/h

Min head 22,30 m

kW 3,00 kW

Power consumption

Efficiency ---

Model MXH-F 2003

Family MXH

Code 6224030000002

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 48,50 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 8,00 m³/h

Min head 22,30 m

kW 3,00 kW

Power consumption

Efficiency ---

Model MXH 2003-60

Family MXH

Code 6224030001000

Speed Fixed speed

Max Flow Rate 25,00 m³/h

H max 71,50 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 9,00 m³/h

Min head 45,50 m

kW 5,50 kW

Power consumption

Efficiency ---

Model MXH-F 2003-60

Family MXH

Code 6224030001002

Speed Fixed speed

Max Flow Rate 25,00 m³/h

H max 71,50 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 9,00 m³/h

Min head 45,50 m

kW 5,50 kW

Power consumption

Efficiency ---

Model MXH 2004/A

Family MXH

Code 6224040000000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 64,50 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 8,00 m³/h

Min head 29,00 m

kW 4,00 kW

Power consumption

Efficiency ---

Model MXH-F 2004/A

Family MXH

Code 6224040000002

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 64,50 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 8,00 m³/h

Min head 29,00 m

kW 4,00 kW

Power consumption

Efficiency ---

Model MXH 2004-60

Family MXH

Code 6224040001000

Speed Fixed speed

Max Flow Rate 25,00 m³/h

H max 95,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 9,00 m³/h

Min head 62,00 m

kW 7,50 kW

Power consumption

Efficiency ---

Model MXH-F 2004-60

Family MXH

Code 6224040001002

Speed Fixed speed

Max Flow Rate 25,00 m³/h

H max 95,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 9,00 m³/h

Min head 62,00 m

kW 7,50 kW

Power consumption

Efficiency ---

Model MXH 2005

Family MXH

Code 6224050000000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 81,50 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 8,00 m³/h

Min head 36,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model MXH-F 2005

Family MXH

Code 6224050000002

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 81,50 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 8,00 m³/h

Min head 36,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model MXH 3201/B

Family MXH

Code 6225010000000

Speed Fixed speed

Max Flow Rate 44,00 m³/h

H max 16,30 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 15,00 m³/h

Min head 6,00 m

kW 2,20 kW

Power consumption

Efficiency ---

Model MXH-F 3201/B

Family MXH

Code 6225010000002

Speed Fixed speed

Max Flow Rate 44,00 m³/h

H max 16,30 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 15,00 m³/h

Min head 6,00 m

kW 2,20 kW

Power consumption

Efficiency ---

Model MXH 3201-60/B

Family MXH

Code 6225010001000

Speed Fixed speed

Max Flow Rate 52,00 m³/h

H max 24,50 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 18,00 m³/h

Min head 11,00 m

kW 4,00 kW

Power consumption

Efficiency ---

Model MXH-F 3201-60/B

Family MXH

Code 6225010001002

Speed Fixed speed

Max Flow Rate 52,00 m³/h

H max 24,50 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 18,00 m³/h

Min head 11,00 m

kW 4,00 kW

Power consumption

Efficiency ---

Model MXH 3202/B

Family MXH

Code 6225020000000

Speed Fixed speed

Max Flow Rate 50,00 m³/h

H max 33,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 15,00 m³/h

Min head 7,50 m

kW 4,00 kW

Power consumption

Efficiency ---

Model MXH-F 3202/B

Family MXH

Code 6225020000002

Speed Fixed speed

Max Flow Rate 50,00 m³/h

H max 33,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 15,00 m³/h

Min head 7,50 m

kW 4,00 kW

Power consumption

Efficiency ---

Model MXH 3202-60/A

Family MXH

Code 6225020001000

Speed Fixed speed

Max Flow Rate 52,00 m³/h

H max 49,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 18,00 m³/h

Min head 23,00 m

kW 7,50 kW

Power consumption

Efficiency ---

Model MXH-F 3202-60/A

Family MXH

Code 6225020001002

Speed Fixed speed

Max Flow Rate 52,00 m³/h

H max 49,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 18,00 m³/h

Min head 23,00 m

kW 7,50 kW

Power consumption

Efficiency ---

Model MXH 3203/A

Family MXH

Code 6225030000000

Speed Fixed speed

Max Flow Rate 50,00 m³/h

H max 50,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 15,00 m³/h

Min head 10,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model MXH-F 3203/A

Family MXH

Code 6225030000002

Speed Fixed speed

Max Flow Rate 50,00 m³/h

H max 50,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 15,00 m³/h

Min head 10,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model MXH 3203-60/B

Family MXH

Code 6225030001000

Speed Fixed speed

Max Flow Rate 52,00 m³/h

H max 73,50 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 18,00 m³/h

Min head 37,50 m

kW 11,00 kW

Power consumption

Efficiency ---

Model MXH-F 3203-60/B

Family MXH

Code 6225030001002

Speed Fixed speed

Max Flow Rate 52,00 m³/h

H max 73,50 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 18,00 m³/h

Min head 37,50 m

kW 11,00 kW

Power consumption

Efficiency ---

Model MXH 3204/A

Family MXH

Code 6225040000000

Speed Fixed speed

Max Flow Rate 50,00 m³/h

H max 67,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 15,00 m³/h

Min head 16,50 m

kW 7,50 kW

Power consumption

Efficiency ---

Model MXH-F 3204/A

Family MXH

Code 6225040000002

Speed Fixed speed

Max Flow Rate 50,00 m³/h

H max 67,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 15,00 m³/h

Min head 16,50 m

kW 7,50 kW

Power consumption

Efficiency ---

Model MXH-F 3204-60/A

Family MXH

Code 6225040001002

Speed Fixed speed

Max Flow Rate 52,00 m³/h

H max 98,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 18,00 m³/h

Min head 52,00 m

kW 15,00 kW

Power consumption

Efficiency ---

Model MXH 3204-60/A

Family MXH

Code 6225040001000

Speed Fixed speed

Max Flow Rate 52,00 m³/h

H max 98,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 18,00 m³/h

Min head 52,00 m

kW 15,00 kW

Power consumption

Efficiency ---

Model MXH 4801/A

Family MXH

Code 6226010000000

Speed Fixed speed

Max Flow Rate 60,00 m³/h

H max 18,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 21,00 m³/h

Min head 7,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model MXH-F 4801/A

Family MXH

Code 6226010000002

Speed Fixed speed

Max Flow Rate 60,00 m³/h

H max 18,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 21,00 m³/h

Min head 7,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model MXH 4801-60/B

Family MXH

Code 6226010001000

Speed Fixed speed

Max Flow Rate 70,00 m³/h

H max 25,50 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 27,00 m³/h

Min head 10,50 m

kW 4,00 kW

Power consumption

Efficiency ---

Model MXH-F 4801-60/B

Family MXH

Code 6226010001002

Speed Fixed speed

Max Flow Rate 70,00 m³/h

H max 25,50 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 27,00 m³/h

Min head 10,50 m

kW 4,00 kW

Power consumption

Efficiency ---

Model MXH 4802/A

Family MXH

Code 6226020000000

Speed Fixed speed

Max Flow Rate 66,00 m³/h

H max 35,30 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 21,00 m³/h

Min head 7,50 m

kW 5,50 kW

Power consumption

Efficiency ---

Model MXH-F 4802/A

Family MXH

Code 6226020000002

Speed Fixed speed

Max Flow Rate 66,00 m³/h

H max 35,30 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 21,00 m³/h

Min head 7,50 m

kW 5,50 kW

Power consumption

Efficiency ---

Model MXH 4802-60/B

Family MXH

Code 6226020001000

Speed Fixed speed

Max Flow Rate 70,00 m³/h

H max 51,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 27,00 m³/h

Min head 21,00 m

kW 9,20 kW

Power consumption

Efficiency ---

Model MXH-F 4802-60/B

Family MXH

Code 6226020001002

Speed Fixed speed

Max Flow Rate 70,00 m³/h

H max 51,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 27,00 m³/h

Min head 21,00 m

kW 9,20 kW

Power consumption

Efficiency ---

Model MXH 4803/A

Family MXH

Code 6226030000000

Speed Fixed speed

Max Flow Rate 66,00 m³/h

H max 53,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 21,00 m³/h

Min head 16,00 m

kW 7,50 kW

Power consumption

Efficiency ---

Model MXH-F 4803/A

Family MXH

Code 6226030000002

Speed Fixed speed

Max Flow Rate 66,00 m³/h

H max 53,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 21,00 m³/h

Min head 16,00 m

kW 7,50 kW

Power consumption

Efficiency ---

Model MXH 4803-60/A

Family MXH

Code 6226030001000

Speed Fixed speed

Max Flow Rate 70,00 m³/h

H max 76,50 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 27,00 m³/h

Min head 34,50 m

kW 15,00 kW

Power consumption

Efficiency ---

Model MXH-F 4803-60/A

Family MXH

Code 6226030001002

Speed Fixed speed

Max Flow Rate 70,00 m³/h

H max 76,50 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 27,00 m³/h

Min head 34,50 m

kW 15,00 kW

Power consumption

Efficiency ---

Model MXHL 805/C

Family MXH

Code 6322050000000

Speed Fixed speed

Max Flow Rate 13,00 m³/h

H max 54,00 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 5,00 m³/h

Min head 24,00 m

kW 1,80 kW

Power consumption

Efficiency ---

Model MXHLM 805/B

Family MXH

Code 6332050000000

Speed Fixed speed

Max Flow Rate 13,00 m³/h

H max 54,00 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 5,00 m³/h

Min head 24,00 m

kW 1,80 kW

Power consumption

Efficiency ---

Model MXH 1602/A

Family MXH

Code 6223020000000

Speed Fixed speed

Max Flow Rate 25,00 m³/h

H max 23,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 5,00 m³/h

Min head 6,50 m

kW 1,50 kW

Power consumption

Efficiency ---

Model MXH 1602-60/B

Family MXH

Code 6223020001000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 33,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 6,00 m³/h

Min head 15,80 m

kW 2,20 kW

Power consumption

Efficiency ---

Model MXH 1603/B

Family MXH

Code 6223030000000

Speed Fixed speed

Max Flow Rate 25,00 m³/h

H max 34,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 5,00 m³/h

Min head 8,80 m

kW 1,80 kW

Power consumption

Efficiency ---

Model MXH 1603-60/A

Family MXH

Code 6223030001000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 49,50 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 6,00 m³/h

Min head 23,70 m

kW 3,00 kW

Power consumption

Efficiency ---

Model MXH 1604/A

Family MXH

Code 6223040000000

Speed Fixed speed

Max Flow Rate 25,00 m³/h

H max 46,50 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 5,00 m³/h

Min head 14,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model MXH 1604-60/B

Family MXH

Code 6223040001000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 66,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 6,00 m³/h

Min head 31,50 m

kW 4,00 kW

Power consumption

Efficiency ---

Model MXH 1605/B

Family MXH

Code 6223050000000

Speed Fixed speed

Max Flow Rate 25,00 m³/h

H max 57,50 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 5,00 m³/h

Min head 19,00 m

kW 4,00 kW

Power consumption

Efficiency ---

Model MXH 1606/B

Family MXH

Code 6223060000000

Speed Fixed speed

Max Flow Rate 25,00 m³/h

H max 68,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 5,00 m³/h

Min head 22,00 m

kW 4,00 kW

Power consumption

Efficiency ---

Model MXH 803/B

Family MXH

Code 6222030000000

Speed Fixed speed

Max Flow Rate 13,00 m³/h

H max 32,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 5,00 m³/h

Min head 14,00 m

kW 1,10 kW

Power consumption

Efficiency ---

Model MXH 802/C

Family MXH

Code 6222020000000

Speed Fixed speed

Max Flow Rate 13,00 m³/h

H max 20,50 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 5,00 m³/h

Min head 8,50 m

kW 0,75 kW

Power consumption

Efficiency ---

Model MXH 206-60

Family MXH

Code 6220060001000

Speed Fixed speed

Max Flow Rate 5,00 m³/h

H max 96,60 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 1,00 m³/h

Min head 50,10 m

kW 1,50 kW

Power consumption

Efficiency ---

Model MXHL 206-60

Family MXH

Code 6320060001000

Speed Fixed speed

Max Flow Rate 5,00 m³/h

H max 96,60 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 1,00 m³/h

Min head 50,10 m

kW 1,50 kW

Power consumption

Efficiency ---

Model MXH-V 3201/B

Family MXH

Code 6225010000003

Speed Fixed speed

Max Flow Rate 44,00 m³/h

H max 16,30 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 15,00 m³/h

Min head 6,00 m

kW 2,20 kW

Power consumption

Efficiency ---

Model MXH-V 3201-60/B

Family MXH

Code 6225010001003

Speed Fixed speed

Max Flow Rate 52,00 m³/h

H max 24,50 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 18,00 m³/h

Min head 11,00 m

kW 4,00 kW

Power consumption

Efficiency ---

Model MXH-V 3202/B

Family MXH

Code 6225020000003

Speed Fixed speed

Max Flow Rate 50,00 m³/h

H max 33,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 15,00 m³/h

Min head 7,50 m

kW 4,00 kW

Power consumption

Efficiency ---

Model MXH-V 3202-60/A

Family MXH

Code 6225020001003

Speed Fixed speed

Max Flow Rate 52,00 m³/h

H max 49,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 18,00 m³/h

Min head 23,00 m

kW 7,50 kW

Power consumption

Efficiency ---

Model MXH-V 3203/A

Family MXH

Code 6225030000003

Speed Fixed speed

Max Flow Rate 50,00 m³/h

H max 50,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 15,00 m³/h

Min head 10,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model MXH-V 3203-60/B

Family MXH

Code 6225030001003

Speed Fixed speed

Max Flow Rate 52,00 m³/h

H max 73,50 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 18,00 m³/h

Min head 37,50 m

kW 11,00 kW

Power consumption

Efficiency ---

Model MXH-V 3204/A

Family MXH

Code 6225040000003

Speed Fixed speed

Max Flow Rate 50,00 m³/h

H max 67,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 15,00 m³/h

Min head 16,50 m

kW 7,50 kW

Power consumption

Efficiency ---

Model MXH-V 3204-60/A

Family MXH

Code 6225040001003

Speed Fixed speed

Max Flow Rate 52,00 m³/h

H max 98,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 18,00 m³/h

Min head 52,00 m

kW 15,00 kW

Power consumption

Efficiency ---

Model MXH-V 4801/A

Family MXH

Code 6226010000003

Speed Fixed speed

Max Flow Rate 60,00 m³/h

H max 18,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 21,00 m³/h

Min head 7,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model MXH-V 4801-60/B

Family MXH

Code 6226010001003

Speed Fixed speed

Max Flow Rate 70,00 m³/h

H max 25,50 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 27,00 m³/h

Min head 10,50 m

kW 4,00 kW

Power consumption

Efficiency ---

Model MXH-V 4802/A

Family MXH

Code 6226020000003

Speed Fixed speed

Max Flow Rate 66,00 m³/h

H max 35,30 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 21,00 m³/h

Min head 7,50 m

kW 5,50 kW

Power consumption

Efficiency ---

Model MXH-V 4802-60/B

Family MXH

Code 6226020001003

Speed Fixed speed

Max Flow Rate 70,00 m³/h

H max 51,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 27,00 m³/h

Min head 21,00 m

kW 9,20 kW

Power consumption

Efficiency ---

Model MXH-V 4803/A

Family MXH

Code 6226030000003

Speed Fixed speed

Max Flow Rate 66,00 m³/h

H max 53,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 21,00 m³/h

Min head 16,00 m

kW 7,50 kW

Power consumption

Efficiency ---

Model MXH-V 4803-60/A

Family MXH

Code 6226030001003

Speed Fixed speed

Max Flow Rate 70,00 m³/h

H max 76,50 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 27,00 m³/h

Min head 34,50 m

kW 15,00 kW

Power consumption

Efficiency ---

Model MXHM 204/B

Family MXH

Code 6230041000000

Speed Fixed speed

Max Flow Rate 4,80 m³/h

H max 42,50 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 1,00 m³/h

Min head 14,80 m

kW 0,55 kW

Power consumption

Efficiency ---

Model MXHM 205/B

Family MXH

Code 6230051000000

Speed Fixed speed

Max Flow Rate 4,80 m³/h

H max 53,50 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 1,00 m³/h

Min head 19,00 m

kW 0,75 kW

Power consumption

Efficiency ---

Model MXHM 206/A

Family MXH

Code 6230061000000

Speed Fixed speed

Max Flow Rate 4,80 m³/h

H max 65,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 1,00 m³/h

Min head 25,00 m

kW 1,10 kW

Power consumption

Efficiency ---

Model MXHM 403/B

Family MXH

Code 6231031000000

Speed Fixed speed

Max Flow Rate 8,00 m³/h

H max 30,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 2,25 m³/h

Min head 9,50 m

kW 0,55 kW

Power consumption

Efficiency ---

Model MXHM 404/B

Family MXH

Code 6231041000000

Speed Fixed speed

Max Flow Rate 8,00 m³/h

H max 40,50 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 2,25 m³/h

Min head 12,50 m

kW 0,75 kW

Power consumption

Efficiency ---

Model MXHM 405/A

Family MXH

Code 6231051000000

Speed Fixed speed

Max Flow Rate 8,00 m³/h

H max 52,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 2,25 m³/h

Min head 16,50 m

kW 1,10 kW

Power consumption

Efficiency ---

Model MXHM 802/B

Family MXH

Code 6232021000000

Speed Fixed speed

Max Flow Rate 13,00 m³/h

H max 20,50 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 5,00 m³/h

Min head 8,50 m

kW 0,75 kW

Power consumption

Efficiency ---

Model MXHM 803/A

Family MXH

Code 6232031000000

Speed Fixed speed

Max Flow Rate 13,00 m³/h

H max 32,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 5,00 m³/h

Min head 14,00 m

kW 1,10 kW

Power consumption

Efficiency ---

Model MXHM 1602

Family MXH

Code 6233020000000

Speed Fixed speed

Max Flow Rate 25,00 m³/h

H max 23,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 5,00 m³/h

Min head 6,50 m

kW 1,50 kW

Power consumption

Efficiency ---

Model MXHM 1603

Family MXH

Code 6233030000000

Speed Fixed speed

Max Flow Rate 25,00 m³/h

H max 34,00 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 5,00 m³/h

Min head 8,80 m

kW 1,80 kW

Power consumption

Efficiency ---

Model MXHLM 204/B

Family MXH

Code 6330041000000

Speed Fixed speed

Max Flow Rate 4,80 m³/h

H max 42,50 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 1,00 m³/h

Min head 14,80 m

kW 0,55 kW

Power consumption

Efficiency ---

Model MXHLM 205/B

Family MXH

Code 6330051000000

Speed Fixed speed

Max Flow Rate 4,80 m³/h

H max 53,50 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 1,00 m³/h

Min head 19,00 m

kW 0,75 kW

Power consumption

Efficiency ---

Model MXHLM 206/A

Family MXH

Code 6330061000000

Speed Fixed speed

Max Flow Rate 4,80 m³/h

H max 65,00 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 1,00 m³/h

Min head 25,00 m

kW 1,10 kW

Power consumption

Efficiency ---

Model MXHLM 403/B

Family MXH

Code 6331031000000

Speed Fixed speed

Max Flow Rate 8,00 m³/h

H max 30,00 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 2,25 m³/h

Min head 9,50 m

kW 0,55 kW

Power consumption

Efficiency ---

Model MXHLM 404/B

Family MXH

Code 6331041000000

Speed Fixed speed

Max Flow Rate 8,00 m³/h

H max 40,50 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 2,25 m³/h

Min head 12,50 m

kW 0,75 kW

Power consumption

Efficiency ---

Model MXHLM 405/A

Family MXH

Code 6331051000000

Speed Fixed speed

Max Flow Rate 8,00 m³/h

H max 52,00 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 2,25 m³/h

Min head 16,50 m

kW 1,10 kW

Power consumption

Efficiency ---

Model MXHLM 802/B

Family MXH

Code 6332021000000

Speed Fixed speed

Max Flow Rate 13,00 m³/h

H max 20,50 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 5,00 m³/h

Min head 8,50 m

kW 0,75 kW

Power consumption

Efficiency ---

Model MXHLM 803/A

Family MXH

Code 6332031000000

Speed Fixed speed

Max Flow Rate 13,00 m³/h

H max 32,00 m

Pump casing Cr-Ni-Mo steel 1.4404 EN 10088 (AISI 316L)

Min Flow Rate 5,00 m³/h

Min head 14,00 m

kW 1,10 kW

Power consumption

Efficiency ---

Model MXH 1601-60

Family MXH

Code 6223010001000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 16,50 m

Pump casing Cr-Ni steel 1.4301 EN 10088 (AISI 304)

Min Flow Rate 6,00 m³/h

Min head 7,20 m

kW 1,50 kW

Power consumption

Efficiency ---

Filters for

Results MXH

Filters for

Filters for
