Pump Selector - Calpeda Spa

Model N 100-200C/A

Family N

Code 5000236000000

Speed Fixed speed

Max Flow Rate 300,00 m³/h

H max 45,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 108,00 m³/h

Min head 22,00 m

kW 30,00 kW

Power consumption

Efficiency ---

Model N4 125-315A/A

Family N

Code 5000282000000

Speed Fixed speed

Max Flow Rate 330,00 m³/h

H max 36,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 84,00 m³/h

Min head 21,60 m

kW 30,00 kW

Power consumption

Efficiency ---

Model N4 80-315A/B

Family N

Code 5000224100000

Speed Fixed speed

Max Flow Rate 150,00 m³/h

H max 36,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 25,30 m

kW 15,00 kW

Power consumption

Efficiency ---

Model N 65-250B/B

Family N

Code 5000164100000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 73,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 59,00 m

kW 30,00 kW

Power consumption

Efficiency ---

Model N4 150-400A/B

Family N

Code 5000302100000

Speed Fixed speed

Max Flow Rate 660,00 m³/h

H max 52,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 132,00 m³/h

Min head 32,20 m

kW 75,00 kW

Power consumption

Efficiency ---

Model N 40-250A/A

Family N

Code 5000078000000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 90,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 70,50 m

kW 15,00 kW

Power consumption

Efficiency ---

Model N 80-250A/A

Family N

Code 5000216000000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 95,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 75,00 m³/h

Min head 76,50 m

kW 55,00 kW

Power consumption

Efficiency ---

Model N4 100-200B/A

Family N

Code 5000242000000

Speed Fixed speed

Max Flow Rate 168,00 m³/h

H max 12,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 4,50 m

kW 4,00 kW

Power consumption

Efficiency ---

Model N4 50-160A/A

Family N

Code 5000100000000

Speed Fixed speed

Max Flow Rate 48,00 m³/h

H max 9,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 3,10 m

kW 1,10 kW

Power consumption

Efficiency ---

Model N 40-200B/A

Family N

Code 5000060000000

Speed Fixed speed

Max Flow Rate 33,00 m³/h

H max 50,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 37,50 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N 65-250C/B

Family N

Code 5000162100000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 61,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 43,00 m

kW 22,00 kW

Power consumption

Efficiency ---

Model N 40-250B/A

Family N

Code 5000074000000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 69,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 45,00 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N 32-200A/A

Family N

Code 5000030000000

Speed Fixed speed

Max Flow Rate 15,00 m³/h

H max 57,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 51,00 m

kW 4,00 kW

Power consumption

Efficiency ---

Model N 32L-160B

Family N

Code 5000305000000

Speed Fixed speed

Max Flow Rate 29,00 m³/h

H max 30,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 9,60 m³/h

Min head 17,90 m

kW 3,00 kW

Power consumption

Efficiency ---

Model N 32L-160A

Family N

Code 5000307000000

Speed Fixed speed

Max Flow Rate 32,00 m³/h

H max 39,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 9,60 m³/h

Min head 25,60 m

kW 4,00 kW

Power consumption

Efficiency ---

Model N 40-125A/A

Family N

Code 5000042000000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 22,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 11,50 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N 65-125A/B

Family N

Code 5000132100000

Speed Fixed speed

Max Flow Rate 120,00 m³/h

H max 25,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 37,80 m³/h

Min head 17,60 m

kW 7,50 kW

Power consumption

Efficiency ---

Model N 40-125F/A

Family N

Code 5000034000000

Speed Fixed speed

Max Flow Rate 33,00 m³/h

H max 14,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 6,00 m

kW 1,10 kW

Power consumption

Efficiency ---

Model N 40-125F-60/A

Family N

Code 5000034001000

Speed Fixed speed

Max Flow Rate 33,00 m³/h

H max 15,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 5,60 m

kW 1,10 kW

Power consumption

Efficiency ---

Model N 40-125C/A

Family N

Code 5000038000000

Speed Fixed speed

Max Flow Rate 39,00 m³/h

H max 17,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 6,50 m

kW 1,50 kW

Power consumption

Efficiency ---

Model N 40-125C-60/A

Family N

Code 5000038001000

Speed Fixed speed

Max Flow Rate 37,80 m³/h

H max 18,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 6,90 m

kW 1,50 kW

Power consumption

Efficiency ---

Model N 40-125A-60/A

Family N

Code 5000042001000

Speed Fixed speed

Max Flow Rate 39,00 m³/h

H max 22,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 12,90 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N 40-160C/A

Family N

Code 5000046000000

Speed Fixed speed

Max Flow Rate 39,00 m³/h

H max 23,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 10,00 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N 40-250B-60/A

Family N

Code 5000074001000

Speed Fixed speed

Max Flow Rate 37,80 m³/h

H max 71,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 50,00 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N4 40-250B/A

Family N

Code 5000076000000

Speed Fixed speed

Max Flow Rate 30,00 m³/h

H max 21,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 5,40 m³/h

Min head 5,00 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N4 40-250B-60/A

Family N

Code 5000076001000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 22,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 5,40 m³/h

Min head 10,10 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N 40-250A-60/A

Family N

Code 5000078001000

Speed Fixed speed

Max Flow Rate 39,00 m³/h

H max 90,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 76,00 m

kW 15,00 kW

Power consumption

Efficiency ---

Model N4 40-250A/A

Family N

Code 5000080000000

Speed Fixed speed

Max Flow Rate 30,00 m³/h

H max 22,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 5,40 m³/h

Min head 8,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model N4 40-250A-60/A

Family N

Code 5000080001000

Speed Fixed speed

Max Flow Rate 30,00 m³/h

H max 25,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 5,40 m³/h

Min head 10,70 m

kW 3,00 kW

Power consumption

Efficiency ---

Model N 50-125F/A

Family N

Code 5000082000000

Speed Fixed speed

Max Flow Rate 66,00 m³/h

H max 15,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 6,00 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N 50-125F-60/A

Family N

Code 5000082001000

Speed Fixed speed

Max Flow Rate 60,00 m³/h

H max 16,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 5,80 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N4 50-125F/A

Family N

Code 5000084000000

Speed Fixed speed

Max Flow Rate 33,00 m³/h

H max 4,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 0,50 m

kW 0,37 kW

Power consumption

Efficiency ---

Model N 50-125D/A

Family N

Code 5000086000000

Speed Fixed speed

Max Flow Rate 72,00 m³/h

H max 20,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 8,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model N 50-125D-60/A

Family N

Code 5000086001000

Speed Fixed speed

Max Flow Rate 66,00 m³/h

H max 19,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 8,40 m

kW 3,00 kW

Power consumption

Efficiency ---

Model N4 50-125D/A

Family N

Code 5000088000000

Speed Fixed speed

Max Flow Rate 33,00 m³/h

H max 5,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 2,50 m

kW 0,55 kW

Power consumption

Efficiency ---

Model N 50-125A-60/A

Family N

Code 5000090001000

Speed Fixed speed

Max Flow Rate 48,00 m³/h

H max 24,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 22,30 m

kW 4,00 kW

Power consumption

Efficiency ---

Model N 50-125A-60-S/A

Family N

Code 5000090003000

Speed Fixed speed

Max Flow Rate 75,00 m³/h

H max 24,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 13,60 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N4 50-125A/A

Family N

Code 5000092000000

Speed Fixed speed

Max Flow Rate 37,80 m³/h

H max 6,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 2,90 m

kW 0,75 kW

Power consumption

Efficiency ---

Model N 50-160B/A

Family N

Code 5000094000000

Speed Fixed speed

Max Flow Rate 81,00 m³/h

H max 31,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 9,50 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N 50-160B-60/A

Family N

Code 5000094001000

Speed Fixed speed

Max Flow Rate 37,80 m³/h

H max 35,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 33,60 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N 50-160B-60-S/A

Family N

Code 5000094003000

Speed Fixed speed

Max Flow Rate 75,00 m³/h

H max 35,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 15,10 m

kW 7,50 kW

Power consumption

Efficiency ---

Model N4 50-160B/A

Family N

Code 5000096000000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 8,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 3,30 m

kW 1,10 kW

Power consumption

Efficiency ---

Model N4 50-160B-60/A

Family N

Code 5000096001000

Speed Fixed speed

Max Flow Rate 37,80 m³/h

H max 9,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 3,80 m

kW 1,10 kW

Power consumption

Efficiency ---

Model N 50-160A/A

Family N

Code 5000098000000

Speed Fixed speed

Max Flow Rate 81,00 m³/h

H max 38,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 19,00 m

kW 7,50 kW

Power consumption

Efficiency ---

Model N 50-160A-60/A

Family N

Code 5000098001000

Speed Fixed speed

Max Flow Rate 84,00 m³/h

H max 41,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 20,40 m

kW 7,50 kW

Power consumption

Efficiency ---

Model N4 50-200C/A

Family N

Code 5000102000000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 11,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 4,70 m

kW 1,10 kW

Power consumption

Efficiency ---

Model N4 50-200C-60/A

Family N

Code 5000102001000

Speed Fixed speed

Max Flow Rate 37,80 m³/h

H max 11,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 2,70 m

kW 1,10 kW

Power consumption

Efficiency ---

Model N 50-200B-60/A

Family N

Code 5000104001000

Speed Fixed speed

Max Flow Rate 69,00 m³/h

H max 51,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 24,00 m³/h

Min head 27,30 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N4 50-200B/A

Family N

Code 5000106000000

Speed Fixed speed

Max Flow Rate 48,00 m³/h

H max 13,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 3,70 m

kW 1,50 kW

Power consumption

Efficiency ---

Model N4 50-200B-60/A

Family N

Code 5000106001000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 12,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 3,40 m

kW 1,50 kW

Power consumption

Efficiency ---

Model N 50-200A-60/A

Family N

Code 5000108001000

Speed Fixed speed

Max Flow Rate 75,00 m³/h

H max 57,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 24,00 m³/h

Min head 33,20 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N4 50-200A/A

Family N

Code 5000110000000

Speed Fixed speed

Max Flow Rate 48,00 m³/h

H max 14,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 6,00 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N4 50-200A-60/A

Family N

Code 5000110001000

Speed Fixed speed

Max Flow Rate 54,00 m³/h

H max 16,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 5,40 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N 50-250C/A

Family N

Code 5000112000000

Speed Fixed speed

Max Flow Rate 69,00 m³/h

H max 55,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 24,00 m³/h

Min head 24,50 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N 50-250C-60/A

Family N

Code 5000112001000

Speed Fixed speed

Max Flow Rate 60,00 m³/h

H max 61,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 24,00 m³/h

Min head 36,50 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N4 50-250C/A

Family N

Code 5000114000000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 17,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 6,80 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N4 50-250C-60/A

Family N

Code 5000114001000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 18,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 7,20 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N4 50-250D

Family N

Code 5000114010000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 14,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 2,30 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N 50-250B-60/A

Family N

Code 5000116001000

Speed Fixed speed

Max Flow Rate 66,00 m³/h

H max 74,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 24,00 m³/h

Min head 43,80 m

kW 15,00 kW

Power consumption

Efficiency ---

Model N4 50-250B/A

Family N

Code 5000118000000

Speed Fixed speed

Max Flow Rate 48,00 m³/h

H max 20,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 5,80 m

kW 3,00 kW

Power consumption

Efficiency ---

Model N4 50-250B-60/A

Family N

Code 5000118001000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 23,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 12,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model N 50-250A/A

Family N

Code 5000120000000

Speed Fixed speed

Max Flow Rate 69,00 m³/h

H max 80,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 24,00 m³/h

Min head 58,50 m

kW 18,50 kW

Power consumption

Efficiency ---

Model N 50-250A-60/A

Family N

Code 5000120001000

Speed Fixed speed

Max Flow Rate 66,00 m³/h

H max 87,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 24,00 m³/h

Min head 66,90 m

kW 18,50 kW

Power consumption

Efficiency ---

Model N4 50-250A/A

Family N

Code 5000122000000

Speed Fixed speed

Max Flow Rate 48,00 m³/h

H max 22,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 9,00 m

kW 4,00 kW

Power consumption

Efficiency ---

Model N4 50-250A-60/A

Family N

Code 5000122001000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 24,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 14,00 m

kW 4,00 kW

Power consumption

Efficiency ---

Model N 65-125E/B

Family N

Code 5000124100000

Speed Fixed speed

Max Flow Rate 108,00 m³/h

H max 16,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 37,80 m³/h

Min head 9,20 m

kW 4,00 kW

Power consumption

Efficiency ---

Model N 65-125E-60/B

Family N

Code 5000124101000

Speed Fixed speed

Max Flow Rate 108,00 m³/h

H max 16,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 37,80 m³/h

Min head 9,90 m

kW 4,00 kW

Power consumption

Efficiency ---

Model N4 65-125E/B

Family N

Code 5000126100000

Speed Fixed speed

Max Flow Rate 54,00 m³/h

H max 4,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 2,30 m

kW 0,75 kW

Power consumption

Efficiency ---

Model N4 65-125E-60/B

Family N

Code 5000126101000

Speed Fixed speed

Max Flow Rate 54,00 m³/h

H max 4,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 2,50 m

kW 0,75 kW

Power consumption

Efficiency ---

Model N 65-125C/B

Family N

Code 5000128100000

Speed Fixed speed

Max Flow Rate 120,00 m³/h

H max 21,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 37,80 m³/h

Min head 11,80 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N 65-125C-60/B

Family N

Code 5000128101000

Speed Fixed speed

Max Flow Rate 120,00 m³/h

H max 21,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 37,80 m³/h

Min head 13,10 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N4 65-125C/B

Family N

Code 5000130100000

Speed Fixed speed

Max Flow Rate 60,00 m³/h

H max 5,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 3,00 m

kW 0,75 kW

Power consumption

Efficiency ---

Model N4 65-125C-60/B

Family N

Code 5000130101000

Speed Fixed speed

Max Flow Rate 60,00 m³/h

H max 5,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 3,30 m

kW 0,75 kW

Power consumption

Efficiency ---

Model N 65-125A-60/B

Family N

Code 5000132101000

Speed Fixed speed

Max Flow Rate 120,00 m³/h

H max 26,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 37,80 m³/h

Min head 18,90 m

kW 7,50 kW

Power consumption

Efficiency ---

Model N4 65-125A/B

Family N

Code 5000134100000

Speed Fixed speed

Max Flow Rate 60,00 m³/h

H max 6,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 4,40 m

kW 1,10 kW

Power consumption

Efficiency ---

Model N4 65-125A-60/B

Family N

Code 5000134101000

Speed Fixed speed

Max Flow Rate 60,00 m³/h

H max 6,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 4,70 m

kW 1,10 kW

Power consumption

Efficiency ---

Model N 65-160D/B

Family N

Code 5000138100000

Speed Fixed speed

Max Flow Rate 120,00 m³/h

H max 24,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 16,30 m

kW 7,50 kW

Power consumption

Efficiency ---

Model N 65-160D-60/B

Family N

Code 5000138101000

Speed Fixed speed

Max Flow Rate 120,00 m³/h

H max 24,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 17,60 m

kW 7,50 kW

Power consumption

Efficiency ---

Model N 65-160C/B

Family N

Code 5000140100000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 28,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 17,70 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N 65-160C-60/B

Family N

Code 5000140101000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 27,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 19,00 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N4 80-160C-60/B

Family N

Code 5000184101000

Speed Fixed speed

Max Flow Rate 84,00 m³/h

H max 6,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 3,70 m

kW 1,10 kW

Power consumption

Efficiency ---

Model N 80-160B/B

Family N

Code 5000186100000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 34,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 75,00 m³/h

Min head 22,40 m

kW 15,00 kW

Power consumption

Efficiency ---

Model N 80-160B-60/B

Family N

Code 5000186101000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 35,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 75,00 m³/h

Min head 21,00 m

kW 15,00 kW

Power consumption

Efficiency ---

Model N4 80-160B/B

Family N

Code 5000188100000

Speed Fixed speed

Max Flow Rate 96,00 m³/h

H max 7,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 4,10 m

kW 1,50 kW

Power consumption

Efficiency ---

Model N4 80-160B-60/B

Family N

Code 5000188101000

Speed Fixed speed

Max Flow Rate 96,00 m³/h

H max 8,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 4,50 m

kW 1,50 kW

Power consumption

Efficiency ---

Model N 80-160A/B

Family N

Code 5000190100000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 39,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 75,00 m³/h

Min head 28,10 m

kW 18,50 kW

Power consumption

Efficiency ---

Model N 80-160A-60/B

Family N

Code 5000190101000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 41,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 75,00 m³/h

Min head 28,80 m

kW 18,50 kW

Power consumption

Efficiency ---

Model N4 80-160A/B

Family N

Code 5000192100000

Speed Fixed speed

Max Flow Rate 108,00 m³/h

H max 10,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 5,90 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N4 80-160A-60/B

Family N

Code 5000192101000

Speed Fixed speed

Max Flow Rate 108,00 m³/h

H max 11,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 6,60 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N4 80-200C/B

Family N

Code 5000194100000

Speed Fixed speed

Max Flow Rate 120,00 m³/h

H max 9,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 2,70 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N4 80-200C-60/B

Family N

Code 5000194101000

Speed Fixed speed

Max Flow Rate 108,00 m³/h

H max 9,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 4,50 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N 80-200B/B

Family N

Code 5000196100000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 44,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 75,00 m³/h

Min head 32,40 m

kW 22,00 kW

Power consumption

Efficiency ---

Model N 80-200B-60/B

Family N

Code 5000196101000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 43,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 75,00 m³/h

Min head 32,20 m

kW 22,00 kW

Power consumption

Efficiency ---

Model N4 80-200B/B

Family N

Code 5000198100000

Speed Fixed speed

Max Flow Rate 120,00 m³/h

H max 11,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 4,10 m

kW 3,00 kW

Power consumption

Efficiency ---

Model N4 80-200B-60/B

Family N

Code 5000198101000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 12,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 4,50 m

kW 3,00 kW

Power consumption

Efficiency ---

Model N 80-200A-60/B

Family N

Code 5000200101000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 58,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 75,00 m³/h

Min head 47,80 m

kW 30,00 kW

Power consumption

Efficiency ---

Model N4 80-200A/B

Family N

Code 5000202100000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 14,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 6,90 m

kW 4,00 kW

Power consumption

Efficiency ---

Model N4 80-200A-60/B

Family N

Code 5000202101000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 14,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 7,70 m

kW 4,00 kW

Power consumption

Efficiency ---

Model N 80-250E/A

Family N

Code 5000204000000

Speed Fixed speed

Max Flow Rate 180,00 m³/h

H max 51,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 75,00 m³/h

Min head 29,00 m

kW 22,00 kW

Power consumption

Efficiency ---

Model N 80-250E-60/A

Family N

Code 5000204001000

Speed Fixed speed

Max Flow Rate 180,00 m³/h

H max 51,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 75,00 m³/h

Min head 29,00 m

kW 22,00 kW

Power consumption

Efficiency ---

Model N 80-250D-60/A

Family N

Code 5000206001000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 65,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 75,00 m³/h

Min head 41,00 m

kW 30,00 kW

Power consumption

Efficiency ---

Model N 80-250C/A

Family N

Code 5000208000000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 73,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 75,00 m³/h

Min head 51,50 m

kW 37,00 kW

Power consumption

Efficiency ---

Model N 100-200E/A

Family N

Code 5000232000000

Speed Fixed speed

Max Flow Rate 240,00 m³/h

H max 30,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 108,00 m³/h

Min head 19,00 m

kW 18,50 kW

Power consumption

Efficiency ---

Model N 100-200E-60/A

Family N

Code 5000232001000

Speed Fixed speed

Max Flow Rate 240,00 m³/h

H max 30,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 108,00 m³/h

Min head 19,00 m

kW 18,50 kW

Power consumption

Efficiency ---

Model N 100-200D/A

Family N

Code 5000234000000

Speed Fixed speed

Max Flow Rate 270,00 m³/h

H max 36,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 108,00 m³/h

Min head 19,00 m

kW 22,00 kW

Power consumption

Efficiency ---

Model N 100-200D-60/A

Family N

Code 5000234001000

Speed Fixed speed

Max Flow Rate 240,00 m³/h

H max 36,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 108,00 m³/h

Min head 24,00 m

kW 22,00 kW

Power consumption

Efficiency ---

Model N 100-200C-60/A

Family N

Code 5000236001000

Speed Fixed speed

Max Flow Rate 270,00 m³/h

H max 45,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 108,00 m³/h

Min head 28,00 m

kW 30,00 kW

Power consumption

Efficiency ---

Model N4 100-200C-60/A

Family N

Code 5000238001000

Speed Fixed speed

Max Flow Rate 150,00 m³/h

H max 9,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 4,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model N4 125-250C/A

Family N

Code 5000272000000

Speed Fixed speed

Max Flow Rate 300,00 m³/h

H max 16,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 84,00 m³/h

Min head 5,80 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N4 125-250C-60/A

Family N

Code 5000272001000

Speed Fixed speed

Max Flow Rate 300,00 m³/h

H max 16,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 84,00 m³/h

Min head 5,40 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N4 125-250B-60/A

Family N

Code 5000274001000

Speed Fixed speed

Max Flow Rate 300,00 m³/h

H max 19,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 84,00 m³/h

Min head 8,00 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N4 125-250A/A

Family N

Code 5000276000000

Speed Fixed speed

Max Flow Rate 330,00 m³/h

H max 22,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 84,00 m³/h

Min head 9,30 m

kW 15,00 kW

Power consumption

Efficiency ---

Model N4 125-250A-60/A

Family N

Code 5000276001000

Speed Fixed speed

Max Flow Rate 330,00 m³/h

H max 23,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 84,00 m³/h

Min head 9,00 m

kW 15,00 kW

Power consumption

Efficiency ---

Model N4 125-315C/A

Family N

Code 5000278000000

Speed Fixed speed

Max Flow Rate 330,00 m³/h

H max 27,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 84,00 m³/h

Min head 9,50 m

kW 18,50 kW

Power consumption

Efficiency ---

Model N4 125-315C-60/A

Family N

Code 5000278001000

Speed Fixed speed

Max Flow Rate 300,00 m³/h

H max 28,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 84,00 m³/h

Min head 13,00 m

kW 18,50 kW

Power consumption

Efficiency ---

Model N4 125-315B/A

Family N

Code 5000280000000

Speed Fixed speed

Max Flow Rate 330,00 m³/h

H max 31,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 84,00 m³/h

Min head 14,30 m

kW 22,00 kW

Power consumption

Efficiency ---

Model N4 125-315B-60/A

Family N

Code 5000280001000

Speed Fixed speed

Max Flow Rate 330,00 m³/h

H max 32,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 84,00 m³/h

Min head 14,50 m

kW 22,00 kW

Power consumption

Efficiency ---

Model N4 125-315A-60/A

Family N

Code 5000282001000

Speed Fixed speed

Max Flow Rate 330,00 m³/h

H max 37,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 84,00 m³/h

Min head 21,50 m

kW 30,00 kW

Power consumption

Efficiency ---

Model N4 125-400C/A

Family N

Code 5000284000000

Speed Fixed speed

Max Flow Rate 330,00 m³/h

H max 45,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 84,00 m³/h

Min head 23,50 m

kW 37,00 kW

Power consumption

Efficiency ---

Model N4 125-400C-60/A

Family N

Code 5000284001000

Speed Fixed speed

Max Flow Rate 300,00 m³/h

H max 45,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 84,00 m³/h

Min head 28,00 m

kW 37,00 kW

Power consumption

Efficiency ---

Model N4 125-400B/A

Family N

Code 5000286000000

Speed Fixed speed

Max Flow Rate 330,00 m³/h

H max 51,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 84,00 m³/h

Min head 31,50 m

kW 45,00 kW

Power consumption

Efficiency ---

Model N4 125-400B-60/A

Family N

Code 5000286001000

Speed Fixed speed

Max Flow Rate 330,00 m³/h

H max 51,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 84,00 m³/h

Min head 31,00 m

kW 45,00 kW

Power consumption

Efficiency ---

Model N4 125-400A/A

Family N

Code 5000288000000

Speed Fixed speed

Max Flow Rate 330,00 m³/h

H max 59,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 84,00 m³/h

Min head 42,50 m

kW 55,00 kW

Power consumption

Efficiency ---

Model N4 125-400A-60/A

Family N

Code 5000288001000

Speed Fixed speed

Max Flow Rate 330,00 m³/h

H max 59,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 84,00 m³/h

Min head 41,50 m

kW 55,00 kW

Power consumption

Efficiency ---

Model N 32L-160A-60

Family N

Code 5000307001000

Speed Fixed speed

Max Flow Rate 32,00 m³/h

H max 38,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 9,60 m³/h

Min head 23,90 m

kW 4,00 kW

Power consumption

Efficiency ---

Model N 32L-200C-60

Family N

Code 5000309001000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 46,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 9,60 m³/h

Min head 25,60 m

kW 4,00 kW

Power consumption

Efficiency ---

Model N 32L-200B

Family N

Code 5000310000000

Speed Fixed speed

Max Flow Rate 29,00 m³/h

H max 51,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 9,60 m³/h

Min head 33,50 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N4 200-400A

Family N

Code 5000318000000

Speed Fixed speed

Max Flow Rate 900,00 m³/h

H max 58,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 180,00 m³/h

Min head 38,80 m

kW 132,00 kW

Power consumption

Efficiency ---

Model N 32L-160C

Family N

Code 5000303000000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 25,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 9,60 m³/h

Min head 13,40 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N4 100-315A/A

Family N

Code 5000260000000

Speed Fixed speed

Max Flow Rate 210,00 m³/h

H max 36,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 22,20 m

kW 18,50 kW

Power consumption

Efficiency ---

Model N4 80-400C/B

Family N

Code 5000226100000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 42,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 29,10 m

kW 18,50 kW

Power consumption

Efficiency ---

Model N4 80-400C-60/B

Family N

Code 5000226101000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 47,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 31,30 m

kW 18,50 kW

Power consumption

Efficiency ---

Model N4 80-400B/B

Family N

Code 5000228100000

Speed Fixed speed

Max Flow Rate 150,00 m³/h

H max 48,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 30,50 m

kW 22,00 kW

Power consumption

Efficiency ---

Model N4 80-400B-60/B

Family N

Code 5000228101000

Speed Fixed speed

Max Flow Rate 150,00 m³/h

H max 52,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 31,00 m

kW 22,00 kW

Power consumption

Efficiency ---

Model N4 80-400A/B

Family N

Code 5000230100000

Speed Fixed speed

Max Flow Rate 150,00 m³/h

H max 61,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 49,50 m

kW 30,00 kW

Power consumption

Efficiency ---

Model N4 80-400A-60/B

Family N

Code 5000230101000

Speed Fixed speed

Max Flow Rate 150,00 m³/h

H max 64,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 48,10 m

kW 30,00 kW

Power consumption

Efficiency ---

Model N 40-160C-60/A

Family N

Code 5000046001000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 25,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 22,10 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N 40-160C-60-S/A

Family N

Code 5000046003000

Speed Fixed speed

Max Flow Rate 37,80 m³/h

H max 25,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 10,60 m

kW 3,00 kW

Power consumption

Efficiency ---

Model N4 40-160C/A

Family N

Code 5000048000000

Speed Fixed speed

Max Flow Rate 21,00 m³/h

H max 6,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 5,40 m³/h

Min head 2,30 m

kW 0,37 kW

Power consumption

Efficiency ---

Model N4 40-160C-60/A

Family N

Code 5000048001000

Speed Fixed speed

Max Flow Rate 18,90 m³/h

H max 6,75 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 5,40 m³/h

Min head 3,20 m

kW 0,37 kW

Power consumption

Efficiency ---

Model N 40-160B/A

Family N

Code 5000050000000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 29,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 14,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model N4 40-160B/A

Family N

Code 5000052000000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 7,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 5,40 m³/h

Min head 2,70 m

kW 0,55 kW

Power consumption

Efficiency ---

Model N4 40-160B-60/A

Family N

Code 5000052001000

Speed Fixed speed

Max Flow Rate 21,00 m³/h

H max 8,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 5,40 m³/h

Min head 4,60 m

kW 0,55 kW

Power consumption

Efficiency ---

Model N 40-160A/A

Family N

Code 5000054000000

Speed Fixed speed

Max Flow Rate 37,80 m³/h

H max 37,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 27,00 m

kW 4,00 kW

Power consumption

Efficiency ---

Model N 40-160A-60/A

Family N

Code 5000054001000

Speed Fixed speed

Max Flow Rate 33,00 m³/h

H max 37,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 31,80 m

kW 4,00 kW

Power consumption

Efficiency ---

Model N 40-160A-S/A

Family N

Code 5000054002000

Speed Fixed speed

Max Flow Rate 48,00 m³/h

H max 37,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 17,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N 40-160A-60-S/A

Family N

Code 5000054003000

Speed Fixed speed

Max Flow Rate 45,00 m³/h

H max 37,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 23,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N4 40-160A/A

Family N

Code 5000056000000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 9,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 5,40 m³/h

Min head 3,50 m

kW 0,75 kW

Power consumption

Efficiency ---

Model N4 40-160A-60/A

Family N

Code 5000056001000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 9,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 5,40 m³/h

Min head 5,80 m

kW 0,75 kW

Power consumption

Efficiency ---

Model N 40-200C/A

Family N

Code 5000058000000

Speed Fixed speed

Max Flow Rate 21,00 m³/h

H max 41,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 38,00 m

kW 4,00 kW

Power consumption

Efficiency ---

Model N 40-200C-60/A

Family N

Code 5000058001000

Speed Fixed speed

Max Flow Rate 21,00 m³/h

H max 44,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 41,00 m

kW 4,00 kW

Power consumption

Efficiency ---

Model N 40-200C-S/A

Family N

Code 5000058002000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 41,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 33,50 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N 40-200C-60-S/A

Family N

Code 5000058003000

Speed Fixed speed

Max Flow Rate 21,00 m³/h

H max 44,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 36,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N 40-200D/A

Family N

Code 5000058010000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 39,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 30,50 m

kW 4,00 kW

Power consumption

Efficiency ---

Model N 40-200D-S/A

Family N

Code 5000058012000

Speed Fixed speed

Max Flow Rate 37,80 m³/h

H max 39,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 14,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N 40-200B-60/A

Family N

Code 5000060001000

Speed Fixed speed

Max Flow Rate 33,00 m³/h

H max 52,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 35,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N 40-200B-S/A

Family N

Code 5000060002000

Speed Fixed speed

Max Flow Rate 37,80 m³/h

H max 50,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 30,50 m

kW 7,50 kW

Power consumption

Efficiency ---

Model N4 40-200B/A

Family N

Code 5000062000000

Speed Fixed speed

Max Flow Rate 21,00 m³/h

H max 13,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 5,40 m³/h

Min head 7,00 m

kW 1,10 kW

Power consumption

Efficiency ---

Model N4 40-200B-60/A

Family N

Code 5000062001000

Speed Fixed speed

Max Flow Rate 18,90 m³/h

H max 13,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 5,40 m³/h

Min head 7,80 m

kW 1,10 kW

Power consumption

Efficiency ---

Model N 40-200AR/A

Family N

Code 5000064000000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 55,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 51,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N 40-200AR-60/A

Family N

Code 5000064001000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 56,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 52,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N 40-200AR-S/A

Family N

Code 5000064002000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 55,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 49,00 m

kW 7,50 kW

Power consumption

Efficiency ---

Model N 40-200AR-60-S/A

Family N

Code 5000064003000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 56,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 49,00 m

kW 7,50 kW

Power consumption

Efficiency ---

Model N 40-200A/A

Family N

Code 5000066000000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 57,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 35,00 m

kW 7,50 kW

Power consumption

Efficiency ---

Model N 40-200A-60/A

Family N

Code 5000066001000

Speed Fixed speed

Max Flow Rate 37,80 m³/h

H max 59,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 38,50 m

kW 7,50 kW

Power consumption

Efficiency ---

Model N4 40-200A/A

Family N

Code 5000068000000

Speed Fixed speed

Max Flow Rate 21,00 m³/h

H max 14,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 5,40 m³/h

Min head 10,00 m

kW 1,10 kW

Power consumption

Efficiency ---

Model N4 40-200A-60/A

Family N

Code 5000068001000

Speed Fixed speed

Max Flow Rate 21,00 m³/h

H max 15,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 5,40 m³/h

Min head 9,30 m

kW 1,10 kW

Power consumption

Efficiency ---

Model N 40-250C/A

Family N

Code 5000070000000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 61,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 33,50 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N 40-250C-60/A

Family N

Code 5000070001000

Speed Fixed speed

Max Flow Rate 33,00 m³/h

H max 65,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 49,00 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N4 40-250C/A

Family N

Code 5000072000000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 17,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 5,40 m³/h

Min head 2,80 m

kW 1,50 kW

Power consumption

Efficiency ---

Model N4 40-250C-60/A

Family N

Code 5000072001000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 18,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 5,40 m³/h

Min head 4,40 m

kW 1,50 kW

Power consumption

Efficiency ---

Model N4 65-160C/B

Family N

Code 5000142100000

Speed Fixed speed

Max Flow Rate 60,00 m³/h

H max 6,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 4,20 m

kW 1,10 kW

Power consumption

Efficiency ---

Model N4 65-160C-60/B

Family N

Code 5000142101000

Speed Fixed speed

Max Flow Rate 60,00 m³/h

H max 6,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 4,30 m

kW 1,10 kW

Power consumption

Efficiency ---

Model N 65-160B/B

Family N

Code 5000144100000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 32,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 23,00 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N 65-160B-60/B

Family N

Code 5000144101000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 32,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 24,40 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N4 65-160B/B

Family N

Code 5000146100000

Speed Fixed speed

Max Flow Rate 66,00 m³/h

H max 7,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 4,50 m

kW 1,10 kW

Power consumption

Efficiency ---

Model N4 65-160B-60/B

Family N

Code 5000146101000

Speed Fixed speed

Max Flow Rate 66,00 m³/h

H max 7,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 4,60 m

kW 1,10 kW

Power consumption

Efficiency ---

Model N 65-160A/B

Family N

Code 5000148100000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 40,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 31,70 m

kW 15,00 kW

Power consumption

Efficiency ---

Model N 65-160A-60/B

Family N

Code 5000148101000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 40,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 33,20 m

kW 15,00 kW

Power consumption

Efficiency ---

Model N4 65-160A/B

Family N

Code 5000150100000

Speed Fixed speed

Max Flow Rate 75,00 m³/h

H max 8,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 5,20 m

kW 1,50 kW

Power consumption

Efficiency ---

Model N4 65-160A-60/B

Family N

Code 5000150101000

Speed Fixed speed

Max Flow Rate 75,00 m³/h

H max 8,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 5,70 m

kW 1,50 kW

Power consumption

Efficiency ---

Model N 65-200C/B

Family N

Code 5000152100000

Speed Fixed speed

Max Flow Rate 141,00 m³/h

H max 44,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 28,80 m

kW 15,00 kW

Power consumption

Efficiency ---

Model N 65-200C-60/B

Family N

Code 5000152101000

Speed Fixed speed

Max Flow Rate 141,00 m³/h

H max 45,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 30,40 m

kW 15,00 kW

Power consumption

Efficiency ---

Model N 65-200B/B

Family N

Code 5000154100000

Speed Fixed speed

Max Flow Rate 141,00 m³/h

H max 50,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 37,50 m

kW 18,50 kW

Power consumption

Efficiency ---

Model N 65-200B-60/B

Family N

Code 5000154101000

Speed Fixed speed

Max Flow Rate 141,00 m³/h

H max 52,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 38,70 m

kW 18,50 kW

Power consumption

Efficiency ---

Model N4 65-200B/B

Family N

Code 5000156100000

Speed Fixed speed

Max Flow Rate 96,00 m³/h

H max 11,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 3,30 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N4 65-200B-60/B

Family N

Code 5000156101000

Speed Fixed speed

Max Flow Rate 96,00 m³/h

H max 12,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 3,20 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N 65-200A/B

Family N

Code 5000158100000

Speed Fixed speed

Max Flow Rate 141,00 m³/h

H max 57,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 45,50 m

kW 22,00 kW

Power consumption

Efficiency ---

Model N 65-200A-60/B

Family N

Code 5000158101000

Speed Fixed speed

Max Flow Rate 141,00 m³/h

H max 58,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 45,50 m

kW 22,00 kW

Power consumption

Efficiency ---

Model N4 65-200A/B

Family N

Code 5000160100000

Speed Fixed speed

Max Flow Rate 96,00 m³/h

H max 14,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 7,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model N4 65-200A-60/B

Family N

Code 5000160101000

Speed Fixed speed

Max Flow Rate 96,00 m³/h

H max 14,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 6,80 m

kW 3,00 kW

Power consumption

Efficiency ---

Model N 65-250C-60/B

Family N

Code 5000162101000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 63,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 43,00 m

kW 22,00 kW

Power consumption

Efficiency ---

Model N 65-250B-60/B

Family N

Code 5000164101000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 74,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 60,50 m

kW 30,00 kW

Power consumption

Efficiency ---

Model N4 65-250B/B

Family N

Code 5000166100000

Speed Fixed speed

Max Flow Rate 96,00 m³/h

H max 17,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 7,00 m

kW 4,00 kW

Power consumption

Efficiency ---

Model N4 65-250B-60/B

Family N

Code 5000166101000

Speed Fixed speed

Max Flow Rate 96,00 m³/h

H max 19,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 7,10 m

kW 4,00 kW

Power consumption

Efficiency ---

Model N 65-250A/B

Family N

Code 5000168100000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 86,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 74,50 m

kW 37,00 kW

Power consumption

Efficiency ---

Model N 65-250A-60/B

Family N

Code 5000168101000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 87,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 74,50 m

kW 37,00 kW

Power consumption

Efficiency ---

Model N4 65-250A/B

Family N

Code 5000170100000

Speed Fixed speed

Max Flow Rate 96,00 m³/h

H max 22,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 12,60 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N4 65-250A-60/B

Family N

Code 5000170101000

Speed Fixed speed

Max Flow Rate 96,00 m³/h

H max 23,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 13,70 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N4 65-315C/A

Family N

Code 5000172000000

Speed Fixed speed

Max Flow Rate 84,00 m³/h

H max 25,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 11,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N4 65-315C-60/A

Family N

Code 5000172001000

Speed Fixed speed

Max Flow Rate 84,00 m³/h

H max 27,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 13,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N4 65-315B/A

Family N

Code 5000174000000

Speed Fixed speed

Max Flow Rate 84,00 m³/h

H max 31,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 18,60 m

kW 7,50 kW

Power consumption

Efficiency ---

Model N4 65-315B-60/A

Family N

Code 5000174001000

Speed Fixed speed

Max Flow Rate 84,00 m³/h

H max 32,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 20,50 m

kW 7,50 kW

Power consumption

Efficiency ---

Model N4 65-315A/A

Family N

Code 5000176000000

Speed Fixed speed

Max Flow Rate 84,00 m³/h

H max 35,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 25,00 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N4 65-315A-60/A

Family N

Code 5000176001000

Speed Fixed speed

Max Flow Rate 84,00 m³/h

H max 36,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 26,50 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N 80-160E/B

Family N

Code 5000178100000

Speed Fixed speed

Max Flow Rate 168,00 m³/h

H max 21,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 75,00 m³/h

Min head 10,60 m

kW 7,50 kW

Power consumption

Efficiency ---

Model N 80-160E-60/B

Family N

Code 5000178101000

Speed Fixed speed

Max Flow Rate 168,00 m³/h

H max 23,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 75,00 m³/h

Min head 11,90 m

kW 7,50 kW

Power consumption

Efficiency ---

Model N 80-160D/B

Family N

Code 5000180100000

Speed Fixed speed

Max Flow Rate 168,00 m³/h

H max 25,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 75,00 m³/h

Min head 14,40 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N 80-160D-60/B

Family N

Code 5000180101000

Speed Fixed speed

Max Flow Rate 168,00 m³/h

H max 26,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 75,00 m³/h

Min head 15,10 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N 80-160C/B

Family N

Code 5000182100000

Speed Fixed speed

Max Flow Rate 180,00 m³/h

H max 28,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 75,00 m³/h

Min head 16,40 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N 80-160C-60/B

Family N

Code 5000182101000

Speed Fixed speed

Max Flow Rate 180,00 m³/h

H max 30,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 75,00 m³/h

Min head 17,90 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N4 80-160C/B

Family N

Code 5000184100000

Speed Fixed speed

Max Flow Rate 84,00 m³/h

H max 6,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 3,30 m

kW 1,10 kW

Power consumption

Efficiency ---

Model N 80-250C-60/A

Family N

Code 5000208001000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 73,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 75,00 m³/h

Min head 51,00 m

kW 37,00 kW

Power consumption

Efficiency ---

Model N4 80-250C/A

Family N

Code 5000210000000

Speed Fixed speed

Max Flow Rate 120,00 m³/h

H max 16,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 7,20 m

kW 4,00 kW

Power consumption

Efficiency ---

Model N4 80-250C-60/A

Family N

Code 5000210001000

Speed Fixed speed

Max Flow Rate 108,00 m³/h

H max 17,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 9,50 m

kW 4,00 kW

Power consumption

Efficiency ---

Model N 80-250B/A

Family N

Code 5000212000000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 84,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 75,00 m³/h

Min head 63,00 m

kW 45,00 kW

Power consumption

Efficiency ---

Model N 80-250B-60/A

Family N

Code 5000212001000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 84,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 75,00 m³/h

Min head 62,50 m

kW 45,00 kW

Power consumption

Efficiency ---

Model N4 80-250B/A

Family N

Code 5000214000000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 20,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 9,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N4 80-250B-60/A

Family N

Code 5000214001000

Speed Fixed speed

Max Flow Rate 120,00 m³/h

H max 20,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 11,50 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N 80-250A-60/A

Family N

Code 5000216001000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 94,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 75,00 m³/h

Min head 76,50 m

kW 55,00 kW

Power consumption

Efficiency ---

Model N4 80-250A-60/A

Family N

Code 5000218001000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 24,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 12,70 m

kW 7,50 kW

Power consumption

Efficiency ---

Model N4 80-315C/B

Family N

Code 5000220100000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 25,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 15,90 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N4 80-315C-60/B

Family N

Code 5000220101000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 26,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 16,20 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N4 80-315B/B

Family N

Code 5000222100000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 30,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 22,00 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N4 80-315B-60/B

Family N

Code 5000222101000

Speed Fixed speed

Max Flow Rate 150,00 m³/h

H max 31,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 17,50 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N4 80-315A-60/B

Family N

Code 5000224101000

Speed Fixed speed

Max Flow Rate 168,00 m³/h

H max 36,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 20,60 m

kW 15,00 kW

Power consumption

Efficiency ---

Model N 100-200B-60/A

Family N

Code 5000240001000

Speed Fixed speed

Max Flow Rate 270,00 m³/h

H max 54,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 108,00 m³/h

Min head 38,00 m

kW 37,00 kW

Power consumption

Efficiency ---

Model N4 100-200B-60/A

Family N

Code 5000242001000

Speed Fixed speed

Max Flow Rate 168,00 m³/h

H max 11,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 4,60 m

kW 4,00 kW

Power consumption

Efficiency ---

Model N 100-200A-60/A

Family N

Code 5000244001000

Speed Fixed speed

Max Flow Rate 300,00 m³/h

H max 61,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 108,00 m³/h

Min head 42,00 m

kW 45,00 kW

Power consumption

Efficiency ---

Model N4 100-200A/A

Family N

Code 5000246000000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 15,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 6,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N 100-250B-60/A

Family N

Code 5000248001000

Speed Fixed speed

Max Flow Rate 300,00 m³/h

H max 73,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 108,00 m³/h

Min head 48,00 m

kW 55,00 kW

Power consumption

Efficiency ---

Model N4 100-250B-60/A

Family N

Code 5000250001000

Speed Fixed speed

Max Flow Rate 210,00 m³/h

H max 19,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 5,50 m

kW 7,50 kW

Power consumption

Efficiency ---

Model N 100-250A-60/A

Family N

Code 5000252001000

Speed Fixed speed

Max Flow Rate 300,00 m³/h

H max 90,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 108,00 m³/h

Min head 67,00 m

kW 75,00 kW

Power consumption

Efficiency ---

Model N4 100-250A-60/A

Family N

Code 5000254001000

Speed Fixed speed

Max Flow Rate 210,00 m³/h

H max 22,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 8,80 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N4 100-315C/A

Family N

Code 5000256000000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 26,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 11,30 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N4 100-315C-60/A

Family N

Code 5000256001000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 28,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 10,00 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N4 100-315B/A

Family N

Code 5000258000000

Speed Fixed speed

Max Flow Rate 210,00 m³/h

H max 31,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 14,00 m

kW 15,00 kW

Power consumption

Efficiency ---

Model N4 100-315B-60/A

Family N

Code 5000258001000

Speed Fixed speed

Max Flow Rate 210,00 m³/h

H max 32,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 13,50 m

kW 15,00 kW

Power consumption

Efficiency ---

Model N4 100-315A-60/A

Family N

Code 5000260001000

Speed Fixed speed

Max Flow Rate 210,00 m³/h

H max 38,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 21,00 m

kW 18,50 kW

Power consumption

Efficiency ---

Model N4 100-400C/A

Family N

Code 5000262000000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 41,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 26,00 m

kW 22,00 kW

Power consumption

Efficiency ---

Model N4 100-400C-60/A

Family N

Code 5000262001000

Speed Fixed speed

Max Flow Rate 180,00 m³/h

H max 43,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 28,00 m

kW 22,00 kW

Power consumption

Efficiency ---

Model N4 100-400B/A

Family N

Code 5000264000000

Speed Fixed speed

Max Flow Rate 210,00 m³/h

H max 50,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 33,50 m

kW 30,00 kW

Power consumption

Efficiency ---

Model N4 100-400B-60/A

Family N

Code 5000264001000

Speed Fixed speed

Max Flow Rate 210,00 m³/h

H max 51,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 33,00 m

kW 30,00 kW

Power consumption

Efficiency ---

Model N4 100-400A-60/A

Family N

Code 5000266001000

Speed Fixed speed

Max Flow Rate 210,00 m³/h

H max 59,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 44,00 m

kW 37,00 kW

Power consumption

Efficiency ---

Model N4 125-250E/A

Family N

Code 5000268000000

Speed Fixed speed

Max Flow Rate 240,00 m³/h

H max 11,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 84,00 m³/h

Min head 4,40 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N4 125-250E-60/A

Family N

Code 5000268001000

Speed Fixed speed

Max Flow Rate 210,00 m³/h

H max 11,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 84,00 m³/h

Min head 6,20 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N4 125-250D/A

Family N

Code 5000270000000

Speed Fixed speed

Max Flow Rate 270,00 m³/h

H max 14,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 84,00 m³/h

Min head 5,10 m

kW 7,50 kW

Power consumption

Efficiency ---

Model N4 125-250D-60/A

Family N

Code 5000270001000

Speed Fixed speed

Max Flow Rate 270,00 m³/h

H max 14,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 84,00 m³/h

Min head 5,00 m

kW 7,50 kW

Power consumption

Efficiency ---

Model N4 150-400B/B

Family N

Code 5000300100000

Speed Fixed speed

Max Flow Rate 600,00 m³/h

H max 42,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 132,00 m³/h

Min head 25,40 m

kW 55,00 kW

Power consumption

Efficiency ---

Model N4 150-400B-60/B

Family N

Code 5000300101000

Speed Fixed speed

Max Flow Rate 600,00 m³/h

H max 42,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 132,00 m³/h

Min head 27,10 m

kW 55,00 kW

Power consumption

Efficiency ---

Model N4 150-400A-60/B

Family N

Code 5000302101000

Speed Fixed speed

Max Flow Rate 660,00 m³/h

H max 51,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 132,00 m³/h

Min head 32,70 m

kW 75,00 kW

Power consumption

Efficiency ---

Model N 32L-160C-60

Family N

Code 5000303001000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 26,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 9,60 m³/h

Min head 13,70 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N 32L-160B-60

Family N

Code 5000305001000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 30,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 9,60 m³/h

Min head 20,10 m

kW 3,00 kW

Power consumption

Efficiency ---

Model N 32L-200B-60

Family N

Code 5000310001000

Speed Fixed speed

Max Flow Rate 29,00 m³/h

H max 52,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 9,60 m³/h

Min head 30,60 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N 32L-200A-60

Family N

Code 5000312001000

Speed Fixed speed

Max Flow Rate 32,00 m³/h

H max 60,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 9,60 m³/h

Min head 35,30 m

kW 7,50 kW

Power consumption

Efficiency ---

Model N4 200-400C

Family N

Code 5000314000000

Speed Fixed speed

Max Flow Rate 900,00 m³/h

H max 47,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 180,00 m³/h

Min head 27,00 m

kW 90,00 kW

Power consumption

Efficiency ---

Model N4 200-400C-60

Family N

Code 5000314001000

Speed Fixed speed

Max Flow Rate 900,00 m³/h

H max 48,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 180,00 m³/h

Min head 27,60 m

kW 90,00 kW

Power consumption

Efficiency ---

Model N4 200-400B

Family N

Code 5000316000000

Speed Fixed speed

Max Flow Rate 900,00 m³/h

H max 53,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 180,00 m³/h

Min head 34,30 m

kW 110,00 kW

Power consumption

Efficiency ---

Model N4 200-400B-60

Family N

Code 5000316001000

Speed Fixed speed

Max Flow Rate 900,00 m³/h

H max 54,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 180,00 m³/h

Min head 34,60 m

kW 110,00 kW

Power consumption

Efficiency ---

Model N4 200-400A-60

Family N

Code 5000318001000

Speed Fixed speed

Max Flow Rate 900,00 m³/h

H max 59,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 180,00 m³/h

Min head 40,80 m

kW 132,00 kW

Power consumption

Efficiency ---

Model N 32L-200C

Family N

Code 5000309000000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 42,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 9,60 m³/h

Min head 23,80 m

kW 4,00 kW

Power consumption

Efficiency ---

Model N 100-250A/A

Family N

Code 5000252000000

Speed Fixed speed

Max Flow Rate 300,00 m³/h

H max 91,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 108,00 m³/h

Min head 67,00 m

kW 75,00 kW

Power consumption

Efficiency ---

Model N 50-125A/A

Family N

Code 5000090000000

Speed Fixed speed

Max Flow Rate 78,00 m³/h

H max 24,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 10,00 m

kW 4,00 kW

Power consumption

Efficiency ---

Model N 100-200A/A

Family N

Code 5000244000000

Speed Fixed speed

Max Flow Rate 300,00 m³/h

H max 61,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 108,00 m³/h

Min head 42,00 m

kW 45,00 kW

Power consumption

Efficiency ---

Model N 50-200A/A

Family N

Code 5000108000000

Speed Fixed speed

Max Flow Rate 78,00 m³/h

H max 55,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 24,00 m³/h

Min head 32,50 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N4 100-200C/A

Family N

Code 5000238000000

Speed Fixed speed

Max Flow Rate 150,00 m³/h

H max 9,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 4,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model N 80-200A/B

Family N

Code 5000200100000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 56,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 75,00 m³/h

Min head 45,60 m

kW 30,00 kW

Power consumption

Efficiency ---

Model N4 100-250A/A

Family N

Code 5000254000000

Speed Fixed speed

Max Flow Rate 210,00 m³/h

H max 22,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 8,90 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N4 100-250B/A

Family N

Code 5000250000000

Speed Fixed speed

Max Flow Rate 210,00 m³/h

H max 19,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 5,50 m

kW 7,50 kW

Power consumption

Efficiency ---

Model N 50-125S/A

Family N

Code 5000090A00000

Speed Fixed speed

Max Flow Rate 54,00 m³/h

H max 26,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 22,00 m

kW 4,00 kW

Power consumption

Efficiency ---

Model N 50-125S-S/A

Family N

Code 5000090A02000

Speed Fixed speed

Max Flow Rate 81,00 m³/h

H max 26,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 11,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N4 50-125S/A

Family N

Code 5000092A00000

Speed Fixed speed

Max Flow Rate 37,80 m³/h

H max 6,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 3,80 m

kW 0,75 kW

Power consumption

Efficiency ---

Model N 65-160AR-60

Family N

Code 5000148A01000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 35,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 28,50 m

kW 15,00 kW

Power consumption

Efficiency ---

Model N4 65-160S

Family N

Code 5000150A00000

Speed Fixed speed

Max Flow Rate 84,00 m³/h

H max 10,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 5,70 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N4 65-160S-60

Family N

Code 5000150A01000

Speed Fixed speed

Max Flow Rate 84,00 m³/h

H max 10,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 6,20 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N4 80-315S

Family N

Code 5000224A00000

Speed Fixed speed

Max Flow Rate 168,00 m³/h

H max 39,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 22,50 m

kW 18,50 kW

Power consumption

Efficiency ---

Model N4 80-315S-60

Family N

Code 5000224A01000

Speed Fixed speed

Max Flow Rate 168,00 m³/h

H max 42,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 28,00 m

kW 18,50 kW

Power consumption

Efficiency ---

Model N4 150-400S-60

Family N

Code 5000302A01000

Speed Fixed speed

Max Flow Rate 660,00 m³/h

H max 60,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 132,00 m³/h

Min head 42,50 m

kW 90,00 kW

Power consumption

Efficiency ---

Model N 50-200S/A

Family N

Code 5000108A00000

Speed Fixed speed

Max Flow Rate 78,00 m³/h

H max 60,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 24,00 m³/h

Min head 37,00 m

kW 15,00 kW

Power consumption

Efficiency ---

Model N 65-160AR

Family N

Code 5000148A00000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 36,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 27,50 m

kW 15,00 kW

Power consumption

Efficiency ---

Model N4 150-400S

Family N

Code 5000302A00000

Speed Fixed speed

Max Flow Rate 660,00 m³/h

H max 60,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 132,00 m³/h

Min head 37,60 m

kW 90,00 kW

Power consumption

Efficiency ---

Model N4 80-400S

Family N

Code 5000230A00000

Speed Fixed speed

Max Flow Rate 180,00 m³/h

H max 61,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 39,20 m

kW 37,00 kW

Power consumption

Efficiency ---

Model N4 80-400S-60

Family N

Code 5000230A01000

Speed Fixed speed

Max Flow Rate 180,00 m³/h

H max 64,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 36,80 m

kW 37,00 kW

Power consumption

Efficiency ---

Model N 50-250B/A

Family N

Code 5000116000000

Speed Fixed speed

Max Flow Rate 69,00 m³/h

H max 69,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 24,00 m³/h

Min head 43,00 m

kW 15,00 kW

Power consumption

Efficiency ---

Model N4 100-200A-60/A

Family N

Code 5000246001000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 14,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 5,50 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N4 32-125A/A

Family N

Code 5000012000000

Speed Fixed speed

Max Flow Rate 10,80 m³/h

H max 5,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,40 m³/h

Min head 4,30 m

kW 0,25 kW

Power consumption

Efficiency ---

Model N4 50-160A-60/A

Family N

Code 5000100001000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 10,55 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 5,30 m

kW 1,10 kW

Power consumption

Efficiency ---

Model N 40-160B-60/A

Family N

Code 5000050001000

Speed Fixed speed

Max Flow Rate 39,00 m³/h

H max 31,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 18,10 m

kW 3,00 kW

Power consumption

Efficiency ---

Model N 50-250S/A

Family N

Code 5000120A00000

Speed Fixed speed

Max Flow Rate 69,00 m³/h

H max 88,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 24,00 m³/h

Min head 68,50 m

kW 22,00 kW

Power consumption

Efficiency ---

Model N 32-125F/A

Family N

Code 5000002000000

Speed Fixed speed

Max Flow Rate 16,80 m³/h

H max 12,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 6,00 m

kW 0,55 kW

Power consumption

Efficiency ---

Model N 32-125F-60/A

Family N

Code 5000002001000

Speed Fixed speed

Max Flow Rate 15,00 m³/h

H max 12,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 7,00 m

kW 0,55 kW

Power consumption

Efficiency ---

Model N4 32-125F/A

Family N

Code 5000004000000

Speed Fixed speed

Max Flow Rate 9,60 m³/h

H max 3,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,40 m³/h

Min head 1,10 m

kW 0,25 kW

Power consumption

Efficiency ---

Model N 32-125D/A

Family N

Code 5000006000000

Speed Fixed speed

Max Flow Rate 9,60 m³/h

H max 18,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 17,00 m

kW 0,75 kW

Power consumption

Efficiency ---

Model N 32-125D-60/A

Family N

Code 5000006001000

Speed Fixed speed

Max Flow Rate 10,80 m³/h

H max 18,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 17,20 m

kW 0,75 kW

Power consumption

Efficiency ---

Model N 32-125D-S/A

Family N

Code 5000006002000

Speed Fixed speed

Max Flow Rate 21,00 m³/h

H max 18,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 8,50 m

kW 1,10 kW

Power consumption

Efficiency ---

Model N 32-125D-60-S/A

Family N

Code 5000006003000

Speed Fixed speed

Max Flow Rate 15,00 m³/h

H max 18,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 14,40 m

kW 1,10 kW

Power consumption

Efficiency ---

Model N4 32-125D/A

Family N

Code 5000008000000

Speed Fixed speed

Max Flow Rate 10,80 m³/h

H max 4,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,40 m³/h

Min head 2,60 m

kW 0,25 kW

Power consumption

Efficiency ---

Model N 32-125A-60/A

Family N

Code 5000010001000

Speed Fixed speed

Max Flow Rate 10,80 m³/h

H max 24,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 22,80 m

kW 1,10 kW

Power consumption

Efficiency ---

Model N 32-125A-S/A

Family N

Code 5000010002000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 23,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 10,00 m

kW 1,50 kW

Power consumption

Efficiency ---

Model N 32-125A-60-S/A

Family N

Code 5000010003000

Speed Fixed speed

Max Flow Rate 15,00 m³/h

H max 24,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 20,10 m

kW 1,50 kW

Power consumption

Efficiency ---

Model N 32-125S/A

Family N

Code 5000014000000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 23,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 13,00 m

kW 1,50 kW

Power consumption

Efficiency ---

Model N 32-125S-60/A

Family N

Code 5000014001000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 25,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 12,00 m

kW 1,50 kW

Power consumption

Efficiency ---

Model N 32-160B/A

Family N

Code 5000016000000

Speed Fixed speed

Max Flow Rate 15,00 m³/h

H max 29,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 25,00 m

kW 1,50 kW

Power consumption

Efficiency ---

Model N 32-160B-60/A

Family N

Code 5000016001000

Speed Fixed speed

Max Flow Rate 10,80 m³/h

H max 31,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 29,00 m

kW 1,50 kW

Power consumption

Efficiency ---

Model N 32-160B-S/A

Family N

Code 5000016002000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 29,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 12,50 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N 32-160B-60-S/A

Family N

Code 5000016003000

Speed Fixed speed

Max Flow Rate 16,80 m³/h

H max 31,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 23,00 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N4 32-160B/A

Family N

Code 5000018000000

Speed Fixed speed

Max Flow Rate 10,80 m³/h

H max 7,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,40 m³/h

Min head 4,20 m

kW 0,37 kW

Power consumption

Efficiency ---

Model N4 32-160B-60/A

Family N

Code 5000018001000

Speed Fixed speed

Max Flow Rate 10,80 m³/h

H max 7,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,40 m³/h

Min head 4,40 m

kW 0,37 kW

Power consumption

Efficiency ---

Model N 32-160A/A

Family N

Code 5000020000000

Speed Fixed speed

Max Flow Rate 16,80 m³/h

H max 35,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 30,00 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N 32-160A-60/A

Family N

Code 5000020001000

Speed Fixed speed

Max Flow Rate 12,00 m³/h

H max 36,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 33,00 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N 32-160A-S/A

Family N

Code 5000020002000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 35,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 15,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model N 32-160A-60-S/A

Family N

Code 5000020003000

Speed Fixed speed

Max Flow Rate 16,80 m³/h

H max 36,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 29,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model N4 32-160A/A

Family N

Code 5000022000000

Speed Fixed speed

Max Flow Rate 12,00 m³/h

H max 9,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,40 m³/h

Min head 5,10 m

kW 0,37 kW

Power consumption

Efficiency ---

Model N4 32-160A-60/A

Family N

Code 5000022001000

Speed Fixed speed

Max Flow Rate 12,00 m³/h

H max 9,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,40 m³/h

Min head 5,40 m

kW 0,37 kW

Power consumption

Efficiency ---

Model N 32-200D/A

Family N

Code 5000024000000

Speed Fixed speed

Max Flow Rate 10,80 m³/h

H max 37,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 34,00 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N 32-200D-60/A

Family N

Code 5000024001000

Speed Fixed speed

Max Flow Rate 10,80 m³/h

H max 39,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 35,00 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N 32-200D-S/A

Family N

Code 5000024002000

Speed Fixed speed

Max Flow Rate 18,90 m³/h

H max 37,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 22,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model N 32-200D-60-S/A

Family N

Code 5000024003000

Speed Fixed speed

Max Flow Rate 13,20 m³/h

H max 39,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 32,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model N 32-200C/A

Family N

Code 5000026000000

Speed Fixed speed

Max Flow Rate 18,90 m³/h

H max 44,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 32,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model N 32-200C-60/A

Family N

Code 5000026001000

Speed Fixed speed

Max Flow Rate 16,80 m³/h

H max 45,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 34,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model N4 32-200B/A

Family N

Code 5000028000000

Speed Fixed speed

Max Flow Rate 13,20 m³/h

H max 12,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,40 m³/h

Min head 4,70 m

kW 0,55 kW

Power consumption

Efficiency ---

Model N4 32-200B-60/A

Family N

Code 5000028001000

Speed Fixed speed

Max Flow Rate 13,20 m³/h

H max 13,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,40 m³/h

Min head 5,70 m

kW 0,55 kW

Power consumption

Efficiency ---

Model N 32-200A-60/A

Family N

Code 5000030001000

Speed Fixed speed

Max Flow Rate 13,20 m³/h

H max 57,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 53,00 m

kW 4,00 kW

Power consumption

Efficiency ---

Model N 32-200A-S/A

Family N

Code 5000030002000

Speed Fixed speed

Max Flow Rate 18,90 m³/h

H max 57,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 46,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N 32-200A-60-S/A

Family N

Code 5000030003000

Speed Fixed speed

Max Flow Rate 16,80 m³/h

H max 57,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 49,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N4 32-200A/A

Family N

Code 5000032000000

Speed Fixed speed

Max Flow Rate 13,20 m³/h

H max 14,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,40 m³/h

Min head 7,50 m

kW 0,75 kW

Power consumption

Efficiency ---

Model N4 32-200A-60/A

Family N

Code 5000032001000

Speed Fixed speed

Max Flow Rate 13,20 m³/h

H max 14,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,40 m³/h

Min head 8,50 m

kW 0,75 kW

Power consumption

Efficiency ---

Model N 32-125A/A

Family N

Code 5000010000000

Speed Fixed speed

Max Flow Rate 13,20 m³/h

H max 23,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 20,50 m

kW 1,10 kW

Power consumption

Efficiency ---

Model N4 125-250B/A

Family N

Code 5000274000000

Speed Fixed speed

Max Flow Rate 300,00 m³/h

H max 19,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 84,00 m³/h

Min head 8,20 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N4 80-250A/A

Family N

Code 5000218000000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 23,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 12,70 m

kW 7,50 kW

Power consumption

Efficiency ---

Model N 50-200B/A

Family N

Code 5000104000000

Speed Fixed speed

Max Flow Rate 78,00 m³/h

H max 48,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 24,00 m³/h

Min head 23,00 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N4 100-400A/A

Family N

Code 5000266000000

Speed Fixed speed

Max Flow Rate 210,00 m³/h

H max 58,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 44,00 m

kW 37,00 kW

Power consumption

Efficiency ---

Model N 100-250B/A

Family N

Code 5000248000000

Speed Fixed speed

Max Flow Rate 300,00 m³/h

H max 73,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 108,00 m³/h

Min head 48,50 m

kW 55,00 kW

Power consumption

Efficiency ---

Model N 100-200B/A

Family N

Code 5000240000000

Speed Fixed speed

Max Flow Rate 300,00 m³/h

H max 54,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 108,00 m³/h

Min head 32,00 m

kW 37,00 kW

Power consumption

Efficiency ---

Model N 32L-200A

Family N

Code 5000312000000

Speed Fixed speed

Max Flow Rate 32,00 m³/h

H max 59,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 9,60 m³/h

Min head 37,70 m

kW 7,50 kW

Power consumption

Efficiency ---

Model N4 150-315D/B

Family N

Code 5000290000000

Speed Fixed speed

Max Flow Rate 450,00 m³/h

H max 20,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 132,00 m³/h

Min head 5,20 m

kW 18,50 kW

Power consumption

Efficiency ---

Model N4 150-315D-60/B

Family N

Code 5000290001000

Speed Fixed speed

Max Flow Rate 450,00 m³/h

H max 20,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 132,00 m³/h

Min head 7,00 m

kW 18,50 kW

Power consumption

Efficiency ---

Model N4 150-315C/B

Family N

Code 5000292000000

Speed Fixed speed

Max Flow Rate 480,00 m³/h

H max 30,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 132,00 m³/h

Min head 17,00 m

kW 22,00 kW

Power consumption

Efficiency ---

Model N4 150-315C-60/B

Family N

Code 5000292001000

Speed Fixed speed

Max Flow Rate 480,00 m³/h

H max 29,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 132,00 m³/h

Min head 16,70 m

kW 22,00 kW

Power consumption

Efficiency ---

Model N4 150-315B/B

Family N

Code 5000294100000

Speed Fixed speed

Max Flow Rate 540,00 m³/h

H max 25,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 132,00 m³/h

Min head 15,10 m

kW 30,00 kW

Power consumption

Efficiency ---

Model N4 150-315B-60/B

Family N

Code 5000294101000

Speed Fixed speed

Max Flow Rate 480,00 m³/h

H max 26,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 132,00 m³/h

Min head 17,40 m

kW 30,00 kW

Power consumption

Efficiency ---

Model N4 150-315A/B

Family N

Code 5000296100000

Speed Fixed speed

Max Flow Rate 600,00 m³/h

H max 29,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 132,00 m³/h

Min head 16,70 m

kW 37,00 kW

Power consumption

Efficiency ---

Model N4 150-315A-60/B

Family N

Code 5000296101000

Speed Fixed speed

Max Flow Rate 600,00 m³/h

H max 30,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 132,00 m³/h

Min head 17,80 m

kW 37,00 kW

Power consumption

Efficiency ---

Model N4 150-315S

Family N

Code 5000296A00000

Speed Fixed speed

Max Flow Rate 660,00 m³/h

H max 34,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 132,00 m³/h

Min head 18,70 m

kW 45,00 kW

Power consumption

Efficiency ---

Model N4 150-315S-60

Family N

Code 5000296A01000

Speed Fixed speed

Max Flow Rate 660,00 m³/h

H max 35,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 132,00 m³/h

Min head 19,80 m

kW 45,00 kW

Power consumption

Efficiency ---

Model N 80-250D/A

Family N

Code 5000206000000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 65,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 75,00 m³/h

Min head 41,00 m

kW 30,00 kW

Power consumption

Efficiency ---

Model BN 40-160B-60/A

Family N

Code 5100050001000

Speed Fixed speed

Max Flow Rate 39,00 m³/h

H max 31,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 18,10 m

kW 3,00 kW

Power consumption

Efficiency ---

Model BN 32-125D-60/A

Family N

Code 5100006001000

Speed Fixed speed

Max Flow Rate 10,80 m³/h

H max 18,80 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 17,20 m

kW 0,75 kW

Power consumption

Efficiency ---

Model BN 32-125D-S/A

Family N

Code 5100006002000

Speed Fixed speed

Max Flow Rate 21,00 m³/h

H max 18,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 8,50 m

kW 1,10 kW

Power consumption

Efficiency ---

Model BN 32-125D-60-S/A

Family N

Code 5100006003000

Speed Fixed speed

Max Flow Rate 15,00 m³/h

H max 18,80 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 14,40 m

kW 1,10 kW

Power consumption

Efficiency ---

Model BN 32-125F/A

Family N

Code 5100002000000

Speed Fixed speed

Max Flow Rate 16,80 m³/h

H max 12,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 6,00 m

kW 0,55 kW

Power consumption

Efficiency ---

Model BN 32-125F-60/A

Family N

Code 5100002001000

Speed Fixed speed

Max Flow Rate 15,00 m³/h

H max 12,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 7,00 m

kW 0,55 kW

Power consumption

Efficiency ---

Model BN4 32-125F/A

Family N

Code 5100004000000

Speed Fixed speed

Max Flow Rate 9,60 m³/h

H max 3,60 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 2,40 m³/h

Min head 1,10 m

kW 0,25 kW

Power consumption

Efficiency ---

Model BN 32-125D/A

Family N

Code 5100006000000

Speed Fixed speed

Max Flow Rate 9,60 m³/h

H max 18,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 17,00 m

kW 0,75 kW

Power consumption

Efficiency ---

Model BN4 32-125D/A

Family N

Code 5100008000000

Speed Fixed speed

Max Flow Rate 10,80 m³/h

H max 4,70 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 2,40 m³/h

Min head 2,60 m

kW 0,25 kW

Power consumption

Efficiency ---

Model BN 32-125A/A

Family N

Code 5100010000000

Speed Fixed speed

Max Flow Rate 13,20 m³/h

H max 23,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 20,50 m

kW 1,10 kW

Power consumption

Efficiency ---

Model BN 32-125A-60/A

Family N

Code 5100010001000

Speed Fixed speed

Max Flow Rate 10,80 m³/h

H max 24,30 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 22,80 m

kW 1,10 kW

Power consumption

Efficiency ---

Model BN 32-125A-S/A

Family N

Code 5100010002000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 23,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 10,00 m

kW 1,50 kW

Power consumption

Efficiency ---

Model BN 32-125A-60-S/A

Family N

Code 5100010003000

Speed Fixed speed

Max Flow Rate 15,00 m³/h

H max 24,30 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 20,10 m

kW 1,50 kW

Power consumption

Efficiency ---

Model BN4 32-125A/A

Family N

Code 5100012000000

Speed Fixed speed

Max Flow Rate 10,80 m³/h

H max 5,70 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 2,40 m³/h

Min head 4,30 m

kW 0,25 kW

Power consumption

Efficiency ---

Model BN 32-125S/A

Family N

Code 5100014000000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 23,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 13,00 m

kW 1,50 kW

Power consumption

Efficiency ---

Model BN 32-125S-60/A

Family N

Code 5100014001000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 25,20 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 12,00 m

kW 1,50 kW

Power consumption

Efficiency ---

Model BN 32-160B/A

Family N

Code 5100016000000

Speed Fixed speed

Max Flow Rate 15,00 m³/h

H max 29,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 25,00 m

kW 1,50 kW

Power consumption

Efficiency ---

Model BN 32-160B-60/A

Family N

Code 5100016001000

Speed Fixed speed

Max Flow Rate 10,80 m³/h

H max 31,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 29,00 m

kW 1,50 kW

Power consumption

Efficiency ---

Model BN 32-160B-S/A

Family N

Code 5100016002000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 29,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 12,50 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN 32-160B-60-S/A

Family N

Code 5100016003000

Speed Fixed speed

Max Flow Rate 16,80 m³/h

H max 31,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 23,00 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN4 32-160B/A

Family N

Code 5100018000000

Speed Fixed speed

Max Flow Rate 10,80 m³/h

H max 7,60 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 2,40 m³/h

Min head 4,20 m

kW 0,37 kW

Power consumption

Efficiency ---

Model BN4 32-160B-60/A

Family N

Code 5100018001000

Speed Fixed speed

Max Flow Rate 10,80 m³/h

H max 7,60 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 2,40 m³/h

Min head 4,40 m

kW 0,37 kW

Power consumption

Efficiency ---

Model BN 32-160A/A

Family N

Code 5100020000000

Speed Fixed speed

Max Flow Rate 16,80 m³/h

H max 35,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 30,00 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN 32-160A-60/A

Family N

Code 5100020001000

Speed Fixed speed

Max Flow Rate 12,00 m³/h

H max 36,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 33,00 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN 32-160A-S/A

Family N

Code 5100020002000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 35,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 15,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model BN 32-160A-60-S/A

Family N

Code 5100020003000

Speed Fixed speed

Max Flow Rate 16,80 m³/h

H max 36,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 29,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model BN4 32-160A/A

Family N

Code 5100022000000

Speed Fixed speed

Max Flow Rate 12,00 m³/h

H max 9,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 2,40 m³/h

Min head 5,10 m

kW 0,37 kW

Power consumption

Efficiency ---

Model BN4 32-160A-60/A

Family N

Code 5100022001000

Speed Fixed speed

Max Flow Rate 12,00 m³/h

H max 9,20 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 2,40 m³/h

Min head 5,40 m

kW 0,37 kW

Power consumption

Efficiency ---

Model BN 32-200D/A

Family N

Code 5100024000000

Speed Fixed speed

Max Flow Rate 10,80 m³/h

H max 37,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 34,00 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN 32-200D-60/A

Family N

Code 5100024001000

Speed Fixed speed

Max Flow Rate 10,80 m³/h

H max 39,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 35,00 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN 32-200D-S/A

Family N

Code 5100024002000

Speed Fixed speed

Max Flow Rate 18,90 m³/h

H max 37,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 22,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model BN 32-200D-60-S/A

Family N

Code 5100024003000

Speed Fixed speed

Max Flow Rate 13,20 m³/h

H max 39,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 32,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model BN 32-200C/A

Family N

Code 5100026000000

Speed Fixed speed

Max Flow Rate 18,90 m³/h

H max 44,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 32,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model BN 32-200C-60/A

Family N

Code 5100026001000

Speed Fixed speed

Max Flow Rate 16,80 m³/h

H max 45,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 34,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model BN4 32-200B/A

Family N

Code 5100028000000

Speed Fixed speed

Max Flow Rate 13,20 m³/h

H max 12,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 2,40 m³/h

Min head 4,70 m

kW 0,55 kW

Power consumption

Efficiency ---

Model BN4 32-200B-60/A

Family N

Code 5100028001000

Speed Fixed speed

Max Flow Rate 13,20 m³/h

H max 13,10 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 2,40 m³/h

Min head 5,70 m

kW 0,55 kW

Power consumption

Efficiency ---

Model BN 32-200A/A

Family N

Code 5100030000000

Speed Fixed speed

Max Flow Rate 15,00 m³/h

H max 57,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 51,00 m

kW 4,00 kW

Power consumption

Efficiency ---

Model BN 32-200A-60/A

Family N

Code 5100030001000

Speed Fixed speed

Max Flow Rate 13,20 m³/h

H max 57,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 66,60 m³/h

Min head 53,00 m

kW 4,00 kW

Power consumption

Efficiency ---

Model BN 32-200A-S/A

Family N

Code 5100030002000

Speed Fixed speed

Max Flow Rate 18,90 m³/h

H max 57,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 46,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN 32-200A-60-S/A

Family N

Code 5100030003000

Speed Fixed speed

Max Flow Rate 16,80 m³/h

H max 57,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 49,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN4 32-200A/A

Family N

Code 5100032000000

Speed Fixed speed

Max Flow Rate 13,20 m³/h

H max 14,30 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 2,40 m³/h

Min head 7,50 m

kW 0,75 kW

Power consumption

Efficiency ---

Model BN4 32-200A-60/A

Family N

Code 5100032001000

Speed Fixed speed

Max Flow Rate 13,20 m³/h

H max 14,90 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 2,40 m³/h

Min head 8,50 m

kW 0,75 kW

Power consumption

Efficiency ---

Model BN 40-125F/A

Family N

Code 5100034000000

Speed Fixed speed

Max Flow Rate 33,00 m³/h

H max 14,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 6,00 m

kW 1,10 kW

Power consumption

Efficiency ---

Model BN 40-125F-60/A

Family N

Code 5100034001000

Speed Fixed speed

Max Flow Rate 33,00 m³/h

H max 15,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 5,60 m

kW 1,10 kW

Power consumption

Efficiency ---

Model BN 40-125C/A

Family N

Code 5100038000000

Speed Fixed speed

Max Flow Rate 39,00 m³/h

H max 17,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 6,50 m

kW 1,50 kW

Power consumption

Efficiency ---

Model BN 40-125C-60/A

Family N

Code 5100038001000

Speed Fixed speed

Max Flow Rate 37,80 m³/h

H max 18,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 6,90 m

kW 1,50 kW

Power consumption

Efficiency ---

Model BN 40-125A/A

Family N

Code 5100042000000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 22,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 11,50 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN 40-125A-60/A

Family N

Code 5100042001000

Speed Fixed speed

Max Flow Rate 39,00 m³/h

H max 22,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 12,90 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN 40-160C/A

Family N

Code 5100046000000

Speed Fixed speed

Max Flow Rate 39,00 m³/h

H max 23,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 10,00 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN 40-160C-60/A

Family N

Code 5100046001000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 25,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 22,10 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN 40-160C-60-S/A

Family N

Code 5100046003000

Speed Fixed speed

Max Flow Rate 37,80 m³/h

H max 25,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 10,60 m

kW 3,00 kW

Power consumption

Efficiency ---

Model BN4 40-160C/A

Family N

Code 5100048000000

Speed Fixed speed

Max Flow Rate 21,00 m³/h

H max 6,10 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 5,40 m³/h

Min head 2,30 m

kW 0,37 kW

Power consumption

Efficiency ---

Model BN4 40-160C-60/A

Family N

Code 5100048001000

Speed Fixed speed

Max Flow Rate 18,90 m³/h

H max 6,75 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 5,40 m³/h

Min head 3,20 m

kW 0,37 kW

Power consumption

Efficiency ---

Model BN 40-160B/A

Family N

Code 5100050000000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 29,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 14,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model BN4 40-160B/A

Family N

Code 5100052000000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 7,60 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 5,40 m³/h

Min head 2,70 m

kW 0,55 kW

Power consumption

Efficiency ---

Model BN4 40-160B-60/A

Family N

Code 5100052001000

Speed Fixed speed

Max Flow Rate 21,00 m³/h

H max 8,10 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 5,40 m³/h

Min head 4,60 m

kW 0,55 kW

Power consumption

Efficiency ---

Model BN 40-160A/A

Family N

Code 5100054000000

Speed Fixed speed

Max Flow Rate 37,80 m³/h

H max 37,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 27,00 m

kW 4,00 kW

Power consumption

Efficiency ---

Model BN 40-160A-60/A

Family N

Code 5100054001000

Speed Fixed speed

Max Flow Rate 33,00 m³/h

H max 37,10 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 31,80 m

kW 4,00 kW

Power consumption

Efficiency ---

Model BN 40-160A-S/A

Family N

Code 5100054002000

Speed Fixed speed

Max Flow Rate 48,00 m³/h

H max 37,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 17,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN 40-160A-60-S/A

Family N

Code 5100054003000

Speed Fixed speed

Max Flow Rate 45,00 m³/h

H max 37,10 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 23,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN4 40-160A/A

Family N

Code 5100056000000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 9,60 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 5,40 m³/h

Min head 3,50 m

kW 0,75 kW

Power consumption

Efficiency ---

Model BN4 40-160A-60/A

Family N

Code 5100056001000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 9,70 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 5,40 m³/h

Min head 5,80 m

kW 0,75 kW

Power consumption

Efficiency ---

Model BN 40-200C/A

Family N

Code 5100058000000

Speed Fixed speed

Max Flow Rate 21,00 m³/h

H max 41,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 38,00 m

kW 4,00 kW

Power consumption

Efficiency ---

Model BN 40-200C-60/A

Family N

Code 5100058001000

Speed Fixed speed

Max Flow Rate 21,00 m³/h

H max 44,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 41,00 m

kW 4,00 kW

Power consumption

Efficiency ---

Model BN 40-200C-S/A

Family N

Code 5100058002000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 41,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 33,50 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN 40-200C-60-S/A

Family N

Code 5100058003000

Speed Fixed speed

Max Flow Rate 21,00 m³/h

H max 44,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 36,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN 40-200D/A

Family N

Code 5100058010000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 39,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 30,50 m

kW 4,00 kW

Power consumption

Efficiency ---

Model BN 40-200D-S/A

Family N

Code 5100058012000

Speed Fixed speed

Max Flow Rate 37,80 m³/h

H max 39,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 14,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN 40-200B/A

Family N

Code 5100060000000

Speed Fixed speed

Max Flow Rate 33,00 m³/h

H max 50,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 37,50 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN 40-200B-60/A

Family N

Code 5100060001000

Speed Fixed speed

Max Flow Rate 33,00 m³/h

H max 52,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 35,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN 40-200B-S/A

Family N

Code 5100060002000

Speed Fixed speed

Max Flow Rate 37,80 m³/h

H max 50,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 30,50 m

kW 7,50 kW

Power consumption

Efficiency ---

Model BN4 40-200B/A

Family N

Code 5100062000000

Speed Fixed speed

Max Flow Rate 21,00 m³/h

H max 13,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 5,40 m³/h

Min head 7,00 m

kW 1,10 kW

Power consumption

Efficiency ---

Model BN4 40-200B-60/A

Family N

Code 5100062001000

Speed Fixed speed

Max Flow Rate 18,90 m³/h

H max 13,30 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 5,40 m³/h

Min head 7,80 m

kW 1,10 kW

Power consumption

Efficiency ---

Model BN 40-200AR/A

Family N

Code 5100064000000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 55,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 51,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN 40-200AR-60/A

Family N

Code 5100064001000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 56,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 52,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN 40-200AR-S/A

Family N

Code 5100064002000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 55,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 49,00 m

kW 7,50 kW

Power consumption

Efficiency ---

Model BN 40-200AR-60-S/A

Family N

Code 5100064003000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 56,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 49,00 m

kW 7,50 kW

Power consumption

Efficiency ---

Model BN 40-200A/A

Family N

Code 5100066000000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 57,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 35,00 m

kW 7,50 kW

Power consumption

Efficiency ---

Model BN 40-200A-60/A

Family N

Code 5100066001000

Speed Fixed speed

Max Flow Rate 37,80 m³/h

H max 59,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 38,50 m

kW 7,50 kW

Power consumption

Efficiency ---

Model BN4 40-200A/A

Family N

Code 5100068000000

Speed Fixed speed

Max Flow Rate 21,00 m³/h

H max 14,80 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 5,40 m³/h

Min head 10,00 m

kW 1,10 kW

Power consumption

Efficiency ---

Model BN4 40-200A-60/A

Family N

Code 5100068001000

Speed Fixed speed

Max Flow Rate 21,00 m³/h

H max 15,30 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 5,40 m³/h

Min head 9,30 m

kW 1,10 kW

Power consumption

Efficiency ---

Model BN 40-250C/A

Family N

Code 5100070000000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 61,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 33,50 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN 40-250C-60/A

Family N

Code 5100070001000

Speed Fixed speed

Max Flow Rate 33,00 m³/h

H max 65,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 49,00 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN4 40-250C/A

Family N

Code 5100072000000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 17,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 5,40 m³/h

Min head 2,80 m

kW 1,50 kW

Power consumption

Efficiency ---

Model BN4 40-250C-60/A

Family N

Code 5100072001000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 18,30 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 5,40 m³/h

Min head 4,40 m

kW 1,50 kW

Power consumption

Efficiency ---

Model BN 40-250B/A

Family N

Code 5100074000000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 69,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 45,00 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN 40-250B-60/A

Family N

Code 5100074001000

Speed Fixed speed

Max Flow Rate 37,80 m³/h

H max 71,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 50,00 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN4 40-250B/A

Family N

Code 5100076000000

Speed Fixed speed

Max Flow Rate 30,00 m³/h

H max 21,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 5,40 m³/h

Min head 5,00 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN4 40-250B-60/A

Family N

Code 5100076001000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 22,70 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 5,40 m³/h

Min head 10,10 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN 40-250A/A

Family N

Code 5100078000000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 90,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 70,50 m

kW 15,00 kW

Power consumption

Efficiency ---

Model BN 40-250A-60/A

Family N

Code 5100078001000

Speed Fixed speed

Max Flow Rate 39,00 m³/h

H max 90,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 76,00 m

kW 15,00 kW

Power consumption

Efficiency ---

Model BN4 40-250A/A

Family N

Code 5100080000000

Speed Fixed speed

Max Flow Rate 30,00 m³/h

H max 22,90 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 5,40 m³/h

Min head 8,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model BN4 40-250A-60/A

Family N

Code 5100080001000

Speed Fixed speed

Max Flow Rate 30,00 m³/h

H max 25,10 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 5,40 m³/h

Min head 10,70 m

kW 3,00 kW

Power consumption

Efficiency ---

Model BN 50-125F/A

Family N

Code 5100082000000

Speed Fixed speed

Max Flow Rate 66,00 m³/h

H max 15,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 6,00 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN 50-125F-60/A

Family N

Code 5100082001000

Speed Fixed speed

Max Flow Rate 60,00 m³/h

H max 16,10 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 5,80 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN4 50-125F/A

Family N

Code 5100084000000

Speed Fixed speed

Max Flow Rate 33,00 m³/h

H max 4,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 10,80 m³/h

Min head 0,50 m

kW 0,37 kW

Power consumption

Efficiency ---

Model BN 50-125D/A

Family N

Code 5100086000000

Speed Fixed speed

Max Flow Rate 72,00 m³/h

H max 20,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 8,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model BN 50-125D-60/A

Family N

Code 5100086001000

Speed Fixed speed

Max Flow Rate 66,00 m³/h

H max 19,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 8,40 m

kW 3,00 kW

Power consumption

Efficiency ---

Model BN4 50-125D/A

Family N

Code 5100088000000

Speed Fixed speed

Max Flow Rate 33,00 m³/h

H max 5,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 10,80 m³/h

Min head 2,50 m

kW 0,55 kW

Power consumption

Efficiency ---

Model BN 50-125A/A

Family N

Code 5100090000000

Speed Fixed speed

Max Flow Rate 78,00 m³/h

H max 24,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 10,00 m

kW 4,00 kW

Power consumption

Efficiency ---

Model BN 50-125A-60/A

Family N

Code 5100090001000

Speed Fixed speed

Max Flow Rate 48,00 m³/h

H max 24,80 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 22,30 m

kW 4,00 kW

Power consumption

Efficiency ---

Model BN 50-125A-60-S/A

Family N

Code 5100090003000

Speed Fixed speed

Max Flow Rate 75,00 m³/h

H max 24,80 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 13,60 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN 50-125S/A

Family N

Code 5100090A00000

Speed Fixed speed

Max Flow Rate 54,00 m³/h

H max 26,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 22,00 m

kW 4,00 kW

Power consumption

Efficiency ---

Model BN 50-125S-S/A

Family N

Code 5100090A02000

Speed Fixed speed

Max Flow Rate 81,00 m³/h

H max 26,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 11,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN4 50-125A/A

Family N

Code 5100092000000

Speed Fixed speed

Max Flow Rate 37,80 m³/h

H max 6,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 10,80 m³/h

Min head 2,90 m

kW 0,75 kW

Power consumption

Efficiency ---

Model BN4 50-125S/A

Family N

Code 5100092A00000

Speed Fixed speed

Max Flow Rate 37,80 m³/h

H max 6,80 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 10,80 m³/h

Min head 3,80 m

kW 0,75 kW

Power consumption

Efficiency ---

Model BN 50-160B/A

Family N

Code 5100094000000

Speed Fixed speed

Max Flow Rate 81,00 m³/h

H max 31,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 9,50 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN 50-160B-60/A

Family N

Code 5100094001000

Speed Fixed speed

Max Flow Rate 37,80 m³/h

H max 35,30 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 33,60 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN 50-160B-60-S/A

Family N

Code 5100094003000

Speed Fixed speed

Max Flow Rate 75,00 m³/h

H max 35,30 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 15,10 m

kW 7,50 kW

Power consumption

Efficiency ---

Model BN4 50-160B/A

Family N

Code 5100096000000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 8,20 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 10,80 m³/h

Min head 3,30 m

kW 1,10 kW

Power consumption

Efficiency ---

Model BN4 50-160B-60/A

Family N

Code 5100096001000

Speed Fixed speed

Max Flow Rate 37,80 m³/h

H max 9,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 10,80 m³/h

Min head 3,80 m

kW 1,10 kW

Power consumption

Efficiency ---

Model BN 50-160A/A

Family N

Code 5100098000000

Speed Fixed speed

Max Flow Rate 81,00 m³/h

H max 38,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 19,00 m

kW 7,50 kW

Power consumption

Efficiency ---

Model BN 50-160A-60/A

Family N

Code 5100098001000

Speed Fixed speed

Max Flow Rate 84,00 m³/h

H max 41,70 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 20,40 m

kW 7,50 kW

Power consumption

Efficiency ---

Model BN4 50-160A/A

Family N

Code 5100100000000

Speed Fixed speed

Max Flow Rate 48,00 m³/h

H max 9,60 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 10,80 m³/h

Min head 3,10 m

kW 1,10 kW

Power consumption

Efficiency ---

Model BN4 50-160A-60/A

Family N

Code 5100100001000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 10,55 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 10,80 m³/h

Min head 5,30 m

kW 1,10 kW

Power consumption

Efficiency ---

Model BN4 50-200C/A

Family N

Code 5100102000000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 11,80 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 10,80 m³/h

Min head 4,70 m

kW 1,10 kW

Power consumption

Efficiency ---

Model BN4 50-200C-60/A

Family N

Code 5100102001000

Speed Fixed speed

Max Flow Rate 37,80 m³/h

H max 11,20 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 10,80 m³/h

Min head 2,70 m

kW 1,10 kW

Power consumption

Efficiency ---

Model BN 50-200B/A

Family N

Code 5100104000000

Speed Fixed speed

Max Flow Rate 78,00 m³/h

H max 48,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 24,00 m³/h

Min head 23,00 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN 50-200B-60/A

Family N

Code 5100104001000

Speed Fixed speed

Max Flow Rate 69,00 m³/h

H max 51,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 24,00 m³/h

Min head 27,30 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN4 50-200B/A

Family N

Code 5100106000000

Speed Fixed speed

Max Flow Rate 48,00 m³/h

H max 13,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 10,80 m³/h

Min head 3,70 m

kW 1,50 kW

Power consumption

Efficiency ---

Model BN4 50-200B-60/A

Family N

Code 5100106001000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 12,80 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 10,80 m³/h

Min head 3,40 m

kW 1,50 kW

Power consumption

Efficiency ---

Model BN 50-200A/A

Family N

Code 5100108000000

Speed Fixed speed

Max Flow Rate 78,00 m³/h

H max 55,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 24,00 m³/h

Min head 32,50 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN 50-200A-60/A

Family N

Code 5100108001000

Speed Fixed speed

Max Flow Rate 75,00 m³/h

H max 57,60 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 24,00 m³/h

Min head 33,20 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN 50-200S/A

Family N

Code 5100108A00000

Speed Fixed speed

Max Flow Rate 78,00 m³/h

H max 60,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 24,00 m³/h

Min head 37,00 m

kW 15,00 kW

Power consumption

Efficiency ---

Model BN4 50-200A/A

Family N

Code 5100110000000

Speed Fixed speed

Max Flow Rate 48,00 m³/h

H max 14,90 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 10,80 m³/h

Min head 6,00 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN4 50-200A-60/A

Family N

Code 5100110001000

Speed Fixed speed

Max Flow Rate 54,00 m³/h

H max 16,70 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 10,80 m³/h

Min head 5,40 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN 50-250C/A

Family N

Code 5100112000000

Speed Fixed speed

Max Flow Rate 69,00 m³/h

H max 55,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 24,00 m³/h

Min head 24,50 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN 50-250C-60/A

Family N

Code 5100112001000

Speed Fixed speed

Max Flow Rate 60,00 m³/h

H max 61,90 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 24,00 m³/h

Min head 36,50 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN4 50-250C/A

Family N

Code 5100114000000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 17,80 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 10,80 m³/h

Min head 6,80 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN4 50-250C-60/A

Family N

Code 5100114001000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 18,90 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 10,80 m³/h

Min head 7,20 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN4 50-250D

Family N

Code 5100114010000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 14,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 10,80 m³/h

Min head 2,30 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN 50-250B/A

Family N

Code 5100116000000

Speed Fixed speed

Max Flow Rate 69,00 m³/h

H max 69,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 24,00 m³/h

Min head 43,00 m

kW 15,00 kW

Power consumption

Efficiency ---

Model BN 50-250B-60/A

Family N

Code 5100116001000

Speed Fixed speed

Max Flow Rate 66,00 m³/h

H max 74,60 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 24,00 m³/h

Min head 43,80 m

kW 15,00 kW

Power consumption

Efficiency ---

Model BN4 50-250B/A

Family N

Code 5100118000000

Speed Fixed speed

Max Flow Rate 48,00 m³/h

H max 20,70 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 10,80 m³/h

Min head 5,80 m

kW 3,00 kW

Power consumption

Efficiency ---

Model BN4 50-250B-60/A

Family N

Code 5100118001000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 23,10 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 10,80 m³/h

Min head 12,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model BN 50-250A/A

Family N

Code 5100120000000

Speed Fixed speed

Max Flow Rate 69,00 m³/h

H max 80,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 24,00 m³/h

Min head 58,50 m

kW 18,50 kW

Power consumption

Efficiency ---

Model BN 50-250A-60/A

Family N

Code 5100120001000

Speed Fixed speed

Max Flow Rate 66,00 m³/h

H max 87,60 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 24,00 m³/h

Min head 66,90 m

kW 18,50 kW

Power consumption

Efficiency ---

Model BN 50-250S/A

Family N

Code 5100120A00000

Speed Fixed speed

Max Flow Rate 69,00 m³/h

H max 88,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 24,00 m³/h

Min head 68,50 m

kW 22,00 kW

Power consumption

Efficiency ---

Model BN4 50-250A/A

Family N

Code 5100122000000

Speed Fixed speed

Max Flow Rate 48,00 m³/h

H max 22,70 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 10,80 m³/h

Min head 9,00 m

kW 4,00 kW

Power consumption

Efficiency ---

Model BN4 50-250A-60/A

Family N

Code 5100122001000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 24,10 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 10,80 m³/h

Min head 14,00 m

kW 4,00 kW

Power consumption

Efficiency ---

Model BN 65-125E/B

Family N

Code 5100124100000

Speed Fixed speed

Max Flow Rate 108,00 m³/h

H max 16,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 37,80 m³/h

Min head 9,20 m

kW 4,00 kW

Power consumption

Efficiency ---

Model BN 65-125E-60/B

Family N

Code 5100124101000

Speed Fixed speed

Max Flow Rate 108,00 m³/h

H max 16,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 37,80 m³/h

Min head 9,90 m

kW 4,00 kW

Power consumption

Efficiency ---

Model BN4 65-125E/B

Family N

Code 5100126100000

Speed Fixed speed

Max Flow Rate 54,00 m³/h

H max 4,10 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 21,00 m³/h

Min head 2,30 m

kW 0,75 kW

Power consumption

Efficiency ---

Model BN4 65-125E-60/B

Family N

Code 5100126101000

Speed Fixed speed

Max Flow Rate 54,00 m³/h

H max 4,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 21,00 m³/h

Min head 2,50 m

kW 0,75 kW

Power consumption

Efficiency ---

Model BN 65-125C/B

Family N

Code 5100128100000

Speed Fixed speed

Max Flow Rate 120,00 m³/h

H max 21,10 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 37,80 m³/h

Min head 11,80 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN 65-125C-60/B

Family N

Code 5100128101000

Speed Fixed speed

Max Flow Rate 120,00 m³/h

H max 21,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 37,80 m³/h

Min head 13,10 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN4 65-125C/B

Family N

Code 5100130100000

Speed Fixed speed

Max Flow Rate 60,00 m³/h

H max 5,30 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 21,00 m³/h

Min head 3,00 m

kW 0,75 kW

Power consumption

Efficiency ---

Model BN4 65-125C-60/B

Family N

Code 5100130101000

Speed Fixed speed

Max Flow Rate 60,00 m³/h

H max 5,30 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 21,00 m³/h

Min head 3,30 m

kW 0,75 kW

Power consumption

Efficiency ---

Model BN 65-125A/B

Family N

Code 5100132100000

Speed Fixed speed

Max Flow Rate 120,00 m³/h

H max 25,90 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 37,80 m³/h

Min head 17,60 m

kW 7,50 kW

Power consumption

Efficiency ---

Model BN 65-125A-60/B

Family N

Code 5100132101000

Speed Fixed speed

Max Flow Rate 120,00 m³/h

H max 26,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 37,80 m³/h

Min head 18,90 m

kW 7,50 kW

Power consumption

Efficiency ---

Model BN4 65-125A/B

Family N

Code 5100134100000

Speed Fixed speed

Max Flow Rate 60,00 m³/h

H max 6,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 21,00 m³/h

Min head 4,40 m

kW 1,10 kW

Power consumption

Efficiency ---

Model BN4 65-125A-60/B

Family N

Code 5100134101000

Speed Fixed speed

Max Flow Rate 60,00 m³/h

H max 6,60 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 21,00 m³/h

Min head 4,70 m

kW 1,10 kW

Power consumption

Efficiency ---

Model BN 65-160D/B

Family N

Code 5100138100000

Speed Fixed speed

Max Flow Rate 120,00 m³/h

H max 24,30 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 16,30 m

kW 7,50 kW

Power consumption

Efficiency ---

Model BN 65-160D-60/B

Family N

Code 5100138101000

Speed Fixed speed

Max Flow Rate 120,00 m³/h

H max 24,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 17,60 m

kW 7,50 kW

Power consumption

Efficiency ---

Model BN 65-160C/B

Family N

Code 5100140100000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 28,10 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 17,70 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN 65-160C-60/B

Family N

Code 5100140101000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 27,90 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 19,00 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN4 65-160C/B

Family N

Code 5100142100000

Speed Fixed speed

Max Flow Rate 60,00 m³/h

H max 6,10 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 21,00 m³/h

Min head 4,20 m

kW 1,10 kW

Power consumption

Efficiency ---

Model BN4 65-160C-60/B

Family N

Code 5100142101000

Speed Fixed speed

Max Flow Rate 60,00 m³/h

H max 6,20 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 21,00 m³/h

Min head 4,30 m

kW 1,10 kW

Power consumption

Efficiency ---

Model BN 65-160B/B

Family N

Code 5100144100000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 32,60 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 23,00 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN 65-160B-60/B

Family N

Code 5100144101000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 32,80 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 24,40 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN4 65-160B/B

Family N

Code 5100146100000

Speed Fixed speed

Max Flow Rate 66,00 m³/h

H max 7,20 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 21,00 m³/h

Min head 4,50 m

kW 1,10 kW

Power consumption

Efficiency ---

Model BN4 65-160B-60/B

Family N

Code 5100146101000

Speed Fixed speed

Max Flow Rate 66,00 m³/h

H max 7,20 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 21,00 m³/h

Min head 4,60 m

kW 1,10 kW

Power consumption

Efficiency ---

Model BN 65-160A/B

Family N

Code 5100148100000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 40,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 31,70 m

kW 15,00 kW

Power consumption

Efficiency ---

Model BN 65-160A-60/B

Family N

Code 5100148101000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 40,70 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 33,20 m

kW 15,00 kW

Power consumption

Efficiency ---

Model BN 65-160AR

Family N

Code 5100148A00000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 36,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 27,50 m

kW 15,00 kW

Power consumption

Efficiency ---

Model BN 65-160AR-60

Family N

Code 5100148A01000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 35,90 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 28,50 m

kW 15,00 kW

Power consumption

Efficiency ---

Model BN4 65-160A/B

Family N

Code 5100150100000

Speed Fixed speed

Max Flow Rate 75,00 m³/h

H max 8,80 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 21,00 m³/h

Min head 5,20 m

kW 1,50 kW

Power consumption

Efficiency ---

Model BN4 65-160A-60/B

Family N

Code 5100150101000

Speed Fixed speed

Max Flow Rate 75,00 m³/h

H max 8,90 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 21,00 m³/h

Min head 5,70 m

kW 1,50 kW

Power consumption

Efficiency ---

Model BN4 65-160S

Family N

Code 5100150A00000

Speed Fixed speed

Max Flow Rate 84,00 m³/h

H max 10,20 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 21,00 m³/h

Min head 5,70 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN4 65-160S-60

Family N

Code 5100150A01000

Speed Fixed speed

Max Flow Rate 84,00 m³/h

H max 10,30 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 21,00 m³/h

Min head 6,20 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN 65-200C/B

Family N

Code 5100152100000

Speed Fixed speed

Max Flow Rate 141,00 m³/h

H max 44,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 28,80 m

kW 15,00 kW

Power consumption

Efficiency ---

Model BN 65-200C-60/B

Family N

Code 5100152101000

Speed Fixed speed

Max Flow Rate 141,00 m³/h

H max 45,10 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 30,40 m

kW 15,00 kW

Power consumption

Efficiency ---

Model BN 65-200B/B

Family N

Code 5100154100000

Speed Fixed speed

Max Flow Rate 141,00 m³/h

H max 50,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 37,50 m

kW 18,50 kW

Power consumption

Efficiency ---

Model BN 65-200B-60/B

Family N

Code 5100154101000

Speed Fixed speed

Max Flow Rate 141,00 m³/h

H max 52,80 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 38,70 m

kW 18,50 kW

Power consumption

Efficiency ---

Model BN4 65-200B/B

Family N

Code 5100156100000

Speed Fixed speed

Max Flow Rate 96,00 m³/h

H max 11,70 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 21,00 m³/h

Min head 3,30 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN4 65-200B-60/B

Family N

Code 5100156101000

Speed Fixed speed

Max Flow Rate 96,00 m³/h

H max 12,20 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 21,00 m³/h

Min head 3,20 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN 65-200A/B

Family N

Code 5100158100000

Speed Fixed speed

Max Flow Rate 141,00 m³/h

H max 57,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 45,50 m

kW 22,00 kW

Power consumption

Efficiency ---

Model BN 65-200A-60/B

Family N

Code 5100158101000

Speed Fixed speed

Max Flow Rate 141,00 m³/h

H max 58,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 45,50 m

kW 22,00 kW

Power consumption

Efficiency ---

Model BN4 65-200A/B

Family N

Code 5100160100000

Speed Fixed speed

Max Flow Rate 96,00 m³/h

H max 14,20 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 21,00 m³/h

Min head 7,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model BN4 65-200A-60/B

Family N

Code 5100160101000

Speed Fixed speed

Max Flow Rate 96,00 m³/h

H max 14,60 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 21,00 m³/h

Min head 6,80 m

kW 3,00 kW

Power consumption

Efficiency ---

Model BN 65-250C/B

Family N

Code 5100162100000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 61,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 43,00 m

kW 22,00 kW

Power consumption

Efficiency ---

Model BN 65-250C-60/B

Family N

Code 5100162101000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 63,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 43,00 m

kW 22,00 kW

Power consumption

Efficiency ---

Model BN 65-250B/B

Family N

Code 5100164100000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 73,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 59,00 m

kW 30,00 kW

Power consumption

Efficiency ---

Model BN 65-250B-60/B

Family N

Code 5100164101000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 74,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 60,50 m

kW 30,00 kW

Power consumption

Efficiency ---

Model BN4 65-250B/B

Family N

Code 5100166100000

Speed Fixed speed

Max Flow Rate 96,00 m³/h

H max 17,90 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 21,00 m³/h

Min head 7,00 m

kW 4,00 kW

Power consumption

Efficiency ---

Model BN4 65-250B-60/B

Family N

Code 5100166101000

Speed Fixed speed

Max Flow Rate 96,00 m³/h

H max 19,60 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 21,00 m³/h

Min head 7,10 m

kW 4,00 kW

Power consumption

Efficiency ---

Model BN 65-250A/B

Family N

Code 5100168100000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 86,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 74,50 m

kW 37,00 kW

Power consumption

Efficiency ---

Model BN 65-250A-60/B

Family N

Code 5100168101000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 87,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 74,50 m

kW 37,00 kW

Power consumption

Efficiency ---

Model BN4 65-250A/B

Family N

Code 5100170100000

Speed Fixed speed

Max Flow Rate 96,00 m³/h

H max 22,20 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 21,00 m³/h

Min head 12,60 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN4 65-250A-60/B

Family N

Code 5100170101000

Speed Fixed speed

Max Flow Rate 96,00 m³/h

H max 23,80 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 21,00 m³/h

Min head 13,70 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN4 65-315C/A

Family N

Code 5100172000000

Speed Fixed speed

Max Flow Rate 84,00 m³/h

H max 25,80 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 21,00 m³/h

Min head 11,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN4 65-315C-60/A

Family N

Code 5100172001000

Speed Fixed speed

Max Flow Rate 84,00 m³/h

H max 27,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 21,00 m³/h

Min head 13,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN4 65-315B/A

Family N

Code 5100174000000

Speed Fixed speed

Max Flow Rate 84,00 m³/h

H max 31,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 21,00 m³/h

Min head 18,60 m

kW 7,50 kW

Power consumption

Efficiency ---

Model BN4 65-315B-60/A

Family N

Code 5100174001000

Speed Fixed speed

Max Flow Rate 84,00 m³/h

H max 32,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 21,00 m³/h

Min head 20,50 m

kW 7,50 kW

Power consumption

Efficiency ---

Model BN4 65-315A/A

Family N

Code 5100176000000

Speed Fixed speed

Max Flow Rate 84,00 m³/h

H max 35,90 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 21,00 m³/h

Min head 25,00 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN4 65-315A-60/A

Family N

Code 5100176001000

Speed Fixed speed

Max Flow Rate 84,00 m³/h

H max 36,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 21,00 m³/h

Min head 26,50 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN 80-160E/B

Family N

Code 5100178100000

Speed Fixed speed

Max Flow Rate 168,00 m³/h

H max 21,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 75,00 m³/h

Min head 10,60 m

kW 7,50 kW

Power consumption

Efficiency ---

Model BN 80-160E-60/B

Family N

Code 5100178101000

Speed Fixed speed

Max Flow Rate 168,00 m³/h

H max 23,30 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 75,00 m³/h

Min head 11,90 m

kW 7,50 kW

Power consumption

Efficiency ---

Model BN 80-160D/B

Family N

Code 5100180100000

Speed Fixed speed

Max Flow Rate 168,00 m³/h

H max 25,20 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 75,00 m³/h

Min head 14,40 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN 80-160D-60/B

Family N

Code 5100180101000

Speed Fixed speed

Max Flow Rate 168,00 m³/h

H max 26,90 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 75,00 m³/h

Min head 15,10 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN 80-160C/B

Family N

Code 5100182100000

Speed Fixed speed

Max Flow Rate 180,00 m³/h

H max 28,70 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 75,00 m³/h

Min head 16,40 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN 80-160C-60/B

Family N

Code 5100182101000

Speed Fixed speed

Max Flow Rate 180,00 m³/h

H max 30,70 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 75,00 m³/h

Min head 17,90 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN4 80-160C/B

Family N

Code 5100184100000

Speed Fixed speed

Max Flow Rate 84,00 m³/h

H max 6,10 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 3,30 m

kW 1,10 kW

Power consumption

Efficiency ---

Model BN4 80-160C-60/B

Family N

Code 5100184101000

Speed Fixed speed

Max Flow Rate 84,00 m³/h

H max 6,90 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 3,70 m

kW 1,10 kW

Power consumption

Efficiency ---

Model BN 80-160B/B

Family N

Code 5100186100000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 34,80 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 75,00 m³/h

Min head 22,40 m

kW 15,00 kW

Power consumption

Efficiency ---

Model BN 80-160B-60/B

Family N

Code 5100186101000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 35,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 75,00 m³/h

Min head 21,00 m

kW 15,00 kW

Power consumption

Efficiency ---

Model BN4 80-160B/B

Family N

Code 5100188100000

Speed Fixed speed

Max Flow Rate 96,00 m³/h

H max 7,80 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 4,10 m

kW 1,50 kW

Power consumption

Efficiency ---

Model BN4 80-160B-60/B

Family N

Code 5100188101000

Speed Fixed speed

Max Flow Rate 96,00 m³/h

H max 8,60 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 4,50 m

kW 1,50 kW

Power consumption

Efficiency ---

Model BN 80-160A/B

Family N

Code 5100190100000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 39,90 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 75,00 m³/h

Min head 28,10 m

kW 18,50 kW

Power consumption

Efficiency ---

Model BN 80-160A-60/B

Family N

Code 5100190101000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 41,30 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 75,00 m³/h

Min head 28,80 m

kW 18,50 kW

Power consumption

Efficiency ---

Model BN4 80-160A/B

Family N

Code 5100192100000

Speed Fixed speed

Max Flow Rate 108,00 m³/h

H max 10,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 5,90 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN4 80-160A-60/B

Family N

Code 5100192101000

Speed Fixed speed

Max Flow Rate 108,00 m³/h

H max 11,30 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 6,60 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN4 80-200C/B

Family N

Code 5100194100000

Speed Fixed speed

Max Flow Rate 120,00 m³/h

H max 9,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 2,70 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN4 80-200C-60/B

Family N

Code 5100194101000

Speed Fixed speed

Max Flow Rate 108,00 m³/h

H max 9,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 4,50 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN 80-200B/B

Family N

Code 5100196100000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 44,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 75,00 m³/h

Min head 32,40 m

kW 22,00 kW

Power consumption

Efficiency ---

Model BN 80-200B-60/B

Family N

Code 5100196101000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 43,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 75,00 m³/h

Min head 32,20 m

kW 22,00 kW

Power consumption

Efficiency ---

Model BN4 80-200B/B

Family N

Code 5100198100000

Speed Fixed speed

Max Flow Rate 120,00 m³/h

H max 11,70 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 4,10 m

kW 3,00 kW

Power consumption

Efficiency ---

Model BN4 80-200B-60/B

Family N

Code 5100198101000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 12,20 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 4,50 m

kW 3,00 kW

Power consumption

Efficiency ---

Model BN 80-200A/B

Family N

Code 5100200100000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 56,60 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 75,00 m³/h

Min head 45,60 m

kW 30,00 kW

Power consumption

Efficiency ---

Model BN 80-200A-60/B

Family N

Code 5100200101000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 58,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 75,00 m³/h

Min head 47,80 m

kW 30,00 kW

Power consumption

Efficiency ---

Model BN4 80-200A/B

Family N

Code 5100202100000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 14,20 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 6,90 m

kW 4,00 kW

Power consumption

Efficiency ---

Model BN4 80-200A-60/B

Family N

Code 5100202101000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 14,80 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 7,70 m

kW 4,00 kW

Power consumption

Efficiency ---

Model BN 80-250E/A

Family N

Code 5100204000000

Speed Fixed speed

Max Flow Rate 180,00 m³/h

H max 51,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 75,00 m³/h

Min head 29,00 m

kW 22,00 kW

Power consumption

Efficiency ---

Model BN 80-250E-60/A

Family N

Code 5100204001000

Speed Fixed speed

Max Flow Rate 180,00 m³/h

H max 51,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 75,00 m³/h

Min head 29,00 m

kW 22,00 kW

Power consumption

Efficiency ---

Model BN 80-250D/A

Family N

Code 5100206000000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 65,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 75,00 m³/h

Min head 41,00 m

kW 30,00 kW

Power consumption

Efficiency ---

Model BN 80-250D-60/A

Family N

Code 5100206001000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 65,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 75,00 m³/h

Min head 41,00 m

kW 30,00 kW

Power consumption

Efficiency ---

Model BN 80-250C/A

Family N

Code 5100208000000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 73,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 75,00 m³/h

Min head 51,50 m

kW 37,00 kW

Power consumption

Efficiency ---

Model BN 80-250C-60/A

Family N

Code 5100208001000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 73,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 75,00 m³/h

Min head 51,00 m

kW 37,00 kW

Power consumption

Efficiency ---

Model BN4 80-250C/A

Family N

Code 5100210000000

Speed Fixed speed

Max Flow Rate 120,00 m³/h

H max 16,90 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 7,20 m

kW 4,00 kW

Power consumption

Efficiency ---

Model BN4 80-250C-60/A

Family N

Code 5100210001000

Speed Fixed speed

Max Flow Rate 108,00 m³/h

H max 17,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 9,50 m

kW 4,00 kW

Power consumption

Efficiency ---

Model BN 80-250B/A

Family N

Code 5100212000000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 84,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 75,00 m³/h

Min head 63,00 m

kW 45,00 kW

Power consumption

Efficiency ---

Model BN 80-250B-60/A

Family N

Code 5100212001000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 84,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 75,00 m³/h

Min head 62,50 m

kW 45,00 kW

Power consumption

Efficiency ---

Model BN4 80-250B/A

Family N

Code 5100214000000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 20,70 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 9,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN4 80-250B-60/A

Family N

Code 5100214001000

Speed Fixed speed

Max Flow Rate 120,00 m³/h

H max 20,80 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 11,50 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN 80-250A/A

Family N

Code 5100216000000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 95,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 75,00 m³/h

Min head 76,50 m

kW 55,00 kW

Power consumption

Efficiency ---

Model BN 80-250A-60/A

Family N

Code 5100216001000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 94,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 75,00 m³/h

Min head 76,50 m

kW 55,00 kW

Power consumption

Efficiency ---

Model BN4 80-250A/A

Family N

Code 5100218000000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 23,70 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 12,70 m

kW 7,50 kW

Power consumption

Efficiency ---

Model BN4 80-250A-60/A

Family N

Code 5100218001000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 24,20 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 12,70 m

kW 7,50 kW

Power consumption

Efficiency ---

Model BN4 80-315C/B

Family N

Code 5100220100000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 25,70 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 15,90 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN4 80-315C-60/B

Family N

Code 5100220101000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 26,20 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 16,20 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN4 80-315B/B

Family N

Code 5100222100000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 30,30 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 22,00 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN4 80-315B-60/B

Family N

Code 5100222101000

Speed Fixed speed

Max Flow Rate 150,00 m³/h

H max 31,10 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 17,50 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN4 80-315A/B

Family N

Code 5100224100000

Speed Fixed speed

Max Flow Rate 150,00 m³/h

H max 36,30 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 25,30 m

kW 15,00 kW

Power consumption

Efficiency ---

Model BN4 80-315A-60/B

Family N

Code 5100224101000

Speed Fixed speed

Max Flow Rate 168,00 m³/h

H max 36,90 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 20,60 m

kW 15,00 kW

Power consumption

Efficiency ---

Model BN4 80-315S

Family N

Code 5100224A00000

Speed Fixed speed

Max Flow Rate 168,00 m³/h

H max 39,10 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 22,50 m

kW 18,50 kW

Power consumption

Efficiency ---

Model BN4 80-315S-60

Family N

Code 5100224A01000

Speed Fixed speed

Max Flow Rate 168,00 m³/h

H max 42,30 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 28,00 m

kW 18,50 kW

Power consumption

Efficiency ---

Model BN 100-200E/A

Family N

Code 5100232000000

Speed Fixed speed

Max Flow Rate 240,00 m³/h

H max 30,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 108,00 m³/h

Min head 19,00 m

kW 18,50 kW

Power consumption

Efficiency ---

Model BN 100-200E-60/A

Family N

Code 5100232001000

Speed Fixed speed

Max Flow Rate 240,00 m³/h

H max 30,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 108,00 m³/h

Min head 19,00 m

kW 18,50 kW

Power consumption

Efficiency ---

Model BN 100-200D/A

Family N

Code 5100234000000

Speed Fixed speed

Max Flow Rate 270,00 m³/h

H max 36,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 108,00 m³/h

Min head 19,00 m

kW 22,00 kW

Power consumption

Efficiency ---

Model BN 100-200D-60/A

Family N

Code 5100234001000

Speed Fixed speed

Max Flow Rate 240,00 m³/h

H max 36,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 108,00 m³/h

Min head 24,00 m

kW 22,00 kW

Power consumption

Efficiency ---

Model BN 100-200C/A

Family N

Code 5100236000000

Speed Fixed speed

Max Flow Rate 300,00 m³/h

H max 45,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 108,00 m³/h

Min head 22,00 m

kW 30,00 kW

Power consumption

Efficiency ---

Model BN 100-200C-60/A

Family N

Code 5100236001000

Speed Fixed speed

Max Flow Rate 270,00 m³/h

H max 45,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 108,00 m³/h

Min head 28,00 m

kW 30,00 kW

Power consumption

Efficiency ---

Model BN4 100-200C/A

Family N

Code 5100238000000

Speed Fixed speed

Max Flow Rate 150,00 m³/h

H max 9,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 4,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model BN4 100-200C-60/A

Family N

Code 5100238001000

Speed Fixed speed

Max Flow Rate 150,00 m³/h

H max 9,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 4,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model BN 100-200B/A

Family N

Code 5100240000000

Speed Fixed speed

Max Flow Rate 300,00 m³/h

H max 54,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 108,00 m³/h

Min head 32,00 m

kW 37,00 kW

Power consumption

Efficiency ---

Model BN 100-200B-60/A

Family N

Code 5100240001000

Speed Fixed speed

Max Flow Rate 270,00 m³/h

H max 54,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 108,00 m³/h

Min head 38,00 m

kW 37,00 kW

Power consumption

Efficiency ---

Model BN4 100-200B/A

Family N

Code 5100242000000

Speed Fixed speed

Max Flow Rate 168,00 m³/h

H max 12,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 4,50 m

kW 4,00 kW

Power consumption

Efficiency ---

Model BN4 100-200B-60/A

Family N

Code 5100242001000

Speed Fixed speed

Max Flow Rate 168,00 m³/h

H max 11,70 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 4,60 m

kW 4,00 kW

Power consumption

Efficiency ---

Model BN 100-200A-60/A

Family N

Code 5100244001000

Speed Fixed speed

Max Flow Rate 300,00 m³/h

H max 61,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 108,00 m³/h

Min head 42,00 m

kW 45,00 kW

Power consumption

Efficiency ---

Model BN4 100-200A/A

Family N

Code 5100246000000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 15,20 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 6,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN4 100-200A-60/A

Family N

Code 5100246001000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 14,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 5,50 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN 100-250B/A

Family N

Code 5100248000000

Speed Fixed speed

Max Flow Rate 300,00 m³/h

H max 73,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 108,00 m³/h

Min head 48,50 m

kW 55,00 kW

Power consumption

Efficiency ---

Model BN 100-250B-60/A

Family N

Code 5100248001000

Speed Fixed speed

Max Flow Rate 300,00 m³/h

H max 73,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 108,00 m³/h

Min head 48,00 m

kW 55,00 kW

Power consumption

Efficiency ---

Model BN4 100-250B/A

Family N

Code 5100250000000

Speed Fixed speed

Max Flow Rate 210,00 m³/h

H max 19,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 5,50 m

kW 7,50 kW

Power consumption

Efficiency ---

Model BN4 100-250B-60/A

Family N

Code 5100250001000

Speed Fixed speed

Max Flow Rate 210,00 m³/h

H max 19,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 5,50 m

kW 7,50 kW

Power consumption

Efficiency ---

Model BN 100-250A/A

Family N

Code 5100252000000

Speed Fixed speed

Max Flow Rate 300,00 m³/h

H max 91,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 108,00 m³/h

Min head 67,00 m

kW 75,00 kW

Power consumption

Efficiency ---

Model BN 100-250A-60/A

Family N

Code 5100252001000

Speed Fixed speed

Max Flow Rate 300,00 m³/h

H max 90,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 108,00 m³/h

Min head 67,00 m

kW 75,00 kW

Power consumption

Efficiency ---

Model BN4 100-250A/A

Family N

Code 5100254000000

Speed Fixed speed

Max Flow Rate 210,00 m³/h

H max 22,30 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 8,90 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN4 100-250A-60/A

Family N

Code 5100254001000

Speed Fixed speed

Max Flow Rate 210,00 m³/h

H max 22,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 8,80 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN4 100-315C/A

Family N

Code 5100256000000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 26,90 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 11,30 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN4 100-315C-60/A

Family N

Code 5100256001000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 28,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 10,00 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN4 100-315B/A

Family N

Code 5100258000000

Speed Fixed speed

Max Flow Rate 210,00 m³/h

H max 31,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 14,00 m

kW 15,00 kW

Power consumption

Efficiency ---

Model BN4 100-315B-60/A

Family N

Code 5100258001000

Speed Fixed speed

Max Flow Rate 210,00 m³/h

H max 32,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 13,50 m

kW 15,00 kW

Power consumption

Efficiency ---

Model BN4 100-315A/A

Family N

Code 5100260000000

Speed Fixed speed

Max Flow Rate 210,00 m³/h

H max 36,90 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 22,20 m

kW 18,50 kW

Power consumption

Efficiency ---

Model BN4 100-315A-60/A

Family N

Code 5100260001000

Speed Fixed speed

Max Flow Rate 210,00 m³/h

H max 38,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 21,00 m

kW 18,50 kW

Power consumption

Efficiency ---

Model BN4 100-400C/A

Family N

Code 5100262000000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 41,30 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 26,00 m

kW 22,00 kW

Power consumption

Efficiency ---

Model BN4 100-400C-60/A

Family N

Code 5100262001000

Speed Fixed speed

Max Flow Rate 180,00 m³/h

H max 43,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 28,00 m

kW 22,00 kW

Power consumption

Efficiency ---

Model BN4 100-400B/A

Family N

Code 5100264000000

Speed Fixed speed

Max Flow Rate 210,00 m³/h

H max 50,20 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 33,50 m

kW 30,00 kW

Power consumption

Efficiency ---

Model BN4 100-400B-60/A

Family N

Code 5100264001000

Speed Fixed speed

Max Flow Rate 210,00 m³/h

H max 51,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 33,00 m

kW 30,00 kW

Power consumption

Efficiency ---

Model BN4 100-400A/A

Family N

Code 5100266000000

Speed Fixed speed

Max Flow Rate 210,00 m³/h

H max 58,20 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 44,00 m

kW 37,00 kW

Power consumption

Efficiency ---

Model BN4 100-400A-60/A

Family N

Code 5100266001000

Speed Fixed speed

Max Flow Rate 210,00 m³/h

H max 59,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 44,00 m

kW 37,00 kW

Power consumption

Efficiency ---

Model BN4 125-250E/A

Family N

Code 5100268000000

Speed Fixed speed

Max Flow Rate 240,00 m³/h

H max 11,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 84,00 m³/h

Min head 4,40 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN4 125-250E-60/A

Family N

Code 5100268001000

Speed Fixed speed

Max Flow Rate 210,00 m³/h

H max 11,20 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 84,00 m³/h

Min head 6,20 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN4 125-250D/A

Family N

Code 5100270000000

Speed Fixed speed

Max Flow Rate 270,00 m³/h

H max 14,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 84,00 m³/h

Min head 5,10 m

kW 7,50 kW

Power consumption

Efficiency ---

Model BN4 125-250D-60/A

Family N

Code 5100270001000

Speed Fixed speed

Max Flow Rate 270,00 m³/h

H max 14,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 84,00 m³/h

Min head 5,00 m

kW 7,50 kW

Power consumption

Efficiency ---

Model BN4 125-250C/A

Family N

Code 5100272000000

Speed Fixed speed

Max Flow Rate 300,00 m³/h

H max 16,70 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 84,00 m³/h

Min head 5,80 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN4 125-250C-60/A

Family N

Code 5100272001000

Speed Fixed speed

Max Flow Rate 300,00 m³/h

H max 16,80 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 84,00 m³/h

Min head 5,40 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN4 125-250B/A

Family N

Code 5100274000000

Speed Fixed speed

Max Flow Rate 300,00 m³/h

H max 19,30 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 84,00 m³/h

Min head 8,20 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN4 125-250B-60/A

Family N

Code 5100274001000

Speed Fixed speed

Max Flow Rate 300,00 m³/h

H max 19,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 84,00 m³/h

Min head 8,00 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN4 125-250A/A

Family N

Code 5100276000000

Speed Fixed speed

Max Flow Rate 330,00 m³/h

H max 22,70 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 84,00 m³/h

Min head 9,30 m

kW 15,00 kW

Power consumption

Efficiency ---

Model BN4 125-250A-60/A

Family N

Code 5100276001000

Speed Fixed speed

Max Flow Rate 330,00 m³/h

H max 23,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 84,00 m³/h

Min head 9,00 m

kW 15,00 kW

Power consumption

Efficiency ---

Model BN4 125-315C/A

Family N

Code 5100278000000

Speed Fixed speed

Max Flow Rate 330,00 m³/h

H max 27,90 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 84,00 m³/h

Min head 9,50 m

kW 18,50 kW

Power consumption

Efficiency ---

Model BN4 125-315C-60/A

Family N

Code 5100278001000

Speed Fixed speed

Max Flow Rate 300,00 m³/h

H max 28,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 84,00 m³/h

Min head 13,00 m

kW 18,50 kW

Power consumption

Efficiency ---

Model BN4 125-315B/A

Family N

Code 5100280000000

Speed Fixed speed

Max Flow Rate 330,00 m³/h

H max 31,80 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 84,00 m³/h

Min head 14,30 m

kW 22,00 kW

Power consumption

Efficiency ---

Model BN4 125-315B-60/A

Family N

Code 5100280001000

Speed Fixed speed

Max Flow Rate 330,00 m³/h

H max 32,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 84,00 m³/h

Min head 14,50 m

kW 22,00 kW

Power consumption

Efficiency ---

Model BN4 125-315A/A

Family N

Code 5100282000000

Speed Fixed speed

Max Flow Rate 330,00 m³/h

H max 36,80 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 84,00 m³/h

Min head 21,60 m

kW 30,00 kW

Power consumption

Efficiency ---

Model BN4 125-315A-60/A

Family N

Code 5100282001000

Speed Fixed speed

Max Flow Rate 330,00 m³/h

H max 37,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 84,00 m³/h

Min head 21,50 m

kW 30,00 kW

Power consumption

Efficiency ---

Model BN4 125-400C/A

Family N

Code 5100284000000

Speed Fixed speed

Max Flow Rate 330,00 m³/h

H max 45,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 84,00 m³/h

Min head 23,50 m

kW 37,00 kW

Power consumption

Efficiency ---

Model BN4 125-400C-60/A

Family N

Code 5100284001000

Speed Fixed speed

Max Flow Rate 300,00 m³/h

H max 45,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 84,00 m³/h

Min head 28,00 m

kW 37,00 kW

Power consumption

Efficiency ---

Model BN4 125-400B/A

Family N

Code 5100286000000

Speed Fixed speed

Max Flow Rate 330,00 m³/h

H max 51,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 84,00 m³/h

Min head 31,50 m

kW 45,00 kW

Power consumption

Efficiency ---

Model BN4 125-400B-60/A

Family N

Code 5100286001000

Speed Fixed speed

Max Flow Rate 330,00 m³/h

H max 51,70 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 84,00 m³/h

Min head 31,00 m

kW 45,00 kW

Power consumption

Efficiency ---

Model BN4 125-400A/A

Family N

Code 5100288000000

Speed Fixed speed

Max Flow Rate 330,00 m³/h

H max 59,20 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 84,00 m³/h

Min head 42,50 m

kW 55,00 kW

Power consumption

Efficiency ---

Model BN4 125-400A-60/A

Family N

Code 5100288001000

Speed Fixed speed

Max Flow Rate 330,00 m³/h

H max 59,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 84,00 m³/h

Min head 41,50 m

kW 55,00 kW

Power consumption

Efficiency ---

Model BN4 150-315D/B

Family N

Code 5100290000000

Speed Fixed speed

Max Flow Rate 450,00 m³/h

H max 23,10 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 132,00 m³/h

Min head 10,20 m

kW 18,50 kW

Power consumption

Efficiency ---

Model BN4 150-315D-60/B

Family N

Code 5100290001000

Speed Fixed speed

Max Flow Rate 450,00 m³/h

H max 23,30 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 132,00 m³/h

Min head 10,90 m

kW 18,50 kW

Power consumption

Efficiency ---

Model BN4 150-315C/B

Family N

Code 5100292000000

Speed Fixed speed

Max Flow Rate 480,00 m³/h

H max 26,70 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 132,00 m³/h

Min head 10,80 m

kW 22,00 kW

Power consumption

Efficiency ---

Model BN4 150-315C-60/B

Family N

Code 5100292001000

Speed Fixed speed

Max Flow Rate 480,00 m³/h

H max 26,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 132,00 m³/h

Min head 12,20 m

kW 22,00 kW

Power consumption

Efficiency ---

Model BN4 150-315B/B

Family N

Code 5100294100000

Speed Fixed speed

Max Flow Rate 540,00 m³/h

H max 25,30 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 132,00 m³/h

Min head 15,10 m

kW 30,00 kW

Power consumption

Efficiency ---

Model BN4 150-315B-60/B

Family N

Code 5100294101000

Speed Fixed speed

Max Flow Rate 480,00 m³/h

H max 26,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 132,00 m³/h

Min head 17,40 m

kW 30,00 kW

Power consumption

Efficiency ---

Model BN4 150-315A/B

Family N

Code 5100296100000

Speed Fixed speed

Max Flow Rate 600,00 m³/h

H max 29,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 132,00 m³/h

Min head 16,70 m

kW 37,00 kW

Power consumption

Efficiency ---

Model BN4 150-315A-60/B

Family N

Code 5100296101000

Speed Fixed speed

Max Flow Rate 600,00 m³/h

H max 30,90 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 132,00 m³/h

Min head 17,80 m

kW 37,00 kW

Power consumption

Efficiency ---

Model BN4 150-315S

Family N

Code 5100296A00000

Speed Fixed speed

Max Flow Rate 660,00 m³/h

H max 34,90 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 132,00 m³/h

Min head 18,70 m

kW 45,00 kW

Power consumption

Efficiency ---

Model BN4 150-315S-60

Family N

Code 5100296A01000

Speed Fixed speed

Max Flow Rate 660,00 m³/h

H max 35,60 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 132,00 m³/h

Min head 19,80 m

kW 45,00 kW

Power consumption

Efficiency ---

Model BN4 150-400B/B

Family N

Code 5100300100000

Speed Fixed speed

Max Flow Rate 600,00 m³/h

H max 42,20 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 132,00 m³/h

Min head 25,40 m

kW 55,00 kW

Power consumption

Efficiency ---

Model BN4 150-400B-60/B

Family N

Code 5100300101000

Speed Fixed speed

Max Flow Rate 600,00 m³/h

H max 42,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 132,00 m³/h

Min head 27,10 m

kW 55,00 kW

Power consumption

Efficiency ---

Model BN4 150-400A/B

Family N

Code 5100302100000

Speed Fixed speed

Max Flow Rate 660,00 m³/h

H max 52,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 132,00 m³/h

Min head 32,20 m

kW 75,00 kW

Power consumption

Efficiency ---

Model BN4 150-400A-60/B

Family N

Code 5100302101000

Speed Fixed speed

Max Flow Rate 660,00 m³/h

H max 51,90 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 132,00 m³/h

Min head 32,70 m

kW 75,00 kW

Power consumption

Efficiency ---

Model BN4 150-400S

Family N

Code 5100302A00000

Speed Fixed speed

Max Flow Rate 660,00 m³/h

H max 60,80 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 132,00 m³/h

Min head 37,60 m

kW 90,00 kW

Power consumption

Efficiency ---

Model BN4 150-400S-60

Family N

Code 5100302A01000

Speed Fixed speed

Max Flow Rate 660,00 m³/h

H max 60,60 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 132,00 m³/h

Min head 42,50 m

kW 90,00 kW

Power consumption

Efficiency ---

Model BN 32L-160C

Family N

Code 5100303000000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 25,10 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 9,60 m³/h

Min head 13,40 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN 32L-160C-60

Family N

Code 5100303001000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 26,10 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 9,60 m³/h

Min head 13,70 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN 32L-160B

Family N

Code 5100305000000

Speed Fixed speed

Max Flow Rate 29,00 m³/h

H max 30,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 9,60 m³/h

Min head 17,90 m

kW 3,00 kW

Power consumption

Efficiency ---

Model BN 32L-160B-60

Family N

Code 5100305001000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 30,30 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 9,60 m³/h

Min head 20,10 m

kW 3,00 kW

Power consumption

Efficiency ---

Model BN 32L-160A

Family N

Code 5100307000000

Speed Fixed speed

Max Flow Rate 32,00 m³/h

H max 39,90 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 9,60 m³/h

Min head 25,60 m

kW 4,00 kW

Power consumption

Efficiency ---

Model BN 32L-160A-60

Family N

Code 5100307001000

Speed Fixed speed

Max Flow Rate 32,00 m³/h

H max 38,70 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 9,60 m³/h

Min head 23,90 m

kW 4,00 kW

Power consumption

Efficiency ---

Model BN 32L-200C

Family N

Code 5100309000000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 42,10 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 9,60 m³/h

Min head 23,80 m

kW 4,00 kW

Power consumption

Efficiency ---

Model BN 32L-200C-60

Family N

Code 5100309001000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 46,10 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 9,60 m³/h

Min head 25,60 m

kW 4,00 kW

Power consumption

Efficiency ---

Model BN 32L-200B

Family N

Code 5100310000000

Speed Fixed speed

Max Flow Rate 29,00 m³/h

H max 51,70 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 9,60 m³/h

Min head 33,50 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN 32L-200B-60

Family N

Code 5100310001000

Speed Fixed speed

Max Flow Rate 29,00 m³/h

H max 52,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 9,60 m³/h

Min head 30,60 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN 32L-200A

Family N

Code 5100312000000

Speed Fixed speed

Max Flow Rate 32,00 m³/h

H max 59,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 9,60 m³/h

Min head 37,70 m

kW 7,50 kW

Power consumption

Efficiency ---

Model BN 32L-200A-60

Family N

Code 5100312001000

Speed Fixed speed

Max Flow Rate 32,00 m³/h

H max 60,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 9,60 m³/h

Min head 35,30 m

kW 7,50 kW

Power consumption

Efficiency ---

Model BN4 80-400C/B

Family N

Code 5100226100000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 42,80 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 29,10 m

kW 18,50 kW

Power consumption

Efficiency ---

Model BN4 80-400C-60/B

Family N

Code 5100226101000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 47,20 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 31,30 m

kW 18,50 kW

Power consumption

Efficiency ---

Model BN4 80-400B/B

Family N

Code 5100228100000

Speed Fixed speed

Max Flow Rate 150,00 m³/h

H max 48,20 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 30,50 m

kW 22,00 kW

Power consumption

Efficiency ---

Model BN4 80-400B-60/B

Family N

Code 5100228101000

Speed Fixed speed

Max Flow Rate 150,00 m³/h

H max 52,10 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 31,00 m

kW 22,00 kW

Power consumption

Efficiency ---

Model BN4 80-400A/B

Family N

Code 5100230100000

Speed Fixed speed

Max Flow Rate 150,00 m³/h

H max 61,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 49,50 m

kW 30,00 kW

Power consumption

Efficiency ---

Model BN4 80-400A-60/B

Family N

Code 5100230101000

Speed Fixed speed

Max Flow Rate 150,00 m³/h

H max 64,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 48,10 m

kW 30,00 kW

Power consumption

Efficiency ---

Model BN4 80-400S

Family N

Code 5100230A00000

Speed Fixed speed

Max Flow Rate 180,00 m³/h

H max 61,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 39,20 m

kW 37,00 kW

Power consumption

Efficiency ---

Model BN4 80-400S-60

Family N

Code 5100230A01000

Speed Fixed speed

Max Flow Rate 180,00 m³/h

H max 64,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 36,80 m

kW 37,00 kW

Power consumption

Efficiency ---

Model BN 100-200A/A

Family N

Code 5100244000000

Speed Fixed speed

Max Flow Rate 300,00 m³/h

H max 61,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 108,00 m³/h

Min head 42,00 m

kW 45,00 kW

Power consumption

Efficiency ---

Model N 80-250D/A G

Family N

Code 5000206004000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 65,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 75,00 m³/h

Min head 41,00 m

kW 30,00 kW

Power consumption

Efficiency ---

Model N 80-250B/A G

Family N

Code 5000212004000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 84,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 75,00 m³/h

Min head 63,00 m

kW 45,00 kW

Power consumption

Efficiency ---

Model BN 50-200S/A G

Family N

Code 5100108A04000

Speed Fixed speed

Max Flow Rate 78,00 m³/h

H max 60,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 24,00 m³/h

Min head 37,00 m

kW 15,00 kW

Power consumption

Efficiency ---

Model N4 125-250C/A G

Family N

Code 5000272004000

Speed Fixed speed

Max Flow Rate 300,00 m³/h

H max 16,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 84,00 m³/h

Min head 5,80 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N4 80-200B/B G

Family N

Code 5000198104000

Speed Fixed speed

Max Flow Rate 120,00 m³/h

H max 11,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 4,10 m

kW 3,00 kW

Power consumption

Efficiency ---

Model BN 32L-200A-60 G

Family N

Code 5100312005000

Speed Fixed speed

Max Flow Rate 32,00 m³/h

H max 60,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 9,60 m³/h

Min head 35,30 m

kW 7,50 kW

Power consumption

Efficiency ---

Model BN 32L-200A G

Family N

Code 5100312004000

Speed Fixed speed

Max Flow Rate 32,00 m³/h

H max 59,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 9,60 m³/h

Min head 37,70 m

kW 7,50 kW

Power consumption

Efficiency ---

Model BN 32L-200B-60 G

Family N

Code 5100310005000

Speed Fixed speed

Max Flow Rate 29,00 m³/h

H max 52,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 9,60 m³/h

Min head 30,60 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN 32L-200B G

Family N

Code 5100310004000

Speed Fixed speed

Max Flow Rate 29,00 m³/h

H max 51,70 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 9,60 m³/h

Min head 33,50 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN 32L-200C-60 G

Family N

Code 5100309005000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 46,10 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 9,60 m³/h

Min head 25,60 m

kW 4,00 kW

Power consumption

Efficiency ---

Model BN 32L-200C G

Family N

Code 5100309004000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 42,10 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 9,60 m³/h

Min head 23,80 m

kW 4,00 kW

Power consumption

Efficiency ---

Model BN 32L-160A-60 G

Family N

Code 5100307005000

Speed Fixed speed

Max Flow Rate 32,00 m³/h

H max 38,70 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 9,60 m³/h

Min head 23,90 m

kW 4,00 kW

Power consumption

Efficiency ---

Model BN 32L-160A G

Family N

Code 5100307004000

Speed Fixed speed

Max Flow Rate 32,00 m³/h

H max 39,90 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 9,60 m³/h

Min head 25,60 m

kW 4,00 kW

Power consumption

Efficiency ---

Model BN 32L-160B-60 G

Family N

Code 5100305005000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 30,30 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 9,60 m³/h

Min head 20,10 m

kW 3,00 kW

Power consumption

Efficiency ---

Model BN 32L-160B G

Family N

Code 5100305004000

Speed Fixed speed

Max Flow Rate 29,00 m³/h

H max 30,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 9,60 m³/h

Min head 17,90 m

kW 3,00 kW

Power consumption

Efficiency ---

Model BN 32L-160C-60 G

Family N

Code 5100303005000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 26,10 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 9,60 m³/h

Min head 13,70 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN 32L-160C G

Family N

Code 5100303004000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 25,10 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 9,60 m³/h

Min head 13,40 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN4 150-400S-60 G

Family N

Code 5100302A05000

Speed Fixed speed

Max Flow Rate 660,00 m³/h

H max 60,60 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 132,00 m³/h

Min head 42,50 m

kW 90,00 kW

Power consumption

Efficiency ---

Model BN4 150-400S G

Family N

Code 5100302A04000

Speed Fixed speed

Max Flow Rate 660,00 m³/h

H max 60,80 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 132,00 m³/h

Min head 37,60 m

kW 90,00 kW

Power consumption

Efficiency ---

Model BN4 150-400A-60/B G

Family N

Code 5100302105000

Speed Fixed speed

Max Flow Rate 660,00 m³/h

H max 51,90 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 132,00 m³/h

Min head 32,70 m

kW 75,00 kW

Power consumption

Efficiency ---

Model BN4 150-400A/B G

Family N

Code 5100302104000

Speed Fixed speed

Max Flow Rate 660,00 m³/h

H max 52,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 132,00 m³/h

Min head 32,20 m

kW 75,00 kW

Power consumption

Efficiency ---

Model BN4 150-400B-60/B G

Family N

Code 5100300105000

Speed Fixed speed

Max Flow Rate 600,00 m³/h

H max 42,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 132,00 m³/h

Min head 27,10 m

kW 55,00 kW

Power consumption

Efficiency ---

Model BN4 150-400B/B G

Family N

Code 5100300104000

Speed Fixed speed

Max Flow Rate 600,00 m³/h

H max 42,20 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 132,00 m³/h

Min head 25,40 m

kW 55,00 kW

Power consumption

Efficiency ---

Model BN4 150-315S-60 G

Family N

Code 5100296A05000

Speed Fixed speed

Max Flow Rate 660,00 m³/h

H max 35,60 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 132,00 m³/h

Min head 19,80 m

kW 45,00 kW

Power consumption

Efficiency ---

Model BN4 150-315S G

Family N

Code 5100296A04000

Speed Fixed speed

Max Flow Rate 660,00 m³/h

H max 34,90 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 132,00 m³/h

Min head 18,70 m

kW 45,00 kW

Power consumption

Efficiency ---

Model BN4 150-315A-60/B G

Family N

Code 5100296105000

Speed Fixed speed

Max Flow Rate 600,00 m³/h

H max 30,90 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 132,00 m³/h

Min head 17,80 m

kW 37,00 kW

Power consumption

Efficiency ---

Model BN4 150-315A/B G

Family N

Code 5100296104000

Speed Fixed speed

Max Flow Rate 600,00 m³/h

H max 29,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 132,00 m³/h

Min head 16,70 m

kW 37,00 kW

Power consumption

Efficiency ---

Model BN4 150-315B-60/B G

Family N

Code 5100294105000

Speed Fixed speed

Max Flow Rate 480,00 m³/h

H max 26,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 132,00 m³/h

Min head 17,40 m

kW 30,00 kW

Power consumption

Efficiency ---

Model BN4 150-315B/B G

Family N

Code 5100294104000

Speed Fixed speed

Max Flow Rate 540,00 m³/h

H max 25,30 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 132,00 m³/h

Min head 15,10 m

kW 30,00 kW

Power consumption

Efficiency ---

Model BN4 150-315C-60/B G

Family N

Code 5100292005000

Speed Fixed speed

Max Flow Rate 480,00 m³/h

H max 26,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 132,00 m³/h

Min head 12,20 m

kW 22,00 kW

Power consumption

Efficiency ---

Model BN4 150-315C/B G

Family N

Code 5100292004000

Speed Fixed speed

Max Flow Rate 480,00 m³/h

H max 26,70 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 132,00 m³/h

Min head 10,80 m

kW 22,00 kW

Power consumption

Efficiency ---

Model BN4 150-315D-60/B G

Family N

Code 5100290005000

Speed Fixed speed

Max Flow Rate 450,00 m³/h

H max 23,30 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 132,00 m³/h

Min head 10,90 m

kW 18,50 kW

Power consumption

Efficiency ---

Model BN4 150-315D/B G

Family N

Code 5100290004000

Speed Fixed speed

Max Flow Rate 450,00 m³/h

H max 23,10 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 132,00 m³/h

Min head 10,20 m

kW 18,50 kW

Power consumption

Efficiency ---

Model BN4 125-400A-60/A G

Family N

Code 5100288005000

Speed Fixed speed

Max Flow Rate 330,00 m³/h

H max 59,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 84,00 m³/h

Min head 41,50 m

kW 55,00 kW

Power consumption

Efficiency ---

Model BN4 125-400A/A G

Family N

Code 5100288004000

Speed Fixed speed

Max Flow Rate 330,00 m³/h

H max 59,20 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 84,00 m³/h

Min head 42,50 m

kW 55,00 kW

Power consumption

Efficiency ---

Model BN4 125-400B-60/A G

Family N

Code 5100286005000

Speed Fixed speed

Max Flow Rate 330,00 m³/h

H max 51,70 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 84,00 m³/h

Min head 31,00 m

kW 45,00 kW

Power consumption

Efficiency ---

Model BN4 125-400B/A G

Family N

Code 5100286004000

Speed Fixed speed

Max Flow Rate 330,00 m³/h

H max 51,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 84,00 m³/h

Min head 31,50 m

kW 45,00 kW

Power consumption

Efficiency ---

Model BN4 125-400C-60/A G

Family N

Code 5100284005000

Speed Fixed speed

Max Flow Rate 300,00 m³/h

H max 45,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 84,00 m³/h

Min head 28,00 m

kW 37,00 kW

Power consumption

Efficiency ---

Model BN4 125-400C/A G

Family N

Code 5100284004000

Speed Fixed speed

Max Flow Rate 330,00 m³/h

H max 45,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 84,00 m³/h

Min head 23,50 m

kW 37,00 kW

Power consumption

Efficiency ---

Model BN4 125-315A-60/A G

Family N

Code 5100282005000

Speed Fixed speed

Max Flow Rate 330,00 m³/h

H max 37,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 84,00 m³/h

Min head 21,50 m

kW 30,00 kW

Power consumption

Efficiency ---

Model BN4 125-315A/A G

Family N

Code 5100282004000

Speed Fixed speed

Max Flow Rate 330,00 m³/h

H max 36,80 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 84,00 m³/h

Min head 21,60 m

kW 30,00 kW

Power consumption

Efficiency ---

Model BN4 125-315B-60/A G

Family N

Code 5100280005000

Speed Fixed speed

Max Flow Rate 330,00 m³/h

H max 32,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 84,00 m³/h

Min head 14,50 m

kW 22,00 kW

Power consumption

Efficiency ---

Model BN4 125-315B/A G

Family N

Code 5100280004000

Speed Fixed speed

Max Flow Rate 330,00 m³/h

H max 31,80 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 84,00 m³/h

Min head 14,30 m

kW 22,00 kW

Power consumption

Efficiency ---

Model BN4 125-315C-60/A G

Family N

Code 5100278005000

Speed Fixed speed

Max Flow Rate 300,00 m³/h

H max 28,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 84,00 m³/h

Min head 13,00 m

kW 18,50 kW

Power consumption

Efficiency ---

Model BN4 125-315C/A G

Family N

Code 5100278004000

Speed Fixed speed

Max Flow Rate 330,00 m³/h

H max 27,90 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 84,00 m³/h

Min head 9,50 m

kW 18,50 kW

Power consumption

Efficiency ---

Model BN4 125-250A-60/A G

Family N

Code 5100276005000

Speed Fixed speed

Max Flow Rate 330,00 m³/h

H max 23,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 84,00 m³/h

Min head 9,00 m

kW 15,00 kW

Power consumption

Efficiency ---

Model BN4 125-250A/A G

Family N

Code 5100276004000

Speed Fixed speed

Max Flow Rate 330,00 m³/h

H max 22,70 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 84,00 m³/h

Min head 9,30 m

kW 15,00 kW

Power consumption

Efficiency ---

Model BN4 125-250B-60/A G

Family N

Code 5100274005000

Speed Fixed speed

Max Flow Rate 300,00 m³/h

H max 19,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 84,00 m³/h

Min head 8,00 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN4 125-250B/A G

Family N

Code 5100274004000

Speed Fixed speed

Max Flow Rate 300,00 m³/h

H max 19,30 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 84,00 m³/h

Min head 8,20 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN4 125-250C-60/A G

Family N

Code 5100272005000

Speed Fixed speed

Max Flow Rate 300,00 m³/h

H max 16,80 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 84,00 m³/h

Min head 5,40 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN4 125-250C/A G

Family N

Code 5100272004000

Speed Fixed speed

Max Flow Rate 300,00 m³/h

H max 16,70 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 84,00 m³/h

Min head 5,80 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN4 125-250D-60/A G

Family N

Code 5100270005000

Speed Fixed speed

Max Flow Rate 270,00 m³/h

H max 14,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 84,00 m³/h

Min head 5,00 m

kW 7,50 kW

Power consumption

Efficiency ---

Model BN4 125-250D/A G

Family N

Code 5100270004000

Speed Fixed speed

Max Flow Rate 270,00 m³/h

H max 14,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 84,00 m³/h

Min head 5,10 m

kW 7,50 kW

Power consumption

Efficiency ---

Model BN4 125-250E-60/A G

Family N

Code 5100268005000

Speed Fixed speed

Max Flow Rate 210,00 m³/h

H max 11,20 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 84,00 m³/h

Min head 6,20 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN4 125-250E/A G

Family N

Code 5100268004000

Speed Fixed speed

Max Flow Rate 240,00 m³/h

H max 11,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 84,00 m³/h

Min head 4,40 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN4 100-400A-60/A G

Family N

Code 5100266005000

Speed Fixed speed

Max Flow Rate 210,00 m³/h

H max 59,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 44,00 m

kW 37,00 kW

Power consumption

Efficiency ---

Model BN4 100-400A/A G

Family N

Code 5100266004000

Speed Fixed speed

Max Flow Rate 210,00 m³/h

H max 58,20 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 44,00 m

kW 37,00 kW

Power consumption

Efficiency ---

Model BN4 100-400B-60/A G

Family N

Code 5100264005000

Speed Fixed speed

Max Flow Rate 210,00 m³/h

H max 51,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 33,00 m

kW 30,00 kW

Power consumption

Efficiency ---

Model BN4 100-400B/A G

Family N

Code 5100264004000

Speed Fixed speed

Max Flow Rate 210,00 m³/h

H max 50,20 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 33,50 m

kW 30,00 kW

Power consumption

Efficiency ---

Model BN4 100-400C-60/A G

Family N

Code 5100262005000

Speed Fixed speed

Max Flow Rate 180,00 m³/h

H max 43,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 28,00 m

kW 22,00 kW

Power consumption

Efficiency ---

Model BN4 100-400C/A G

Family N

Code 5100262004000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 41,30 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 26,00 m

kW 22,00 kW

Power consumption

Efficiency ---

Model BN4 100-315A-60/A G

Family N

Code 5100260005000

Speed Fixed speed

Max Flow Rate 210,00 m³/h

H max 38,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 21,00 m

kW 18,50 kW

Power consumption

Efficiency ---

Model BN4 100-315A/A G

Family N

Code 5100260004000

Speed Fixed speed

Max Flow Rate 210,00 m³/h

H max 36,90 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 22,20 m

kW 18,50 kW

Power consumption

Efficiency ---

Model BN4 100-315B-60/A G

Family N

Code 5100258005000

Speed Fixed speed

Max Flow Rate 210,00 m³/h

H max 32,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 13,50 m

kW 15,00 kW

Power consumption

Efficiency ---

Model BN4 100-315B/A G

Family N

Code 5100258004000

Speed Fixed speed

Max Flow Rate 210,00 m³/h

H max 31,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 14,00 m

kW 15,00 kW

Power consumption

Efficiency ---

Model BN4 100-315C-60/A G

Family N

Code 5100256005000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 28,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 10,00 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN4 100-315C/A G

Family N

Code 5100256004000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 26,90 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 11,30 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN4 100-250A-60/A G

Family N

Code 5100254005000

Speed Fixed speed

Max Flow Rate 210,00 m³/h

H max 22,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 8,80 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN4 100-250A/A G

Family N

Code 5100254004000

Speed Fixed speed

Max Flow Rate 210,00 m³/h

H max 22,30 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 8,90 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN 100-250A-60/A G

Family N

Code 5100252005000

Speed Fixed speed

Max Flow Rate 300,00 m³/h

H max 90,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 108,00 m³/h

Min head 67,00 m

kW 75,00 kW

Power consumption

Efficiency ---

Model BN 100-250A/A G

Family N

Code 5100252004000

Speed Fixed speed

Max Flow Rate 300,00 m³/h

H max 91,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 108,00 m³/h

Min head 67,00 m

kW 75,00 kW

Power consumption

Efficiency ---

Model BN4 100-250B-60/A G

Family N

Code 5100250005000

Speed Fixed speed

Max Flow Rate 210,00 m³/h

H max 19,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 5,50 m

kW 7,50 kW

Power consumption

Efficiency ---

Model BN4 100-250B/A G

Family N

Code 5100250004000

Speed Fixed speed

Max Flow Rate 210,00 m³/h

H max 19,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 5,50 m

kW 7,50 kW

Power consumption

Efficiency ---

Model BN 100-250B-60/A G

Family N

Code 5100248005000

Speed Fixed speed

Max Flow Rate 300,00 m³/h

H max 73,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 108,00 m³/h

Min head 48,00 m

kW 55,00 kW

Power consumption

Efficiency ---

Model BN 100-250B/A G

Family N

Code 5100248004000

Speed Fixed speed

Max Flow Rate 300,00 m³/h

H max 73,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 108,00 m³/h

Min head 48,50 m

kW 55,00 kW

Power consumption

Efficiency ---

Model BN4 100-200A-60/A G

Family N

Code 5100246005000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 14,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 5,50 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN4 100-200A/A G

Family N

Code 5100246004000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 15,20 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 6,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN 100-200A-60/A G

Family N

Code 5100244005000

Speed Fixed speed

Max Flow Rate 300,00 m³/h

H max 61,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 108,00 m³/h

Min head 42,00 m

kW 45,00 kW

Power consumption

Efficiency ---

Model BN 100-200A/A G

Family N

Code 5100244004000

Speed Fixed speed

Max Flow Rate 300,00 m³/h

H max 61,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 108,00 m³/h

Min head 42,00 m

kW 45,00 kW

Power consumption

Efficiency ---

Model BN4 100-200B-60/A G

Family N

Code 5100242005000

Speed Fixed speed

Max Flow Rate 168,00 m³/h

H max 11,70 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 4,60 m

kW 4,00 kW

Power consumption

Efficiency ---

Model BN4 100-200B/A G

Family N

Code 5100242004000

Speed Fixed speed

Max Flow Rate 168,00 m³/h

H max 12,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 4,50 m

kW 4,00 kW

Power consumption

Efficiency ---

Model BN 100-200B-60/A G

Family N

Code 5100240005000

Speed Fixed speed

Max Flow Rate 270,00 m³/h

H max 54,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 108,00 m³/h

Min head 38,00 m

kW 37,00 kW

Power consumption

Efficiency ---

Model BN 100-200B/A G

Family N

Code 5100240004000

Speed Fixed speed

Max Flow Rate 300,00 m³/h

H max 54,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 108,00 m³/h

Min head 32,00 m

kW 37,00 kW

Power consumption

Efficiency ---

Model BN4 100-200C-60/A G

Family N

Code 5100238005000

Speed Fixed speed

Max Flow Rate 150,00 m³/h

H max 9,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 4,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model BN4 100-200C/A G

Family N

Code 5100238004000

Speed Fixed speed

Max Flow Rate 150,00 m³/h

H max 9,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 4,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model BN 100-200C-60/A G

Family N

Code 5100236005000

Speed Fixed speed

Max Flow Rate 270,00 m³/h

H max 45,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 108,00 m³/h

Min head 28,00 m

kW 30,00 kW

Power consumption

Efficiency ---

Model BN 100-200C/A G

Family N

Code 5100236004000

Speed Fixed speed

Max Flow Rate 300,00 m³/h

H max 45,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 108,00 m³/h

Min head 22,00 m

kW 30,00 kW

Power consumption

Efficiency ---

Model BN 100-200D-60/A G

Family N

Code 5100234005000

Speed Fixed speed

Max Flow Rate 240,00 m³/h

H max 36,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 108,00 m³/h

Min head 24,00 m

kW 22,00 kW

Power consumption

Efficiency ---

Model BN 100-200D/A G

Family N

Code 5100234004000

Speed Fixed speed

Max Flow Rate 270,00 m³/h

H max 36,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 108,00 m³/h

Min head 19,00 m

kW 22,00 kW

Power consumption

Efficiency ---

Model BN 100-200E-60/A G

Family N

Code 5100232005000

Speed Fixed speed

Max Flow Rate 240,00 m³/h

H max 30,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 108,00 m³/h

Min head 19,00 m

kW 18,50 kW

Power consumption

Efficiency ---

Model BN 100-200E/A G

Family N

Code 5100232004000

Speed Fixed speed

Max Flow Rate 240,00 m³/h

H max 30,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 108,00 m³/h

Min head 19,00 m

kW 18,50 kW

Power consumption

Efficiency ---

Model BN4 80-400S-60 G

Family N

Code 5100230A05000

Speed Fixed speed

Max Flow Rate 180,00 m³/h

H max 64,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 36,80 m

kW 37,00 kW

Power consumption

Efficiency ---

Model BN4 80-400S G

Family N

Code 5100230A04000

Speed Fixed speed

Max Flow Rate 180,00 m³/h

H max 61,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 39,20 m

kW 37,00 kW

Power consumption

Efficiency ---

Model BN4 80-400A-60/B G

Family N

Code 5100230105000

Speed Fixed speed

Max Flow Rate 150,00 m³/h

H max 64,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 48,10 m

kW 30,00 kW

Power consumption

Efficiency ---

Model BN4 80-400A/B G

Family N

Code 5100230104000

Speed Fixed speed

Max Flow Rate 150,00 m³/h

H max 61,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 49,50 m

kW 30,00 kW

Power consumption

Efficiency ---

Model BN4 80-400B-60/B G

Family N

Code 5100228105000

Speed Fixed speed

Max Flow Rate 150,00 m³/h

H max 52,10 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 31,00 m

kW 22,00 kW

Power consumption

Efficiency ---

Model BN4 80-400B/B G

Family N

Code 5100228104000

Speed Fixed speed

Max Flow Rate 150,00 m³/h

H max 48,20 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 30,50 m

kW 22,00 kW

Power consumption

Efficiency ---

Model BN4 80-400C-60/B G

Family N

Code 5100226105000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 47,20 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 31,30 m

kW 18,50 kW

Power consumption

Efficiency ---

Model BN4 80-400C/B G

Family N

Code 5100226104000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 42,80 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 29,10 m

kW 18,50 kW

Power consumption

Efficiency ---

Model BN4 80-315S-60 G

Family N

Code 5100224A05000

Speed Fixed speed

Max Flow Rate 168,00 m³/h

H max 42,30 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 28,00 m

kW 18,50 kW

Power consumption

Efficiency ---

Model BN4 80-315S G

Family N

Code 5100224A04000

Speed Fixed speed

Max Flow Rate 168,00 m³/h

H max 39,10 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 22,50 m

kW 18,50 kW

Power consumption

Efficiency ---

Model BN4 80-315A-60/B G

Family N

Code 5100224105000

Speed Fixed speed

Max Flow Rate 168,00 m³/h

H max 36,90 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 20,60 m

kW 15,00 kW

Power consumption

Efficiency ---

Model BN4 80-315A/B G

Family N

Code 5100224104000

Speed Fixed speed

Max Flow Rate 150,00 m³/h

H max 36,30 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 25,30 m

kW 15,00 kW

Power consumption

Efficiency ---

Model BN4 80-315B-60/B G

Family N

Code 5100222105000

Speed Fixed speed

Max Flow Rate 150,00 m³/h

H max 31,10 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 17,50 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN4 80-315B/B G

Family N

Code 5100222104000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 30,30 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 22,00 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN4 80-315C-60/B G

Family N

Code 5100220105000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 26,20 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 16,20 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN4 80-315C/B G

Family N

Code 5100220104000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 25,70 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 15,90 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN4 80-250A-60/A G

Family N

Code 5100218005000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 24,20 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 12,70 m

kW 7,50 kW

Power consumption

Efficiency ---

Model BN4 80-250A/A G

Family N

Code 5100218004000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 23,70 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 12,70 m

kW 7,50 kW

Power consumption

Efficiency ---

Model BN 80-250A-60/A G

Family N

Code 5100216005000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 94,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 75,00 m³/h

Min head 76,50 m

kW 55,00 kW

Power consumption

Efficiency ---

Model BN 80-250A/A G

Family N

Code 5100216004000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 95,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 75,00 m³/h

Min head 76,50 m

kW 55,00 kW

Power consumption

Efficiency ---

Model BN4 80-250B-60/A G

Family N

Code 5100214005000

Speed Fixed speed

Max Flow Rate 120,00 m³/h

H max 20,80 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 11,50 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN4 80-250B/A G

Family N

Code 5100214004000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 20,70 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 9,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN 80-250B-60/A G

Family N

Code 5100212005000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 84,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 75,00 m³/h

Min head 62,50 m

kW 45,00 kW

Power consumption

Efficiency ---

Model BN 80-250B/A G

Family N

Code 5100212004000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 84,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 75,00 m³/h

Min head 63,00 m

kW 45,00 kW

Power consumption

Efficiency ---

Model BN4 80-250C-60/A G

Family N

Code 5100210005000

Speed Fixed speed

Max Flow Rate 108,00 m³/h

H max 17,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 9,50 m

kW 4,00 kW

Power consumption

Efficiency ---

Model BN4 80-250C/A G

Family N

Code 5100210004000

Speed Fixed speed

Max Flow Rate 120,00 m³/h

H max 16,90 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 7,20 m

kW 4,00 kW

Power consumption

Efficiency ---

Model BN 80-250C-60/A G

Family N

Code 5100208005000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 73,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 75,00 m³/h

Min head 51,00 m

kW 37,00 kW

Power consumption

Efficiency ---

Model BN 80-250C/A G

Family N

Code 5100208004000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 73,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 75,00 m³/h

Min head 51,50 m

kW 37,00 kW

Power consumption

Efficiency ---

Model BN 80-250D-60/A G

Family N

Code 5100206005000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 65,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 75,00 m³/h

Min head 41,00 m

kW 30,00 kW

Power consumption

Efficiency ---

Model BN 80-250D/A G

Family N

Code 5100206004000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 65,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 75,00 m³/h

Min head 41,00 m

kW 30,00 kW

Power consumption

Efficiency ---

Model BN 80-250E-60/A G

Family N

Code 5100204005000

Speed Fixed speed

Max Flow Rate 180,00 m³/h

H max 51,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 75,00 m³/h

Min head 29,00 m

kW 22,00 kW

Power consumption

Efficiency ---

Model BN 80-250E/A G

Family N

Code 5100204004000

Speed Fixed speed

Max Flow Rate 180,00 m³/h

H max 51,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 75,00 m³/h

Min head 29,00 m

kW 22,00 kW

Power consumption

Efficiency ---

Model BN4 80-200A-60/B G

Family N

Code 5100202105000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 14,80 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 7,70 m

kW 4,00 kW

Power consumption

Efficiency ---

Model BN4 80-200A/B G

Family N

Code 5100202104000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 14,20 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 6,90 m

kW 4,00 kW

Power consumption

Efficiency ---

Model BN 80-200A-60/B G

Family N

Code 5100200105000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 58,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 75,00 m³/h

Min head 47,80 m

kW 30,00 kW

Power consumption

Efficiency ---

Model BN 80-200A/B G

Family N

Code 5100200104000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 56,60 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 75,00 m³/h

Min head 45,60 m

kW 30,00 kW

Power consumption

Efficiency ---

Model BN4 80-200B-60/B G

Family N

Code 5100198105000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 12,20 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 4,50 m

kW 3,00 kW

Power consumption

Efficiency ---

Model BN4 80-200B/B G

Family N

Code 5100198104000

Speed Fixed speed

Max Flow Rate 120,00 m³/h

H max 11,70 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 4,10 m

kW 3,00 kW

Power consumption

Efficiency ---

Model BN 80-200B-60/B G

Family N

Code 5100196105000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 43,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 75,00 m³/h

Min head 32,20 m

kW 22,00 kW

Power consumption

Efficiency ---

Model BN 80-200B/B G

Family N

Code 5100196104000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 44,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 75,00 m³/h

Min head 32,40 m

kW 22,00 kW

Power consumption

Efficiency ---

Model BN4 80-200C-60/B G

Family N

Code 5100194105000

Speed Fixed speed

Max Flow Rate 108,00 m³/h

H max 9,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 4,50 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN4 80-200C/B G

Family N

Code 5100194104000

Speed Fixed speed

Max Flow Rate 120,00 m³/h

H max 9,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 2,70 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN4 80-160A-60/B G

Family N

Code 5100192105000

Speed Fixed speed

Max Flow Rate 108,00 m³/h

H max 11,30 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 6,60 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN4 80-160A/B G

Family N

Code 5100192104000

Speed Fixed speed

Max Flow Rate 108,00 m³/h

H max 10,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 5,90 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN 80-160A-60/B G

Family N

Code 5100190105000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 41,30 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 75,00 m³/h

Min head 28,80 m

kW 18,50 kW

Power consumption

Efficiency ---

Model BN 80-160A/B G

Family N

Code 5100190104000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 39,90 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 75,00 m³/h

Min head 28,10 m

kW 18,50 kW

Power consumption

Efficiency ---

Model BN4 80-160B-60/B G

Family N

Code 5100188105000

Speed Fixed speed

Max Flow Rate 96,00 m³/h

H max 8,60 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 4,50 m

kW 1,50 kW

Power consumption

Efficiency ---

Model BN4 80-160B/B G

Family N

Code 5100188104000

Speed Fixed speed

Max Flow Rate 96,00 m³/h

H max 7,80 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 4,10 m

kW 1,50 kW

Power consumption

Efficiency ---

Model BN 80-160B-60/B G

Family N

Code 5100186105000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 35,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 75,00 m³/h

Min head 21,00 m

kW 15,00 kW

Power consumption

Efficiency ---

Model BN 80-160B/B G

Family N

Code 5100186104000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 34,80 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 75,00 m³/h

Min head 22,40 m

kW 15,00 kW

Power consumption

Efficiency ---

Model BN4 80-160C-60/B G

Family N

Code 5100184105000

Speed Fixed speed

Max Flow Rate 84,00 m³/h

H max 6,90 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 3,70 m

kW 1,10 kW

Power consumption

Efficiency ---

Model BN4 80-160C/B G

Family N

Code 5100184104000

Speed Fixed speed

Max Flow Rate 84,00 m³/h

H max 6,10 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 3,30 m

kW 1,10 kW

Power consumption

Efficiency ---

Model BN 80-160C-60/B G

Family N

Code 5100182105000

Speed Fixed speed

Max Flow Rate 180,00 m³/h

H max 30,70 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 75,00 m³/h

Min head 17,90 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN 80-160C/B G

Family N

Code 5100182104000

Speed Fixed speed

Max Flow Rate 180,00 m³/h

H max 28,70 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 75,00 m³/h

Min head 16,40 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN 80-160D-60/B G

Family N

Code 5100180105000

Speed Fixed speed

Max Flow Rate 168,00 m³/h

H max 26,90 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 75,00 m³/h

Min head 15,10 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN 80-160D/B G

Family N

Code 5100180104000

Speed Fixed speed

Max Flow Rate 168,00 m³/h

H max 25,20 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 75,00 m³/h

Min head 14,40 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN 80-160E-60/B G

Family N

Code 5100178105000

Speed Fixed speed

Max Flow Rate 168,00 m³/h

H max 23,30 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 75,00 m³/h

Min head 11,90 m

kW 7,50 kW

Power consumption

Efficiency ---

Model BN 80-160E/B G

Family N

Code 5100178104000

Speed Fixed speed

Max Flow Rate 168,00 m³/h

H max 21,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 75,00 m³/h

Min head 10,60 m

kW 7,50 kW

Power consumption

Efficiency ---

Model BN4 65-315A-60/A G

Family N

Code 5100176005000

Speed Fixed speed

Max Flow Rate 84,00 m³/h

H max 36,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 21,00 m³/h

Min head 26,50 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN4 65-315A/A G

Family N

Code 5100176004000

Speed Fixed speed

Max Flow Rate 84,00 m³/h

H max 35,90 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 21,00 m³/h

Min head 25,00 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN4 65-315B-60/A G

Family N

Code 5100174005000

Speed Fixed speed

Max Flow Rate 84,00 m³/h

H max 32,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 21,00 m³/h

Min head 20,50 m

kW 7,50 kW

Power consumption

Efficiency ---

Model BN4 65-315B/A G

Family N

Code 5100174004000

Speed Fixed speed

Max Flow Rate 84,00 m³/h

H max 31,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 21,00 m³/h

Min head 18,60 m

kW 7,50 kW

Power consumption

Efficiency ---

Model BN4 65-315C-60/A G

Family N

Code 5100172005000

Speed Fixed speed

Max Flow Rate 84,00 m³/h

H max 27,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 21,00 m³/h

Min head 13,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN4 65-315C/A G

Family N

Code 5100172004000

Speed Fixed speed

Max Flow Rate 84,00 m³/h

H max 25,80 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 21,00 m³/h

Min head 11,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN4 65-250A-60/B G

Family N

Code 5100170105000

Speed Fixed speed

Max Flow Rate 96,00 m³/h

H max 23,80 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 21,00 m³/h

Min head 13,70 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN4 65-250A/B G

Family N

Code 5100170104000

Speed Fixed speed

Max Flow Rate 96,00 m³/h

H max 22,20 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 21,00 m³/h

Min head 12,60 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN 65-250A-60/B G

Family N

Code 5100168105000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 87,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 74,50 m

kW 37,00 kW

Power consumption

Efficiency ---

Model BN 65-250A/B G

Family N

Code 5100168104000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 86,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 74,50 m

kW 37,00 kW

Power consumption

Efficiency ---

Model BN4 65-250B-60/B G

Family N

Code 5100166105000

Speed Fixed speed

Max Flow Rate 96,00 m³/h

H max 19,60 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 21,00 m³/h

Min head 7,10 m

kW 4,00 kW

Power consumption

Efficiency ---

Model BN4 65-250B/B G

Family N

Code 5100166104000

Speed Fixed speed

Max Flow Rate 96,00 m³/h

H max 17,90 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 21,00 m³/h

Min head 7,00 m

kW 4,00 kW

Power consumption

Efficiency ---

Model BN 65-250B-60/B G

Family N

Code 5100164105000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 74,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 60,50 m

kW 30,00 kW

Power consumption

Efficiency ---

Model BN 65-250B/B G

Family N

Code 5100164104000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 73,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 59,00 m

kW 30,00 kW

Power consumption

Efficiency ---

Model BN 65-250C-60/B G

Family N

Code 5100162105000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 63,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 43,00 m

kW 22,00 kW

Power consumption

Efficiency ---

Model BN 65-250C/B G

Family N

Code 5100162104000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 61,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 43,00 m

kW 22,00 kW

Power consumption

Efficiency ---

Model BN4 65-200A-60/B G

Family N

Code 5100160105000

Speed Fixed speed

Max Flow Rate 96,00 m³/h

H max 14,60 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 21,00 m³/h

Min head 6,80 m

kW 3,00 kW

Power consumption

Efficiency ---

Model BN4 65-200A/B G

Family N

Code 5100160104000

Speed Fixed speed

Max Flow Rate 96,00 m³/h

H max 14,20 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 21,00 m³/h

Min head 7,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model BN 65-200A-60/B G

Family N

Code 5100158105000

Speed Fixed speed

Max Flow Rate 141,00 m³/h

H max 58,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 45,50 m

kW 22,00 kW

Power consumption

Efficiency ---

Model BN 65-200A/B G

Family N

Code 5100158104000

Speed Fixed speed

Max Flow Rate 141,00 m³/h

H max 57,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 45,50 m

kW 22,00 kW

Power consumption

Efficiency ---

Model BN4 65-200B-60/B G

Family N

Code 5100156105000

Speed Fixed speed

Max Flow Rate 96,00 m³/h

H max 12,20 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 21,00 m³/h

Min head 3,20 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN4 65-200B/B G

Family N

Code 5100156104000

Speed Fixed speed

Max Flow Rate 96,00 m³/h

H max 11,70 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 21,00 m³/h

Min head 3,30 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN 65-200B-60/B G

Family N

Code 5100154105000

Speed Fixed speed

Max Flow Rate 141,00 m³/h

H max 52,80 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 38,70 m

kW 18,50 kW

Power consumption

Efficiency ---

Model BN 65-200B/B G

Family N

Code 5100154104000

Speed Fixed speed

Max Flow Rate 141,00 m³/h

H max 50,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 37,50 m

kW 18,50 kW

Power consumption

Efficiency ---

Model BN 65-200C-60/B G

Family N

Code 5100152105000

Speed Fixed speed

Max Flow Rate 141,00 m³/h

H max 45,10 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 30,40 m

kW 15,00 kW

Power consumption

Efficiency ---

Model BN 65-200C/B G

Family N

Code 5100152104000

Speed Fixed speed

Max Flow Rate 141,00 m³/h

H max 44,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 28,80 m

kW 15,00 kW

Power consumption

Efficiency ---

Model BN4 65-160S-60 G

Family N

Code 5100150A05000

Speed Fixed speed

Max Flow Rate 84,00 m³/h

H max 10,30 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 21,00 m³/h

Min head 6,20 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN4 65-160S G

Family N

Code 5100150A04000

Speed Fixed speed

Max Flow Rate 84,00 m³/h

H max 10,20 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 21,00 m³/h

Min head 5,70 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN4 65-160A-60/B G

Family N

Code 5100150105000

Speed Fixed speed

Max Flow Rate 75,00 m³/h

H max 8,90 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 21,00 m³/h

Min head 5,70 m

kW 1,50 kW

Power consumption

Efficiency ---

Model BN4 65-160A/B G

Family N

Code 5100150104000

Speed Fixed speed

Max Flow Rate 75,00 m³/h

H max 8,80 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 21,00 m³/h

Min head 5,20 m

kW 1,50 kW

Power consumption

Efficiency ---

Model BN 65-160AR-60 G

Family N

Code 5100148A05000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 35,90 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 28,50 m

kW 15,00 kW

Power consumption

Efficiency ---

Model BN 65-160AR G

Family N

Code 5100148A04000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 36,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 27,50 m

kW 15,00 kW

Power consumption

Efficiency ---

Model BN 65-160A-60/B G

Family N

Code 5100148105000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 40,70 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 33,20 m

kW 15,00 kW

Power consumption

Efficiency ---

Model BN 65-160A/B G

Family N

Code 5100148104000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 40,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 31,70 m

kW 15,00 kW

Power consumption

Efficiency ---

Model BN4 65-160B-60/B G

Family N

Code 5100146105000

Speed Fixed speed

Max Flow Rate 66,00 m³/h

H max 7,20 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 21,00 m³/h

Min head 4,60 m

kW 1,10 kW

Power consumption

Efficiency ---

Model BN4 65-160B/B G

Family N

Code 5100146104000

Speed Fixed speed

Max Flow Rate 66,00 m³/h

H max 7,20 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 21,00 m³/h

Min head 4,50 m

kW 1,10 kW

Power consumption

Efficiency ---

Model BN 65-160B-60/B G

Family N

Code 5100144105000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 32,80 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 24,40 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN 65-160B/B G

Family N

Code 5100144104000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 32,60 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 23,00 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN4 65-160C-60/B G

Family N

Code 5100142105000

Speed Fixed speed

Max Flow Rate 60,00 m³/h

H max 6,20 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 21,00 m³/h

Min head 4,30 m

kW 1,10 kW

Power consumption

Efficiency ---

Model BN4 65-160C/B G

Family N

Code 5100142104000

Speed Fixed speed

Max Flow Rate 60,00 m³/h

H max 6,10 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 21,00 m³/h

Min head 4,20 m

kW 1,10 kW

Power consumption

Efficiency ---

Model BN 65-160C-60/B G

Family N

Code 5100140105000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 27,90 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 19,00 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN 65-160C/B G

Family N

Code 5100140104000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 28,10 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 17,70 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN 65-160D-60/B G

Family N

Code 5100138105000

Speed Fixed speed

Max Flow Rate 120,00 m³/h

H max 24,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 17,60 m

kW 7,50 kW

Power consumption

Efficiency ---

Model BN 65-160D/B G

Family N

Code 5100138104000

Speed Fixed speed

Max Flow Rate 120,00 m³/h

H max 24,30 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 48,00 m³/h

Min head 16,30 m

kW 7,50 kW

Power consumption

Efficiency ---

Model BN4 65-125A-60/B G

Family N

Code 5100134105000

Speed Fixed speed

Max Flow Rate 60,00 m³/h

H max 6,60 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 21,00 m³/h

Min head 4,70 m

kW 1,10 kW

Power consumption

Efficiency ---

Model BN4 65-125A/B G

Family N

Code 5100134104000

Speed Fixed speed

Max Flow Rate 60,00 m³/h

H max 6,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 21,00 m³/h

Min head 4,40 m

kW 1,10 kW

Power consumption

Efficiency ---

Model BN 65-125A-60/B G

Family N

Code 5100132105000

Speed Fixed speed

Max Flow Rate 120,00 m³/h

H max 26,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 37,80 m³/h

Min head 18,90 m

kW 7,50 kW

Power consumption

Efficiency ---

Model BN 65-125A/B G

Family N

Code 5100132104000

Speed Fixed speed

Max Flow Rate 120,00 m³/h

H max 25,90 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 37,80 m³/h

Min head 17,60 m

kW 7,50 kW

Power consumption

Efficiency ---

Model BN4 65-125C-60/B G

Family N

Code 5100130105000

Speed Fixed speed

Max Flow Rate 60,00 m³/h

H max 5,30 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 21,00 m³/h

Min head 3,30 m

kW 0,75 kW

Power consumption

Efficiency ---

Model BN4 65-125C/B G

Family N

Code 5100130104000

Speed Fixed speed

Max Flow Rate 60,00 m³/h

H max 5,30 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 21,00 m³/h

Min head 3,00 m

kW 0,75 kW

Power consumption

Efficiency ---

Model BN 65-125C-60/B G

Family N

Code 5100128105000

Speed Fixed speed

Max Flow Rate 120,00 m³/h

H max 21,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 37,80 m³/h

Min head 13,10 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN 65-125C/B G

Family N

Code 5100128104000

Speed Fixed speed

Max Flow Rate 120,00 m³/h

H max 21,10 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 37,80 m³/h

Min head 11,80 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN4 65-125E-60/B G

Family N

Code 5100126105000

Speed Fixed speed

Max Flow Rate 54,00 m³/h

H max 4,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 21,00 m³/h

Min head 2,50 m

kW 0,75 kW

Power consumption

Efficiency ---

Model BN4 65-125E/B G

Family N

Code 5100126104000

Speed Fixed speed

Max Flow Rate 54,00 m³/h

H max 4,10 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 21,00 m³/h

Min head 2,30 m

kW 0,75 kW

Power consumption

Efficiency ---

Model BN 65-125E-60/B G

Family N

Code 5100124105000

Speed Fixed speed

Max Flow Rate 108,00 m³/h

H max 16,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 37,80 m³/h

Min head 9,90 m

kW 4,00 kW

Power consumption

Efficiency ---

Model BN 65-125E/B G

Family N

Code 5100124104000

Speed Fixed speed

Max Flow Rate 108,00 m³/h

H max 16,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 37,80 m³/h

Min head 9,20 m

kW 4,00 kW

Power consumption

Efficiency ---

Model BN4 50-250A-60/A G

Family N

Code 5100122005000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 24,10 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 10,80 m³/h

Min head 14,00 m

kW 4,00 kW

Power consumption

Efficiency ---

Model BN4 50-250A/A G

Family N

Code 5100122004000

Speed Fixed speed

Max Flow Rate 48,00 m³/h

H max 22,70 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 10,80 m³/h

Min head 9,00 m

kW 4,00 kW

Power consumption

Efficiency ---

Model BN 50-250S/A G

Family N

Code 5100120A04000

Speed Fixed speed

Max Flow Rate 69,00 m³/h

H max 88,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 24,00 m³/h

Min head 68,50 m

kW 22,00 kW

Power consumption

Efficiency ---

Model BN 50-250A-60/A G

Family N

Code 5100120005000

Speed Fixed speed

Max Flow Rate 66,00 m³/h

H max 87,60 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 24,00 m³/h

Min head 66,90 m

kW 18,50 kW

Power consumption

Efficiency ---

Model BN 50-250A/A G

Family N

Code 5100120004000

Speed Fixed speed

Max Flow Rate 69,00 m³/h

H max 80,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 24,00 m³/h

Min head 58,50 m

kW 18,50 kW

Power consumption

Efficiency ---

Model BN4 50-250B-60/A G

Family N

Code 5100118005000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 23,10 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 10,80 m³/h

Min head 12,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model BN4 50-250B/A G

Family N

Code 5100118004000

Speed Fixed speed

Max Flow Rate 48,00 m³/h

H max 20,70 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 10,80 m³/h

Min head 5,80 m

kW 3,00 kW

Power consumption

Efficiency ---

Model BN 50-250B-60/A G

Family N

Code 5100116005000

Speed Fixed speed

Max Flow Rate 66,00 m³/h

H max 74,60 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 24,00 m³/h

Min head 43,80 m

kW 15,00 kW

Power consumption

Efficiency ---

Model BN 50-250B/A G

Family N

Code 5100116004000

Speed Fixed speed

Max Flow Rate 69,00 m³/h

H max 69,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 24,00 m³/h

Min head 43,00 m

kW 15,00 kW

Power consumption

Efficiency ---

Model BN4 50-250D G

Family N

Code 5100114014000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 14,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 10,80 m³/h

Min head 2,30 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN4 50-250C-60/A G

Family N

Code 5100114005000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 18,90 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 10,80 m³/h

Min head 7,20 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN4 50-250C/A G

Family N

Code 5100114004000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 17,80 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 10,80 m³/h

Min head 6,80 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN 50-250C-60/A G

Family N

Code 5100112005000

Speed Fixed speed

Max Flow Rate 60,00 m³/h

H max 61,90 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 24,00 m³/h

Min head 36,50 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN 50-250C/A G

Family N

Code 5100112004000

Speed Fixed speed

Max Flow Rate 69,00 m³/h

H max 55,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 24,00 m³/h

Min head 24,50 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN4 50-200A-60/A G

Family N

Code 5100110005000

Speed Fixed speed

Max Flow Rate 54,00 m³/h

H max 16,70 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 10,80 m³/h

Min head 5,40 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN4 50-200A/A G

Family N

Code 5100110004000

Speed Fixed speed

Max Flow Rate 48,00 m³/h

H max 14,90 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 10,80 m³/h

Min head 6,00 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN 50-200A-60/A G

Family N

Code 5100108005000

Speed Fixed speed

Max Flow Rate 75,00 m³/h

H max 57,60 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 24,00 m³/h

Min head 33,20 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN 50-200A/A G

Family N

Code 5100108004000

Speed Fixed speed

Max Flow Rate 78,00 m³/h

H max 55,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 24,00 m³/h

Min head 32,50 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN4 50-200B-60/A G

Family N

Code 5100106005000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 12,80 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 10,80 m³/h

Min head 3,40 m

kW 1,50 kW

Power consumption

Efficiency ---

Model BN4 50-200B/A G

Family N

Code 5100106004000

Speed Fixed speed

Max Flow Rate 48,00 m³/h

H max 13,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 10,80 m³/h

Min head 3,70 m

kW 1,50 kW

Power consumption

Efficiency ---

Model BN 50-200B-60/A G

Family N

Code 5100104005000

Speed Fixed speed

Max Flow Rate 69,00 m³/h

H max 51,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 24,00 m³/h

Min head 27,30 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN 50-200B/A G

Family N

Code 5100104004000

Speed Fixed speed

Max Flow Rate 78,00 m³/h

H max 48,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 24,00 m³/h

Min head 23,00 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN4 50-200C-60/A G

Family N

Code 5100102005000

Speed Fixed speed

Max Flow Rate 37,80 m³/h

H max 11,20 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 10,80 m³/h

Min head 2,70 m

kW 1,10 kW

Power consumption

Efficiency ---

Model BN4 50-200C/A G

Family N

Code 5100102004000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 11,80 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 10,80 m³/h

Min head 4,70 m

kW 1,10 kW

Power consumption

Efficiency ---

Model BN4 50-160A-60/A G

Family N

Code 5100100005000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 10,55 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 10,80 m³/h

Min head 5,30 m

kW 1,10 kW

Power consumption

Efficiency ---

Model BN4 50-160A/A G

Family N

Code 5100100004000

Speed Fixed speed

Max Flow Rate 48,00 m³/h

H max 9,60 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 10,80 m³/h

Min head 3,10 m

kW 1,10 kW

Power consumption

Efficiency ---

Model BN 50-160A-60/A G

Family N

Code 5100098005000

Speed Fixed speed

Max Flow Rate 84,00 m³/h

H max 41,70 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 20,40 m

kW 7,50 kW

Power consumption

Efficiency ---

Model BN 50-160A/A G

Family N

Code 5100098004000

Speed Fixed speed

Max Flow Rate 81,00 m³/h

H max 38,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 19,00 m

kW 7,50 kW

Power consumption

Efficiency ---

Model BN4 50-160B-60/A G

Family N

Code 5100096005000

Speed Fixed speed

Max Flow Rate 37,80 m³/h

H max 9,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 10,80 m³/h

Min head 3,80 m

kW 1,10 kW

Power consumption

Efficiency ---

Model BN4 50-160B/A G

Family N

Code 5100096004000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 8,20 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 10,80 m³/h

Min head 3,30 m

kW 1,10 kW

Power consumption

Efficiency ---

Model BN 50-160B-60-S/A G

Family N

Code 5100094007000

Speed Fixed speed

Max Flow Rate 75,00 m³/h

H max 35,30 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 15,10 m

kW 7,50 kW

Power consumption

Efficiency ---

Model BN 50-160B-60/A G

Family N

Code 5100094005000

Speed Fixed speed

Max Flow Rate 37,80 m³/h

H max 35,30 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 33,60 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN 50-160B/A G

Family N

Code 5100094004000

Speed Fixed speed

Max Flow Rate 81,00 m³/h

H max 31,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 9,50 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN4 50-125S/A G

Family N

Code 5100092A04000

Speed Fixed speed

Max Flow Rate 37,80 m³/h

H max 6,80 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 10,80 m³/h

Min head 3,80 m

kW 0,75 kW

Power consumption

Efficiency ---

Model BN4 50-125A/A G

Family N

Code 5100092004000

Speed Fixed speed

Max Flow Rate 37,80 m³/h

H max 6,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 10,80 m³/h

Min head 2,90 m

kW 0,75 kW

Power consumption

Efficiency ---

Model BN 50-125S-S/A G

Family N

Code 5100090A06000

Speed Fixed speed

Max Flow Rate 81,00 m³/h

H max 26,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 11,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN 50-125S/A G

Family N

Code 5100090A04000

Speed Fixed speed

Max Flow Rate 54,00 m³/h

H max 26,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 22,00 m

kW 4,00 kW

Power consumption

Efficiency ---

Model BN 50-125A-60-S/A G

Family N

Code 5100090007000

Speed Fixed speed

Max Flow Rate 75,00 m³/h

H max 24,80 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 13,60 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN 50-125A-60/A G

Family N

Code 5100090005000

Speed Fixed speed

Max Flow Rate 48,00 m³/h

H max 24,80 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 22,30 m

kW 4,00 kW

Power consumption

Efficiency ---

Model BN 50-125A/A G

Family N

Code 5100090004000

Speed Fixed speed

Max Flow Rate 78,00 m³/h

H max 24,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 10,00 m

kW 4,00 kW

Power consumption

Efficiency ---

Model BN4 50-125D/A G

Family N

Code 5100088004000

Speed Fixed speed

Max Flow Rate 33,00 m³/h

H max 5,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 10,80 m³/h

Min head 2,50 m

kW 0,55 kW

Power consumption

Efficiency ---

Model BN 50-125D-60/A G

Family N

Code 5100086005000

Speed Fixed speed

Max Flow Rate 66,00 m³/h

H max 19,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 8,40 m

kW 3,00 kW

Power consumption

Efficiency ---

Model BN 50-125D/A G

Family N

Code 5100086004000

Speed Fixed speed

Max Flow Rate 72,00 m³/h

H max 20,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 8,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model BN4 50-125F/A G

Family N

Code 5100084004000

Speed Fixed speed

Max Flow Rate 33,00 m³/h

H max 4,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 10,80 m³/h

Min head 0,50 m

kW 0,37 kW

Power consumption

Efficiency ---

Model BN 50-125F-60/A G

Family N

Code 5100082005000

Speed Fixed speed

Max Flow Rate 60,00 m³/h

H max 16,10 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 5,80 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN 50-125F/A G

Family N

Code 5100082004000

Speed Fixed speed

Max Flow Rate 66,00 m³/h

H max 15,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 30,00 m³/h

Min head 6,00 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN4 40-250A-60/A G

Family N

Code 5100080005000

Speed Fixed speed

Max Flow Rate 30,00 m³/h

H max 25,10 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 5,40 m³/h

Min head 10,70 m

kW 3,00 kW

Power consumption

Efficiency ---

Model BN4 40-250A/A G

Family N

Code 5100080004000

Speed Fixed speed

Max Flow Rate 30,00 m³/h

H max 22,90 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 5,40 m³/h

Min head 8,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model BN 40-250A-60/A G

Family N

Code 5100078005000

Speed Fixed speed

Max Flow Rate 39,00 m³/h

H max 90,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 76,00 m

kW 15,00 kW

Power consumption

Efficiency ---

Model BN 40-250A/A G

Family N

Code 5100078004000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 90,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 70,50 m

kW 15,00 kW

Power consumption

Efficiency ---

Model BN4 40-250B-60/A G

Family N

Code 5100076005000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 22,70 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 5,40 m³/h

Min head 10,10 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN4 40-250B/A G

Family N

Code 5100076004000

Speed Fixed speed

Max Flow Rate 30,00 m³/h

H max 21,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 5,40 m³/h

Min head 5,00 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN 40-250B-60/A G

Family N

Code 5100074005000

Speed Fixed speed

Max Flow Rate 37,80 m³/h

H max 71,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 50,00 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN 40-250B/A G

Family N

Code 5100074004000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 69,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 45,00 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN4 40-250C-60/A G

Family N

Code 5100072005000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 18,30 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 5,40 m³/h

Min head 4,40 m

kW 1,50 kW

Power consumption

Efficiency ---

Model BN4 40-250C/A G

Family N

Code 5100072004000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 17,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 5,40 m³/h

Min head 2,80 m

kW 1,50 kW

Power consumption

Efficiency ---

Model BN 40-250C-60/A G

Family N

Code 5100070005000

Speed Fixed speed

Max Flow Rate 33,00 m³/h

H max 65,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 49,00 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN 40-250C/A G

Family N

Code 5100070004000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 61,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 33,50 m

kW 11,00 kW

Power consumption

Efficiency ---

Model BN4 40-200A-60/A G

Family N

Code 5100068005000

Speed Fixed speed

Max Flow Rate 21,00 m³/h

H max 15,30 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 5,40 m³/h

Min head 9,30 m

kW 1,10 kW

Power consumption

Efficiency ---

Model BN4 40-200A/A G

Family N

Code 5100068004000

Speed Fixed speed

Max Flow Rate 21,00 m³/h

H max 14,80 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 5,40 m³/h

Min head 10,00 m

kW 1,10 kW

Power consumption

Efficiency ---

Model BN 40-200A-60/A G

Family N

Code 5100066005000

Speed Fixed speed

Max Flow Rate 37,80 m³/h

H max 59,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 38,50 m

kW 7,50 kW

Power consumption

Efficiency ---

Model BN 40-200A/A G

Family N

Code 5100066004000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 57,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 35,00 m

kW 7,50 kW

Power consumption

Efficiency ---

Model BN 40-200AR-60-S/A G

Family N

Code 5100064007000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 56,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 49,00 m

kW 7,50 kW

Power consumption

Efficiency ---

Model BN 40-200AR-S/A G

Family N

Code 5100064006000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 55,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 49,00 m

kW 7,50 kW

Power consumption

Efficiency ---

Model BN 40-200AR-60/A G

Family N

Code 5100064005000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 56,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 52,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN 40-200AR/A G

Family N

Code 5100064004000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 55,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 51,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN4 40-200B-60/A G

Family N

Code 5100062005000

Speed Fixed speed

Max Flow Rate 18,90 m³/h

H max 13,30 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 5,40 m³/h

Min head 7,80 m

kW 1,10 kW

Power consumption

Efficiency ---

Model BN4 40-200B/A G

Family N

Code 5100062004000

Speed Fixed speed

Max Flow Rate 21,00 m³/h

H max 13,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 5,40 m³/h

Min head 7,00 m

kW 1,10 kW

Power consumption

Efficiency ---

Model BN 40-200B-S/A G

Family N

Code 5100060006000

Speed Fixed speed

Max Flow Rate 37,80 m³/h

H max 50,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 30,50 m

kW 7,50 kW

Power consumption

Efficiency ---

Model BN 40-200B-60/A G

Family N

Code 5100060005000

Speed Fixed speed

Max Flow Rate 33,00 m³/h

H max 52,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 35,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN 40-200B/A G

Family N

Code 5100060004000

Speed Fixed speed

Max Flow Rate 33,00 m³/h

H max 50,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 37,50 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN 40-200D-S/A G

Family N

Code 5100058016000

Speed Fixed speed

Max Flow Rate 37,80 m³/h

H max 39,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 14,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN 40-200D/A G

Family N

Code 5100058014000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 39,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 30,50 m

kW 4,00 kW

Power consumption

Efficiency ---

Model BN 40-200C-60-S/A G

Family N

Code 5100058007000

Speed Fixed speed

Max Flow Rate 21,00 m³/h

H max 44,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 36,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN 40-200C-S/A G

Family N

Code 5100058006000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 41,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 33,50 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN 40-200C-60/A G

Family N

Code 5100058005000

Speed Fixed speed

Max Flow Rate 21,00 m³/h

H max 44,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 41,00 m

kW 4,00 kW

Power consumption

Efficiency ---

Model BN 40-200C/A G

Family N

Code 5100058004000

Speed Fixed speed

Max Flow Rate 21,00 m³/h

H max 41,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 38,00 m

kW 4,00 kW

Power consumption

Efficiency ---

Model BN4 40-160A-60/A G

Family N

Code 5100056005000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 9,70 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 5,40 m³/h

Min head 5,80 m

kW 0,75 kW

Power consumption

Efficiency ---

Model BN4 40-160A/A G

Family N

Code 5100056004000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 9,60 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 5,40 m³/h

Min head 3,50 m

kW 0,75 kW

Power consumption

Efficiency ---

Model BN 40-160A-60-S/A G

Family N

Code 5100054007000

Speed Fixed speed

Max Flow Rate 45,00 m³/h

H max 37,10 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 23,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN 40-160A-S/A G

Family N

Code 5100054006000

Speed Fixed speed

Max Flow Rate 48,00 m³/h

H max 37,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 17,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN 40-160A-60/A G

Family N

Code 5100054005000

Speed Fixed speed

Max Flow Rate 33,00 m³/h

H max 37,10 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 31,80 m

kW 4,00 kW

Power consumption

Efficiency ---

Model BN 40-160A/A G

Family N

Code 5100054004000

Speed Fixed speed

Max Flow Rate 37,80 m³/h

H max 37,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 27,00 m

kW 4,00 kW

Power consumption

Efficiency ---

Model BN4 40-160B-60/A G

Family N

Code 5100052005000

Speed Fixed speed

Max Flow Rate 21,00 m³/h

H max 8,10 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 5,40 m³/h

Min head 4,60 m

kW 0,55 kW

Power consumption

Efficiency ---

Model BN4 40-160B/A G

Family N

Code 5100052004000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 7,60 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 5,40 m³/h

Min head 2,70 m

kW 0,55 kW

Power consumption

Efficiency ---

Model BN 40-160B-60/A G

Family N

Code 5100050005000

Speed Fixed speed

Max Flow Rate 39,00 m³/h

H max 31,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 18,10 m

kW 3,00 kW

Power consumption

Efficiency ---

Model BN 40-160B/A G

Family N

Code 5100050004000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 29,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 14,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model BN4 40-160C-60/A G

Family N

Code 5100048005000

Speed Fixed speed

Max Flow Rate 18,90 m³/h

H max 6,75 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 5,40 m³/h

Min head 3,20 m

kW 0,37 kW

Power consumption

Efficiency ---

Model BN4 40-160C/A G

Family N

Code 5100048004000

Speed Fixed speed

Max Flow Rate 21,00 m³/h

H max 6,10 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 5,40 m³/h

Min head 2,30 m

kW 0,37 kW

Power consumption

Efficiency ---

Model BN 40-160C-60-S/A G

Family N

Code 5100046007000

Speed Fixed speed

Max Flow Rate 37,80 m³/h

H max 25,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 10,60 m

kW 3,00 kW

Power consumption

Efficiency ---

Model BN 40-160C-60/A G

Family N

Code 5100046005000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 25,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 22,10 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN 40-160C/A G

Family N

Code 5100046004000

Speed Fixed speed

Max Flow Rate 39,00 m³/h

H max 23,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 10,00 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN 40-125A-60/A G

Family N

Code 5100042005000

Speed Fixed speed

Max Flow Rate 39,00 m³/h

H max 22,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 12,90 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN 40-125A/A G

Family N

Code 5100042004000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 22,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 11,50 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN 40-125C-60/A G

Family N

Code 5100038005000

Speed Fixed speed

Max Flow Rate 37,80 m³/h

H max 18,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 6,90 m

kW 1,50 kW

Power consumption

Efficiency ---

Model BN 40-125C/A G

Family N

Code 5100038004000

Speed Fixed speed

Max Flow Rate 39,00 m³/h

H max 17,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 6,50 m

kW 1,50 kW

Power consumption

Efficiency ---

Model BN 40-125F-60/A G

Family N

Code 5100034005000

Speed Fixed speed

Max Flow Rate 33,00 m³/h

H max 15,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 5,60 m

kW 1,10 kW

Power consumption

Efficiency ---

Model BN 40-125F/A G

Family N

Code 5100034004000

Speed Fixed speed

Max Flow Rate 33,00 m³/h

H max 14,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 15,00 m³/h

Min head 6,00 m

kW 1,10 kW

Power consumption

Efficiency ---

Model BN4 32-200A-60/A G

Family N

Code 5100032005000

Speed Fixed speed

Max Flow Rate 13,20 m³/h

H max 14,90 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 2,40 m³/h

Min head 8,50 m

kW 0,75 kW

Power consumption

Efficiency ---

Model BN4 32-200A/A G

Family N

Code 5100032004000

Speed Fixed speed

Max Flow Rate 13,20 m³/h

H max 14,30 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 2,40 m³/h

Min head 7,50 m

kW 0,75 kW

Power consumption

Efficiency ---

Model BN 32-200A-60-S/A G

Family N

Code 5100030007000

Speed Fixed speed

Max Flow Rate 16,80 m³/h

H max 57,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 49,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN 32-200A-S/A G

Family N

Code 5100030006000

Speed Fixed speed

Max Flow Rate 18,90 m³/h

H max 57,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 46,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model BN 32-200A-60/A G

Family N

Code 5100030005000

Speed Fixed speed

Max Flow Rate 13,20 m³/h

H max 57,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 66,60 m³/h

Min head 53,00 m

kW 4,00 kW

Power consumption

Efficiency ---

Model BN 32-200A/A G

Family N

Code 5100030004000

Speed Fixed speed

Max Flow Rate 15,00 m³/h

H max 57,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 51,00 m

kW 4,00 kW

Power consumption

Efficiency ---

Model BN4 32-200B-60/A G

Family N

Code 5100028005000

Speed Fixed speed

Max Flow Rate 13,20 m³/h

H max 13,10 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 2,40 m³/h

Min head 5,70 m

kW 0,55 kW

Power consumption

Efficiency ---

Model BN4 32-200B/A G

Family N

Code 5100028004000

Speed Fixed speed

Max Flow Rate 13,20 m³/h

H max 12,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 2,40 m³/h

Min head 4,70 m

kW 0,55 kW

Power consumption

Efficiency ---

Model BN 32-200C-60/A G

Family N

Code 5100026005000

Speed Fixed speed

Max Flow Rate 16,80 m³/h

H max 45,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 34,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model BN 32-200C/A G

Family N

Code 5100026004000

Speed Fixed speed

Max Flow Rate 18,90 m³/h

H max 44,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 32,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model BN 32-200D-60-S/A G

Family N

Code 5100024007000

Speed Fixed speed

Max Flow Rate 13,20 m³/h

H max 39,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 32,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model BN 32-200D-S/A G

Family N

Code 5100024006000

Speed Fixed speed

Max Flow Rate 18,90 m³/h

H max 37,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 22,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model BN 32-200D-60/A G

Family N

Code 5100024005000

Speed Fixed speed

Max Flow Rate 10,80 m³/h

H max 39,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 35,00 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN 32-200D/A G

Family N

Code 5100024004000

Speed Fixed speed

Max Flow Rate 10,80 m³/h

H max 37,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 34,00 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN4 32-160A-60/A G

Family N

Code 5100022005000

Speed Fixed speed

Max Flow Rate 12,00 m³/h

H max 9,20 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 2,40 m³/h

Min head 5,40 m

kW 0,37 kW

Power consumption

Efficiency ---

Model BN4 32-160A/A G

Family N

Code 5100022004000

Speed Fixed speed

Max Flow Rate 12,00 m³/h

H max 9,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 2,40 m³/h

Min head 5,10 m

kW 0,37 kW

Power consumption

Efficiency ---

Model BN 32-160A-60-S/A G

Family N

Code 5100020007000

Speed Fixed speed

Max Flow Rate 16,80 m³/h

H max 36,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 29,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model BN 32-160A-S/A G

Family N

Code 5100020006000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 35,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 15,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model BN 32-160A-60/A G

Family N

Code 5100020005000

Speed Fixed speed

Max Flow Rate 12,00 m³/h

H max 36,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 33,00 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN 32-160A/A G

Family N

Code 5100020004000

Speed Fixed speed

Max Flow Rate 16,80 m³/h

H max 35,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 30,00 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN4 32-160B-60/A G

Family N

Code 5100018005000

Speed Fixed speed

Max Flow Rate 10,80 m³/h

H max 7,60 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 2,40 m³/h

Min head 4,40 m

kW 0,37 kW

Power consumption

Efficiency ---

Model BN4 32-160B/A G

Family N

Code 5100018004000

Speed Fixed speed

Max Flow Rate 10,80 m³/h

H max 7,60 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 2,40 m³/h

Min head 4,20 m

kW 0,37 kW

Power consumption

Efficiency ---

Model BN 32-160B-60-S/A G

Family N

Code 5100016007000

Speed Fixed speed

Max Flow Rate 16,80 m³/h

H max 31,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 23,00 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN 32-160B-S/A G

Family N

Code 5100016006000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 29,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 12,50 m

kW 2,20 kW

Power consumption

Efficiency ---

Model BN 32-160B-60/A G

Family N

Code 5100016005000

Speed Fixed speed

Max Flow Rate 10,80 m³/h

H max 31,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 29,00 m

kW 1,50 kW

Power consumption

Efficiency ---

Model BN 32-160B/A G

Family N

Code 5100016004000

Speed Fixed speed

Max Flow Rate 15,00 m³/h

H max 29,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 25,00 m

kW 1,50 kW

Power consumption

Efficiency ---

Model BN 32-125S-60/A G

Family N

Code 5100014005000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 25,20 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 12,00 m

kW 1,50 kW

Power consumption

Efficiency ---

Model BN 32-125S/A G

Family N

Code 5100014004000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 23,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 13,00 m

kW 1,50 kW

Power consumption

Efficiency ---

Model BN4 32-125A/A G

Family N

Code 5100012004000

Speed Fixed speed

Max Flow Rate 10,80 m³/h

H max 5,70 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 2,40 m³/h

Min head 4,30 m

kW 0,25 kW

Power consumption

Efficiency ---

Model BN 32-125A-60-S/A G

Family N

Code 5100010007000

Speed Fixed speed

Max Flow Rate 15,00 m³/h

H max 24,30 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 20,10 m

kW 1,50 kW

Power consumption

Efficiency ---

Model BN 32-125A-S/A G

Family N

Code 5100010006000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 23,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 10,00 m

kW 1,50 kW

Power consumption

Efficiency ---

Model BN 32-125A-60/A G

Family N

Code 5100010005000

Speed Fixed speed

Max Flow Rate 10,80 m³/h

H max 24,30 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 22,80 m

kW 1,10 kW

Power consumption

Efficiency ---

Model BN 32-125A/A G

Family N

Code 5100010004000

Speed Fixed speed

Max Flow Rate 13,20 m³/h

H max 23,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 20,50 m

kW 1,10 kW

Power consumption

Efficiency ---

Model BN4 32-125D/A G

Family N

Code 5100008004000

Speed Fixed speed

Max Flow Rate 10,80 m³/h

H max 4,70 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 2,40 m³/h

Min head 2,60 m

kW 0,25 kW

Power consumption

Efficiency ---

Model BN 32-125D-60-S/A G

Family N

Code 5100006007000

Speed Fixed speed

Max Flow Rate 15,00 m³/h

H max 18,80 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 14,40 m

kW 1,10 kW

Power consumption

Efficiency ---

Model BN 32-125D-S/A G

Family N

Code 5100006006000

Speed Fixed speed

Max Flow Rate 21,00 m³/h

H max 18,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 8,50 m

kW 1,10 kW

Power consumption

Efficiency ---

Model BN 32-125D-60/A G

Family N

Code 5100006005000

Speed Fixed speed

Max Flow Rate 10,80 m³/h

H max 18,80 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 17,20 m

kW 0,75 kW

Power consumption

Efficiency ---

Model BN 32-125D/A G

Family N

Code 5100006004000

Speed Fixed speed

Max Flow Rate 9,60 m³/h

H max 18,00 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 17,00 m

kW 0,75 kW

Power consumption

Efficiency ---

Model BN4 32-125F/A G

Family N

Code 5100004004000

Speed Fixed speed

Max Flow Rate 9,60 m³/h

H max 3,60 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 2,40 m³/h

Min head 1,10 m

kW 0,25 kW

Power consumption

Efficiency ---

Model BN 32-125F-60/A G

Family N

Code 5100002005000

Speed Fixed speed

Max Flow Rate 15,00 m³/h

H max 12,40 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 7,00 m

kW 0,55 kW

Power consumption

Efficiency ---

Model BN 32-125F/A G

Family N

Code 5100002004000

Speed Fixed speed

Max Flow Rate 16,80 m³/h

H max 12,50 m

Pump casing Bronze G-Cu Sn 10 EN 1982

Min Flow Rate 6,60 m³/h

Min head 6,00 m

kW 0,55 kW

Power consumption

Efficiency ---

Model N4 200-400A-60 G

Family N

Code 5000318005000

Speed Fixed speed

Max Flow Rate 900,00 m³/h

H max 59,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 180,00 m³/h

Min head 40,80 m

kW 132,00 kW

Power consumption

Efficiency ---

Model N4 200-400A G

Family N

Code 5000318004000

Speed Fixed speed

Max Flow Rate 900,00 m³/h

H max 58,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 180,00 m³/h

Min head 38,80 m

kW 132,00 kW

Power consumption

Efficiency ---

Model N4 200-400B-60 G

Family N

Code 5000316005000

Speed Fixed speed

Max Flow Rate 900,00 m³/h

H max 54,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 180,00 m³/h

Min head 34,60 m

kW 110,00 kW

Power consumption

Efficiency ---

Model N4 200-400B G

Family N

Code 5000316004000

Speed Fixed speed

Max Flow Rate 900,00 m³/h

H max 53,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 180,00 m³/h

Min head 34,30 m

kW 110,00 kW

Power consumption

Efficiency ---

Model N4 200-400C-60 G

Family N

Code 5000314005000

Speed Fixed speed

Max Flow Rate 900,00 m³/h

H max 48,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 180,00 m³/h

Min head 27,60 m

kW 90,00 kW

Power consumption

Efficiency ---

Model N4 200-400C G

Family N

Code 5000314004000

Speed Fixed speed

Max Flow Rate 900,00 m³/h

H max 47,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 180,00 m³/h

Min head 27,00 m

kW 90,00 kW

Power consumption

Efficiency ---

Model N 32L-200A-60 G

Family N

Code 5000312005000

Speed Fixed speed

Max Flow Rate 32,00 m³/h

H max 60,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 9,60 m³/h

Min head 35,30 m

kW 7,50 kW

Power consumption

Efficiency ---

Model N 32L-200A G

Family N

Code 5000312004000

Speed Fixed speed

Max Flow Rate 32,00 m³/h

H max 59,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 9,60 m³/h

Min head 37,70 m

kW 7,50 kW

Power consumption

Efficiency ---

Model N 32L-200B-60 G

Family N

Code 5000310005000

Speed Fixed speed

Max Flow Rate 29,00 m³/h

H max 52,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 9,60 m³/h

Min head 30,60 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N 32L-200B G

Family N

Code 5000310004000

Speed Fixed speed

Max Flow Rate 29,00 m³/h

H max 51,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 9,60 m³/h

Min head 33,50 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N 32L-200C-60 G

Family N

Code 5000309005000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 46,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 9,60 m³/h

Min head 25,60 m

kW 4,00 kW

Power consumption

Efficiency ---

Model N 32L-200C G

Family N

Code 5000309004000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 42,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 9,60 m³/h

Min head 23,80 m

kW 4,00 kW

Power consumption

Efficiency ---

Model N 32L-160A-60 G

Family N

Code 5000307005000

Speed Fixed speed

Max Flow Rate 32,00 m³/h

H max 38,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 9,60 m³/h

Min head 23,90 m

kW 4,00 kW

Power consumption

Efficiency ---

Model N 32L-160A G

Family N

Code 5000307004000

Speed Fixed speed

Max Flow Rate 32,00 m³/h

H max 39,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 9,60 m³/h

Min head 25,60 m

kW 4,00 kW

Power consumption

Efficiency ---

Model N 32L-160B-60 G

Family N

Code 5000305005000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 30,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 9,60 m³/h

Min head 20,10 m

kW 3,00 kW

Power consumption

Efficiency ---

Model N 32L-160B G

Family N

Code 5000305004000

Speed Fixed speed

Max Flow Rate 29,00 m³/h

H max 30,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 9,60 m³/h

Min head 17,90 m

kW 3,00 kW

Power consumption

Efficiency ---

Model N 32L-160C-60 G

Family N

Code 5000303005000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 26,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 9,60 m³/h

Min head 13,70 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N 32L-160C G

Family N

Code 5000303004000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 25,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 9,60 m³/h

Min head 13,40 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N4 150-400S-60 G

Family N

Code 5000302A05000

Speed Fixed speed

Max Flow Rate 660,00 m³/h

H max 60,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 132,00 m³/h

Min head 42,50 m

kW 90,00 kW

Power consumption

Efficiency ---

Model N4 150-400S G

Family N

Code 5000302A04000

Speed Fixed speed

Max Flow Rate 660,00 m³/h

H max 60,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 132,00 m³/h

Min head 37,60 m

kW 90,00 kW

Power consumption

Efficiency ---

Model N4 150-400A-60/B G

Family N

Code 5000302105000

Speed Fixed speed

Max Flow Rate 660,00 m³/h

H max 51,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 132,00 m³/h

Min head 32,70 m

kW 75,00 kW

Power consumption

Efficiency ---

Model N4 150-400A/B G

Family N

Code 5000302104000

Speed Fixed speed

Max Flow Rate 660,00 m³/h

H max 52,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 132,00 m³/h

Min head 32,20 m

kW 75,00 kW

Power consumption

Efficiency ---

Model N4 150-400B-60/B G

Family N

Code 5000300105000

Speed Fixed speed

Max Flow Rate 600,00 m³/h

H max 42,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 132,00 m³/h

Min head 27,10 m

kW 55,00 kW

Power consumption

Efficiency ---

Model N4 150-400B/B G

Family N

Code 5000300104000

Speed Fixed speed

Max Flow Rate 600,00 m³/h

H max 42,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 132,00 m³/h

Min head 25,40 m

kW 55,00 kW

Power consumption

Efficiency ---

Model N4 150-315S-60 G

Family N

Code 5000296A05000

Speed Fixed speed

Max Flow Rate 660,00 m³/h

H max 35,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 132,00 m³/h

Min head 19,80 m

kW 45,00 kW

Power consumption

Efficiency ---

Model N4 150-315S G

Family N

Code 5000296A04000

Speed Fixed speed

Max Flow Rate 660,00 m³/h

H max 34,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 132,00 m³/h

Min head 18,70 m

kW 45,00 kW

Power consumption

Efficiency ---

Model N4 150-315A-60/B G

Family N

Code 5000296105000

Speed Fixed speed

Max Flow Rate 600,00 m³/h

H max 30,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 132,00 m³/h

Min head 17,80 m

kW 37,00 kW

Power consumption

Efficiency ---

Model N4 150-315A/B G

Family N

Code 5000296104000

Speed Fixed speed

Max Flow Rate 600,00 m³/h

H max 29,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 132,00 m³/h

Min head 16,70 m

kW 37,00 kW

Power consumption

Efficiency ---

Model N4 150-315B-60/B G

Family N

Code 5000294105000

Speed Fixed speed

Max Flow Rate 480,00 m³/h

H max 26,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 132,00 m³/h

Min head 17,40 m

kW 30,00 kW

Power consumption

Efficiency ---

Model N4 150-315B/B G

Family N

Code 5000294104000

Speed Fixed speed

Max Flow Rate 540,00 m³/h

H max 25,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 132,00 m³/h

Min head 15,10 m

kW 30,00 kW

Power consumption

Efficiency ---

Model N4 150-315C-60/B G

Family N

Code 5000292005000

Speed Fixed speed

Max Flow Rate 480,00 m³/h

H max 29,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 132,00 m³/h

Min head 16,70 m

kW 22,00 kW

Power consumption

Efficiency ---

Model N4 150-315C/B G

Family N

Code 5000292004000

Speed Fixed speed

Max Flow Rate 480,00 m³/h

H max 30,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 132,00 m³/h

Min head 17,00 m

kW 22,00 kW

Power consumption

Efficiency ---

Model N4 150-315D-60/B G

Family N

Code 5000290005000

Speed Fixed speed

Max Flow Rate 450,00 m³/h

H max 20,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 132,00 m³/h

Min head 7,00 m

kW 18,50 kW

Power consumption

Efficiency ---

Model N4 150-315D/B G

Family N

Code 5000290004000

Speed Fixed speed

Max Flow Rate 450,00 m³/h

H max 20,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 132,00 m³/h

Min head 5,20 m

kW 18,50 kW

Power consumption

Efficiency ---

Model N4 125-400A-60/A G

Family N

Code 5000288005000

Speed Fixed speed

Max Flow Rate 330,00 m³/h

H max 59,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 84,00 m³/h

Min head 41,50 m

kW 55,00 kW

Power consumption

Efficiency ---

Model N4 125-400A/A G

Family N

Code 5000288004000

Speed Fixed speed

Max Flow Rate 330,00 m³/h

H max 59,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 84,00 m³/h

Min head 42,50 m

kW 55,00 kW

Power consumption

Efficiency ---

Model N4 125-400B-60/A G

Family N

Code 5000286005000

Speed Fixed speed

Max Flow Rate 330,00 m³/h

H max 51,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 84,00 m³/h

Min head 31,00 m

kW 45,00 kW

Power consumption

Efficiency ---

Model N4 125-400B/A G

Family N

Code 5000286004000

Speed Fixed speed

Max Flow Rate 330,00 m³/h

H max 51,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 84,00 m³/h

Min head 31,50 m

kW 45,00 kW

Power consumption

Efficiency ---

Model N4 125-400C-60/A G

Family N

Code 5000284005000

Speed Fixed speed

Max Flow Rate 300,00 m³/h

H max 45,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 84,00 m³/h

Min head 28,00 m

kW 37,00 kW

Power consumption

Efficiency ---

Model N4 125-400C/A G

Family N

Code 5000284004000

Speed Fixed speed

Max Flow Rate 330,00 m³/h

H max 45,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 84,00 m³/h

Min head 23,50 m

kW 37,00 kW

Power consumption

Efficiency ---

Model N4 125-315A-60/A G

Family N

Code 5000282005000

Speed Fixed speed

Max Flow Rate 330,00 m³/h

H max 37,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 84,00 m³/h

Min head 21,50 m

kW 30,00 kW

Power consumption

Efficiency ---

Model N4 125-315A/A G

Family N

Code 5000282004000

Speed Fixed speed

Max Flow Rate 330,00 m³/h

H max 36,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 84,00 m³/h

Min head 21,60 m

kW 30,00 kW

Power consumption

Efficiency ---

Model N4 125-315B-60/A G

Family N

Code 5000280005000

Speed Fixed speed

Max Flow Rate 330,00 m³/h

H max 32,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 84,00 m³/h

Min head 14,50 m

kW 22,00 kW

Power consumption

Efficiency ---

Model N4 125-315B/A G

Family N

Code 5000280004000

Speed Fixed speed

Max Flow Rate 330,00 m³/h

H max 31,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 84,00 m³/h

Min head 14,30 m

kW 22,00 kW

Power consumption

Efficiency ---

Model N4 125-315C-60/A G

Family N

Code 5000278005000

Speed Fixed speed

Max Flow Rate 300,00 m³/h

H max 28,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 84,00 m³/h

Min head 13,00 m

kW 18,50 kW

Power consumption

Efficiency ---

Model N4 125-315C/A G

Family N

Code 5000278004000

Speed Fixed speed

Max Flow Rate 330,00 m³/h

H max 27,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 84,00 m³/h

Min head 9,50 m

kW 18,50 kW

Power consumption

Efficiency ---

Model N4 125-250A-60/A G

Family N

Code 5000276005000

Speed Fixed speed

Max Flow Rate 330,00 m³/h

H max 23,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 84,00 m³/h

Min head 9,00 m

kW 15,00 kW

Power consumption

Efficiency ---

Model N4 125-250A/A G

Family N

Code 5000276004000

Speed Fixed speed

Max Flow Rate 330,00 m³/h

H max 22,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 84,00 m³/h

Min head 9,30 m

kW 15,00 kW

Power consumption

Efficiency ---

Model N4 125-250B-60/A G

Family N

Code 5000274005000

Speed Fixed speed

Max Flow Rate 300,00 m³/h

H max 19,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 84,00 m³/h

Min head 8,00 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N4 125-250B/A G

Family N

Code 5000274004000

Speed Fixed speed

Max Flow Rate 300,00 m³/h

H max 19,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 84,00 m³/h

Min head 8,20 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N4 125-250C-60/A G

Family N

Code 5000272005000

Speed Fixed speed

Max Flow Rate 300,00 m³/h

H max 16,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 84,00 m³/h

Min head 5,40 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N4 125-250D-60/A G

Family N

Code 5000270005000

Speed Fixed speed

Max Flow Rate 270,00 m³/h

H max 14,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 84,00 m³/h

Min head 5,00 m

kW 7,50 kW

Power consumption

Efficiency ---

Model N4 125-250D/A G

Family N

Code 5000270004000

Speed Fixed speed

Max Flow Rate 270,00 m³/h

H max 14,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 84,00 m³/h

Min head 5,10 m

kW 7,50 kW

Power consumption

Efficiency ---

Model N4 125-250E-60/A G

Family N

Code 5000268005000

Speed Fixed speed

Max Flow Rate 210,00 m³/h

H max 11,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 84,00 m³/h

Min head 6,20 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N4 125-250E/A G

Family N

Code 5000268004000

Speed Fixed speed

Max Flow Rate 240,00 m³/h

H max 11,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 84,00 m³/h

Min head 4,40 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N4 100-400A-60/A G

Family N

Code 5000266005000

Speed Fixed speed

Max Flow Rate 210,00 m³/h

H max 59,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 44,00 m

kW 37,00 kW

Power consumption

Efficiency ---

Model N4 100-400A/A G

Family N

Code 5000266004000

Speed Fixed speed

Max Flow Rate 210,00 m³/h

H max 58,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 44,00 m

kW 37,00 kW

Power consumption

Efficiency ---

Model N4 100-400B-60/A G

Family N

Code 5000264005000

Speed Fixed speed

Max Flow Rate 210,00 m³/h

H max 51,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 33,00 m

kW 30,00 kW

Power consumption

Efficiency ---

Model N4 100-400B/A G

Family N

Code 5000264004000

Speed Fixed speed

Max Flow Rate 210,00 m³/h

H max 50,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 33,50 m

kW 30,00 kW

Power consumption

Efficiency ---

Model N4 100-400C-60/A G

Family N

Code 5000262005000

Speed Fixed speed

Max Flow Rate 180,00 m³/h

H max 43,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 28,00 m

kW 22,00 kW

Power consumption

Efficiency ---

Model N4 100-400C/A G

Family N

Code 5000262004000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 41,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 26,00 m

kW 22,00 kW

Power consumption

Efficiency ---

Model N4 100-315A-60/A G

Family N

Code 5000260005000

Speed Fixed speed

Max Flow Rate 210,00 m³/h

H max 38,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 21,00 m

kW 18,50 kW

Power consumption

Efficiency ---

Model N4 100-315B-60/A G

Family N

Code 5000258005000

Speed Fixed speed

Max Flow Rate 210,00 m³/h

H max 32,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 13,50 m

kW 15,00 kW

Power consumption

Efficiency ---

Model N4 100-315B/A G

Family N

Code 5000258004000

Speed Fixed speed

Max Flow Rate 210,00 m³/h

H max 31,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 14,00 m

kW 15,00 kW

Power consumption

Efficiency ---

Model N4 100-315C-60/A G

Family N

Code 5000256005000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 28,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 10,00 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N4 100-315C/A G

Family N

Code 5000256004000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 26,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 11,30 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N4 100-250A-60/A G

Family N

Code 5000254005000

Speed Fixed speed

Max Flow Rate 210,00 m³/h

H max 22,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 8,80 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N4 100-250A/A G

Family N

Code 5000254004000

Speed Fixed speed

Max Flow Rate 210,00 m³/h

H max 22,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 8,90 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N 100-250A-60/A G

Family N

Code 5000252005000

Speed Fixed speed

Max Flow Rate 300,00 m³/h

H max 90,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 108,00 m³/h

Min head 67,00 m

kW 75,00 kW

Power consumption

Efficiency ---

Model N 100-250A/A G

Family N

Code 5000252004000

Speed Fixed speed

Max Flow Rate 300,00 m³/h

H max 91,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 108,00 m³/h

Min head 67,00 m

kW 75,00 kW

Power consumption

Efficiency ---

Model N4 100-250B-60/A G

Family N

Code 5000250005000

Speed Fixed speed

Max Flow Rate 210,00 m³/h

H max 19,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 5,50 m

kW 7,50 kW

Power consumption

Efficiency ---

Model N4 100-250B/A G

Family N

Code 5000250004000

Speed Fixed speed

Max Flow Rate 210,00 m³/h

H max 19,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 5,50 m

kW 7,50 kW

Power consumption

Efficiency ---

Model N 100-250B-60/A G

Family N

Code 5000248005000

Speed Fixed speed

Max Flow Rate 300,00 m³/h

H max 73,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 108,00 m³/h

Min head 48,00 m

kW 55,00 kW

Power consumption

Efficiency ---

Model N 100-250B/A G

Family N

Code 5000248004000

Speed Fixed speed

Max Flow Rate 300,00 m³/h

H max 73,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 108,00 m³/h

Min head 48,50 m

kW 55,00 kW

Power consumption

Efficiency ---

Model N4 100-200A-60/A G

Family N

Code 5000246005000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 14,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 5,50 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N4 100-200A/A G

Family N

Code 5000246004000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 15,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 6,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N 100-200A-60/A G

Family N

Code 5000244005000

Speed Fixed speed

Max Flow Rate 300,00 m³/h

H max 61,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 108,00 m³/h

Min head 42,00 m

kW 45,00 kW

Power consumption

Efficiency ---

Model N4 100-200B-60/A G

Family N

Code 5000242005000

Speed Fixed speed

Max Flow Rate 168,00 m³/h

H max 11,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 4,60 m

kW 4,00 kW

Power consumption

Efficiency ---

Model N4 100-200B/A G

Family N

Code 5000242004000

Speed Fixed speed

Max Flow Rate 168,00 m³/h

H max 12,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 4,50 m

kW 4,00 kW

Power consumption

Efficiency ---

Model N 100-200B-60/A G

Family N

Code 5000240005000

Speed Fixed speed

Max Flow Rate 270,00 m³/h

H max 54,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 108,00 m³/h

Min head 38,00 m

kW 37,00 kW

Power consumption

Efficiency ---

Model N4 100-200C-60/A G

Family N

Code 5000238005000

Speed Fixed speed

Max Flow Rate 150,00 m³/h

H max 9,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 4,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model N4 100-200C/A G

Family N

Code 5000238004000

Speed Fixed speed

Max Flow Rate 150,00 m³/h

H max 9,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 4,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model N 100-200C-60/A G

Family N

Code 5000236005000

Speed Fixed speed

Max Flow Rate 270,00 m³/h

H max 45,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 108,00 m³/h

Min head 28,00 m

kW 30,00 kW

Power consumption

Efficiency ---

Model N 100-200C/A G

Family N

Code 5000236004000

Speed Fixed speed

Max Flow Rate 300,00 m³/h

H max 45,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 108,00 m³/h

Min head 22,00 m

kW 30,00 kW

Power consumption

Efficiency ---

Model N 100-200D-60/A G

Family N

Code 5000234005000

Speed Fixed speed

Max Flow Rate 240,00 m³/h

H max 36,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 108,00 m³/h

Min head 24,00 m

kW 22,00 kW

Power consumption

Efficiency ---

Model N 100-200D/A G

Family N

Code 5000234004000

Speed Fixed speed

Max Flow Rate 270,00 m³/h

H max 36,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 108,00 m³/h

Min head 19,00 m

kW 22,00 kW

Power consumption

Efficiency ---

Model N 100-200E-60/A G

Family N

Code 5000232005000

Speed Fixed speed

Max Flow Rate 240,00 m³/h

H max 30,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 108,00 m³/h

Min head 19,00 m

kW 18,50 kW

Power consumption

Efficiency ---

Model N 100-200E/A G

Family N

Code 5000232004000

Speed Fixed speed

Max Flow Rate 240,00 m³/h

H max 30,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 108,00 m³/h

Min head 19,00 m

kW 18,50 kW

Power consumption

Efficiency ---

Model N4 80-400S-60 G

Family N

Code 5000230A05000

Speed Fixed speed

Max Flow Rate 180,00 m³/h

H max 64,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 36,80 m

kW 37,00 kW

Power consumption

Efficiency ---

Model N4 80-400S G

Family N

Code 5000230A04000

Speed Fixed speed

Max Flow Rate 180,00 m³/h

H max 61,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 39,20 m

kW 37,00 kW

Power consumption

Efficiency ---

Model N4 80-400A-60/B G

Family N

Code 5000230105000

Speed Fixed speed

Max Flow Rate 150,00 m³/h

H max 64,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 48,10 m

kW 30,00 kW

Power consumption

Efficiency ---

Model N4 80-400A/B G

Family N

Code 5000230104000

Speed Fixed speed

Max Flow Rate 150,00 m³/h

H max 61,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 49,50 m

kW 30,00 kW

Power consumption

Efficiency ---

Model N4 80-400B-60/B G

Family N

Code 5000228105000

Speed Fixed speed

Max Flow Rate 150,00 m³/h

H max 52,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 31,00 m

kW 22,00 kW

Power consumption

Efficiency ---

Model N4 80-400B/B G

Family N

Code 5000228104000

Speed Fixed speed

Max Flow Rate 150,00 m³/h

H max 48,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 30,50 m

kW 22,00 kW

Power consumption

Efficiency ---

Model N4 80-400C-60/B G

Family N

Code 5000226105000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 47,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 31,30 m

kW 18,50 kW

Power consumption

Efficiency ---

Model N4 80-400C/B G

Family N

Code 5000226104000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 42,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 29,10 m

kW 18,50 kW

Power consumption

Efficiency ---

Model N4 80-315S-60 G

Family N

Code 5000224A05000

Speed Fixed speed

Max Flow Rate 168,00 m³/h

H max 42,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 28,00 m

kW 18,50 kW

Power consumption

Efficiency ---

Model N4 80-315S G

Family N

Code 5000224A04000

Speed Fixed speed

Max Flow Rate 168,00 m³/h

H max 39,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 22,50 m

kW 18,50 kW

Power consumption

Efficiency ---

Model N4 80-315A-60/B G

Family N

Code 5000224105000

Speed Fixed speed

Max Flow Rate 168,00 m³/h

H max 36,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 20,60 m

kW 15,00 kW

Power consumption

Efficiency ---

Model N4 80-315A/B G

Family N

Code 5000224104000

Speed Fixed speed

Max Flow Rate 150,00 m³/h

H max 36,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 25,30 m

kW 15,00 kW

Power consumption

Efficiency ---

Model N4 80-315B-60/B G

Family N

Code 5000222105000

Speed Fixed speed

Max Flow Rate 150,00 m³/h

H max 31,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 17,50 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N4 80-315B/B G

Family N

Code 5000222104000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 30,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 22,00 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N4 80-315C-60/B G

Family N

Code 5000220105000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 26,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 16,20 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N4 80-315C/B G

Family N

Code 5000220104000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 25,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 15,90 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N4 80-250A-60/A G

Family N

Code 5000218005000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 24,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 12,70 m

kW 7,50 kW

Power consumption

Efficiency ---

Model N4 80-250A/A G

Family N

Code 5000218004000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 23,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 12,70 m

kW 7,50 kW

Power consumption

Efficiency ---

Model N 80-250A-60/A G

Family N

Code 5000216005000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 94,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 75,00 m³/h

Min head 76,50 m

kW 55,00 kW

Power consumption

Efficiency ---

Model N 80-250A/A G

Family N

Code 5000216004000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 95,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 75,00 m³/h

Min head 76,50 m

kW 55,00 kW

Power consumption

Efficiency ---

Model N4 80-250B-60/A G

Family N

Code 5000214005000

Speed Fixed speed

Max Flow Rate 120,00 m³/h

H max 20,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 11,50 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N4 80-250B/A G

Family N

Code 5000214004000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 20,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 9,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N 80-250B-60/A G

Family N

Code 5000212005000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 84,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 75,00 m³/h

Min head 62,50 m

kW 45,00 kW

Power consumption

Efficiency ---

Model N4 80-250C-60/A G

Family N

Code 5000210005000

Speed Fixed speed

Max Flow Rate 108,00 m³/h

H max 17,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 9,50 m

kW 4,00 kW

Power consumption

Efficiency ---

Model N4 80-250C/A G

Family N

Code 5000210004000

Speed Fixed speed

Max Flow Rate 120,00 m³/h

H max 16,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 7,20 m

kW 4,00 kW

Power consumption

Efficiency ---

Model N 80-250C-60/A G

Family N

Code 5000208005000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 73,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 75,00 m³/h

Min head 51,00 m

kW 37,00 kW

Power consumption

Efficiency ---

Model N 80-250C/A G

Family N

Code 5000208004000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 73,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 75,00 m³/h

Min head 51,50 m

kW 37,00 kW

Power consumption

Efficiency ---

Model N 80-250D-60/A G

Family N

Code 5000206005000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 65,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 75,00 m³/h

Min head 41,00 m

kW 30,00 kW

Power consumption

Efficiency ---

Model N 80-250E-60/A G

Family N

Code 5000204005000

Speed Fixed speed

Max Flow Rate 180,00 m³/h

H max 51,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 75,00 m³/h

Min head 29,00 m

kW 22,00 kW

Power consumption

Efficiency ---

Model N 80-250E/A G

Family N

Code 5000204004000

Speed Fixed speed

Max Flow Rate 180,00 m³/h

H max 51,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 75,00 m³/h

Min head 29,00 m

kW 22,00 kW

Power consumption

Efficiency ---

Model N4 80-200A-60/B G

Family N

Code 5000202105000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 14,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 7,70 m

kW 4,00 kW

Power consumption

Efficiency ---

Model N4 80-200A/B G

Family N

Code 5000202104000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 14,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 6,90 m

kW 4,00 kW

Power consumption

Efficiency ---

Model N 80-200A-60/B G

Family N

Code 5000200105000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 58,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 75,00 m³/h

Min head 47,80 m

kW 30,00 kW

Power consumption

Efficiency ---

Model N 80-200A/B G

Family N

Code 5000200104000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 56,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 75,00 m³/h

Min head 45,60 m

kW 30,00 kW

Power consumption

Efficiency ---

Model N4 80-200B-60/B G

Family N

Code 5000198105000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 12,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 4,50 m

kW 3,00 kW

Power consumption

Efficiency ---

Model N 80-200B-60/B G

Family N

Code 5000196105000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 43,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 75,00 m³/h

Min head 32,20 m

kW 22,00 kW

Power consumption

Efficiency ---

Model N 80-200B/B G

Family N

Code 5000196104000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 44,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 75,00 m³/h

Min head 32,40 m

kW 22,00 kW

Power consumption

Efficiency ---

Model N4 80-200C-60/B G

Family N

Code 5000194105000

Speed Fixed speed

Max Flow Rate 108,00 m³/h

H max 9,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 4,50 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N4 80-200C/B G

Family N

Code 5000194104000

Speed Fixed speed

Max Flow Rate 120,00 m³/h

H max 9,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 2,70 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N4 80-160A-60/B G

Family N

Code 5000192105000

Speed Fixed speed

Max Flow Rate 108,00 m³/h

H max 11,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 6,60 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N4 80-160A/B G

Family N

Code 5000192104000

Speed Fixed speed

Max Flow Rate 108,00 m³/h

H max 10,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 5,90 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N 80-160A-60/B G

Family N

Code 5000190105000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 41,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 75,00 m³/h

Min head 28,80 m

kW 18,50 kW

Power consumption

Efficiency ---

Model N 80-160A/B G

Family N

Code 5000190104000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 39,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 75,00 m³/h

Min head 28,10 m

kW 18,50 kW

Power consumption

Efficiency ---

Model N4 80-160B-60/B G

Family N

Code 5000188105000

Speed Fixed speed

Max Flow Rate 96,00 m³/h

H max 8,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 4,50 m

kW 1,50 kW

Power consumption

Efficiency ---

Model N4 80-160B/B G

Family N

Code 5000188104000

Speed Fixed speed

Max Flow Rate 96,00 m³/h

H max 7,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 4,10 m

kW 1,50 kW

Power consumption

Efficiency ---

Model N 80-160B-60/B G

Family N

Code 5000186105000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 35,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 75,00 m³/h

Min head 21,00 m

kW 15,00 kW

Power consumption

Efficiency ---

Model N 80-160B/B G

Family N

Code 5000186104000

Speed Fixed speed

Max Flow Rate 192,00 m³/h

H max 34,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 75,00 m³/h

Min head 22,40 m

kW 15,00 kW

Power consumption

Efficiency ---

Model N4 80-160C-60/B G

Family N

Code 5000184105000

Speed Fixed speed

Max Flow Rate 84,00 m³/h

H max 6,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 3,70 m

kW 1,10 kW

Power consumption

Efficiency ---

Model N4 80-160C/B G

Family N

Code 5000184104000

Speed Fixed speed

Max Flow Rate 84,00 m³/h

H max 6,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 3,30 m

kW 1,10 kW

Power consumption

Efficiency ---

Model N 80-160C-60/B G

Family N

Code 5000182105000

Speed Fixed speed

Max Flow Rate 180,00 m³/h

H max 30,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 75,00 m³/h

Min head 17,90 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N 80-160C/B G

Family N

Code 5000182104000

Speed Fixed speed

Max Flow Rate 180,00 m³/h

H max 28,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 75,00 m³/h

Min head 16,40 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N 80-160D-60/B G

Family N

Code 5000180105000

Speed Fixed speed

Max Flow Rate 168,00 m³/h

H max 26,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 75,00 m³/h

Min head 15,10 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N 80-160D/B G

Family N

Code 5000180104000

Speed Fixed speed

Max Flow Rate 168,00 m³/h

H max 25,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 75,00 m³/h

Min head 14,40 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N 80-160E-60/B G

Family N

Code 5000178105000

Speed Fixed speed

Max Flow Rate 168,00 m³/h

H max 23,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 75,00 m³/h

Min head 11,90 m

kW 7,50 kW

Power consumption

Efficiency ---

Model N 80-160E/B G

Family N

Code 5000178104000

Speed Fixed speed

Max Flow Rate 168,00 m³/h

H max 21,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 75,00 m³/h

Min head 10,60 m

kW 7,50 kW

Power consumption

Efficiency ---

Model N4 65-315A-60/A G

Family N

Code 5000176005000

Speed Fixed speed

Max Flow Rate 84,00 m³/h

H max 36,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 26,50 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N4 65-315A/A G

Family N

Code 5000176004000

Speed Fixed speed

Max Flow Rate 84,00 m³/h

H max 35,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 25,00 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N4 65-315B-60/A G

Family N

Code 5000174005000

Speed Fixed speed

Max Flow Rate 84,00 m³/h

H max 32,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 20,50 m

kW 7,50 kW

Power consumption

Efficiency ---

Model N4 65-315B/A G

Family N

Code 5000174004000

Speed Fixed speed

Max Flow Rate 84,00 m³/h

H max 31,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 18,60 m

kW 7,50 kW

Power consumption

Efficiency ---

Model N4 65-315C-60/A G

Family N

Code 5000172005000

Speed Fixed speed

Max Flow Rate 84,00 m³/h

H max 27,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 13,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N4 65-315C/A G

Family N

Code 5000172004000

Speed Fixed speed

Max Flow Rate 84,00 m³/h

H max 25,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 11,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N4 65-250A-60/B G

Family N

Code 5000170105000

Speed Fixed speed

Max Flow Rate 96,00 m³/h

H max 23,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 13,70 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N4 65-250A/B G

Family N

Code 5000170104000

Speed Fixed speed

Max Flow Rate 96,00 m³/h

H max 22,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 12,60 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N 65-250A-60/B G

Family N

Code 5000168105000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 87,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 74,50 m

kW 37,00 kW

Power consumption

Efficiency ---

Model N 65-250A/B G

Family N

Code 5000168104000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 86,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 74,50 m

kW 37,00 kW

Power consumption

Efficiency ---

Model N4 65-250B-60/B G

Family N

Code 5000166105000

Speed Fixed speed

Max Flow Rate 96,00 m³/h

H max 19,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 7,10 m

kW 4,00 kW

Power consumption

Efficiency ---

Model N4 65-250B/B G

Family N

Code 5000166104000

Speed Fixed speed

Max Flow Rate 96,00 m³/h

H max 17,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 7,00 m

kW 4,00 kW

Power consumption

Efficiency ---

Model N 65-250B-60/B G

Family N

Code 5000164105000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 74,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 60,50 m

kW 30,00 kW

Power consumption

Efficiency ---

Model N 65-250B/B G

Family N

Code 5000164104000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 73,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 59,00 m

kW 30,00 kW

Power consumption

Efficiency ---

Model N 65-250C-60/B G

Family N

Code 5000162105000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 63,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 43,00 m

kW 22,00 kW

Power consumption

Efficiency ---

Model N 65-250C/B G

Family N

Code 5000162104000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 61,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 43,00 m

kW 22,00 kW

Power consumption

Efficiency ---

Model N4 65-200A-60/B G

Family N

Code 5000160105000

Speed Fixed speed

Max Flow Rate 96,00 m³/h

H max 14,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 6,80 m

kW 3,00 kW

Power consumption

Efficiency ---

Model N4 65-200A/B G

Family N

Code 5000160104000

Speed Fixed speed

Max Flow Rate 96,00 m³/h

H max 14,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 7,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model N 65-200A-60/B G

Family N

Code 5000158105000

Speed Fixed speed

Max Flow Rate 141,00 m³/h

H max 58,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 45,50 m

kW 22,00 kW

Power consumption

Efficiency ---

Model N 65-200A/B G

Family N

Code 5000158104000

Speed Fixed speed

Max Flow Rate 141,00 m³/h

H max 57,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 45,50 m

kW 22,00 kW

Power consumption

Efficiency ---

Model N4 65-200B-60/B G

Family N

Code 5000156105000

Speed Fixed speed

Max Flow Rate 96,00 m³/h

H max 12,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 3,20 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N4 65-200B/B G

Family N

Code 5000156104000

Speed Fixed speed

Max Flow Rate 96,00 m³/h

H max 11,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 3,30 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N 65-200B-60/B G

Family N

Code 5000154105000

Speed Fixed speed

Max Flow Rate 141,00 m³/h

H max 52,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 38,70 m

kW 18,50 kW

Power consumption

Efficiency ---

Model N 65-200B/B G

Family N

Code 5000154104000

Speed Fixed speed

Max Flow Rate 141,00 m³/h

H max 50,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 37,50 m

kW 18,50 kW

Power consumption

Efficiency ---

Model N 65-200C-60/B G

Family N

Code 5000152105000

Speed Fixed speed

Max Flow Rate 141,00 m³/h

H max 45,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 30,40 m

kW 15,00 kW

Power consumption

Efficiency ---

Model N 65-200C/B G

Family N

Code 5000152104000

Speed Fixed speed

Max Flow Rate 141,00 m³/h

H max 44,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 28,80 m

kW 15,00 kW

Power consumption

Efficiency ---

Model N4 65-160S-60 G

Family N

Code 5000150A05000

Speed Fixed speed

Max Flow Rate 84,00 m³/h

H max 10,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 6,20 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N4 65-160S G

Family N

Code 5000150A04000

Speed Fixed speed

Max Flow Rate 84,00 m³/h

H max 10,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 5,70 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N4 65-160A-60/B G

Family N

Code 5000150105000

Speed Fixed speed

Max Flow Rate 75,00 m³/h

H max 8,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 5,70 m

kW 1,50 kW

Power consumption

Efficiency ---

Model N4 65-160A/B G

Family N

Code 5000150104000

Speed Fixed speed

Max Flow Rate 75,00 m³/h

H max 8,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 5,20 m

kW 1,50 kW

Power consumption

Efficiency ---

Model N 65-160AR-60 G

Family N

Code 5000148A05000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 35,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 28,50 m

kW 15,00 kW

Power consumption

Efficiency ---

Model N 65-160AR G

Family N

Code 5000148A04000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 36,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 27,50 m

kW 15,00 kW

Power consumption

Efficiency ---

Model N 65-160A-60/B G

Family N

Code 5000148105000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 40,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 33,20 m

kW 15,00 kW

Power consumption

Efficiency ---

Model N 65-160A/B G

Family N

Code 5000148104000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 40,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 31,70 m

kW 15,00 kW

Power consumption

Efficiency ---

Model N4 65-160B-60/B G

Family N

Code 5000146105000

Speed Fixed speed

Max Flow Rate 66,00 m³/h

H max 7,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 4,60 m

kW 1,10 kW

Power consumption

Efficiency ---

Model N4 65-160B/B G

Family N

Code 5000146104000

Speed Fixed speed

Max Flow Rate 66,00 m³/h

H max 7,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 4,50 m

kW 1,10 kW

Power consumption

Efficiency ---

Model N 65-160B-60/B G

Family N

Code 5000144105000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 32,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 24,40 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N 65-160B/B G

Family N

Code 5000144104000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 32,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 23,00 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N4 65-160C-60/B G

Family N

Code 5000142105000

Speed Fixed speed

Max Flow Rate 60,00 m³/h

H max 6,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 4,30 m

kW 1,10 kW

Power consumption

Efficiency ---

Model N4 65-160C/B G

Family N

Code 5000142104000

Speed Fixed speed

Max Flow Rate 60,00 m³/h

H max 6,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 4,20 m

kW 1,10 kW

Power consumption

Efficiency ---

Model N 65-160C-60/B G

Family N

Code 5000140105000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 27,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 19,00 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N 65-160C/B G

Family N

Code 5000140104000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 28,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 17,70 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N 65-160D-60/B G

Family N

Code 5000138105000

Speed Fixed speed

Max Flow Rate 120,00 m³/h

H max 24,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 17,60 m

kW 7,50 kW

Power consumption

Efficiency ---

Model N4 65-125A-60/B G

Family N

Code 5000134105000

Speed Fixed speed

Max Flow Rate 60,00 m³/h

H max 6,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 4,70 m

kW 1,10 kW

Power consumption

Efficiency ---

Model N4 65-125A/B G

Family N

Code 5000134104000

Speed Fixed speed

Max Flow Rate 60,00 m³/h

H max 6,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 4,40 m

kW 1,10 kW

Power consumption

Efficiency ---

Model N 65-125A-60/B G

Family N

Code 5000132105000

Speed Fixed speed

Max Flow Rate 120,00 m³/h

H max 26,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 37,80 m³/h

Min head 18,90 m

kW 7,50 kW

Power consumption

Efficiency ---

Model N 65-125A/B G

Family N

Code 5000132104000

Speed Fixed speed

Max Flow Rate 120,00 m³/h

H max 25,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 37,80 m³/h

Min head 17,60 m

kW 7,50 kW

Power consumption

Efficiency ---

Model N4 65-125C-60/B G

Family N

Code 5000130105000

Speed Fixed speed

Max Flow Rate 60,00 m³/h

H max 5,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 3,30 m

kW 0,75 kW

Power consumption

Efficiency ---

Model N4 65-125C/B G

Family N

Code 5000130104000

Speed Fixed speed

Max Flow Rate 60,00 m³/h

H max 5,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 3,00 m

kW 0,75 kW

Power consumption

Efficiency ---

Model N 65-125C-60/B G

Family N

Code 5000128105000

Speed Fixed speed

Max Flow Rate 120,00 m³/h

H max 21,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 37,80 m³/h

Min head 13,10 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N 65-125C/B G

Family N

Code 5000128104000

Speed Fixed speed

Max Flow Rate 120,00 m³/h

H max 21,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 37,80 m³/h

Min head 11,80 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N4 65-125E-60/B G

Family N

Code 5000126105000

Speed Fixed speed

Max Flow Rate 54,00 m³/h

H max 4,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 2,50 m

kW 0,75 kW

Power consumption

Efficiency ---

Model N4 65-125E/B G

Family N

Code 5000126104000

Speed Fixed speed

Max Flow Rate 54,00 m³/h

H max 4,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 2,30 m

kW 0,75 kW

Power consumption

Efficiency ---

Model N 65-125E-60/B G

Family N

Code 5000124105000

Speed Fixed speed

Max Flow Rate 108,00 m³/h

H max 16,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 37,80 m³/h

Min head 9,90 m

kW 4,00 kW

Power consumption

Efficiency ---

Model N 65-125E/B G

Family N

Code 5000124104000

Speed Fixed speed

Max Flow Rate 108,00 m³/h

H max 16,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 37,80 m³/h

Min head 9,20 m

kW 4,00 kW

Power consumption

Efficiency ---

Model N4 50-250A-60/A G

Family N

Code 5000122005000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 24,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 14,00 m

kW 4,00 kW

Power consumption

Efficiency ---

Model N4 50-250A/A G

Family N

Code 5000122004000

Speed Fixed speed

Max Flow Rate 48,00 m³/h

H max 22,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 9,00 m

kW 4,00 kW

Power consumption

Efficiency ---

Model N 50-250S/A G

Family N

Code 5000120A04000

Speed Fixed speed

Max Flow Rate 69,00 m³/h

H max 88,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 24,00 m³/h

Min head 68,50 m

kW 22,00 kW

Power consumption

Efficiency ---

Model N 50-250A-60/A G

Family N

Code 5000120005000

Speed Fixed speed

Max Flow Rate 66,00 m³/h

H max 87,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 24,00 m³/h

Min head 66,90 m

kW 18,50 kW

Power consumption

Efficiency ---

Model N 50-250A/A G

Family N

Code 5000120004000

Speed Fixed speed

Max Flow Rate 69,00 m³/h

H max 80,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 24,00 m³/h

Min head 58,50 m

kW 18,50 kW

Power consumption

Efficiency ---

Model N4 50-250B-60/A G

Family N

Code 5000118005000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 23,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 12,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model N4 50-250B/A G

Family N

Code 5000118004000

Speed Fixed speed

Max Flow Rate 48,00 m³/h

H max 20,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 5,80 m

kW 3,00 kW

Power consumption

Efficiency ---

Model N 50-250B-60/A G

Family N

Code 5000116005000

Speed Fixed speed

Max Flow Rate 66,00 m³/h

H max 74,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 24,00 m³/h

Min head 43,80 m

kW 15,00 kW

Power consumption

Efficiency ---

Model N 50-250B/A G

Family N

Code 5000116004000

Speed Fixed speed

Max Flow Rate 69,00 m³/h

H max 69,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 24,00 m³/h

Min head 43,00 m

kW 15,00 kW

Power consumption

Efficiency ---

Model N4 50-250D G

Family N

Code 5000114014000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 14,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 2,30 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N4 50-250C-60/A G

Family N

Code 5000114005000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 18,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 7,20 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N4 50-250C/A G

Family N

Code 5000114004000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 17,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 6,80 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N 50-250C-60/A G

Family N

Code 5000112005000

Speed Fixed speed

Max Flow Rate 60,00 m³/h

H max 61,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 24,00 m³/h

Min head 36,50 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N 50-250C/A G

Family N

Code 5000112004000

Speed Fixed speed

Max Flow Rate 69,00 m³/h

H max 55,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 24,00 m³/h

Min head 24,50 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N4 50-200A-60/A G

Family N

Code 5000110005000

Speed Fixed speed

Max Flow Rate 54,00 m³/h

H max 16,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 5,40 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N 50-200S/A G

Family N

Code 5000108A04000

Speed Fixed speed

Max Flow Rate 78,00 m³/h

H max 60,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 24,00 m³/h

Min head 37,00 m

kW 15,00 kW

Power consumption

Efficiency ---

Model N 50-200A-60/A G

Family N

Code 5000108005000

Speed Fixed speed

Max Flow Rate 75,00 m³/h

H max 57,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 24,00 m³/h

Min head 33,20 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N 50-200A/A G

Family N

Code 5000108004000

Speed Fixed speed

Max Flow Rate 78,00 m³/h

H max 55,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 24,00 m³/h

Min head 32,50 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N4 50-200B-60/A G

Family N

Code 5000106005000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 12,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 3,40 m

kW 1,50 kW

Power consumption

Efficiency ---

Model N4 50-200B/A G

Family N

Code 5000106004000

Speed Fixed speed

Max Flow Rate 48,00 m³/h

H max 13,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 3,70 m

kW 1,50 kW

Power consumption

Efficiency ---

Model N 50-200B-60/A G

Family N

Code 5000104005000

Speed Fixed speed

Max Flow Rate 69,00 m³/h

H max 51,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 24,00 m³/h

Min head 27,30 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N 50-200B/A G

Family N

Code 5000104004000

Speed Fixed speed

Max Flow Rate 78,00 m³/h

H max 48,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 24,00 m³/h

Min head 23,00 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N4 50-200C-60/A G

Family N

Code 5000102005000

Speed Fixed speed

Max Flow Rate 37,80 m³/h

H max 11,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 2,70 m

kW 1,10 kW

Power consumption

Efficiency ---

Model N4 50-200C/A G

Family N

Code 5000102004000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 11,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 4,70 m

kW 1,10 kW

Power consumption

Efficiency ---

Model N4 50-160A-60/A G

Family N

Code 5000100005000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 10,55 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 5,30 m

kW 1,10 kW

Power consumption

Efficiency ---

Model N4 50-160A/A G

Family N

Code 5000100004000

Speed Fixed speed

Max Flow Rate 48,00 m³/h

H max 9,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 3,10 m

kW 1,10 kW

Power consumption

Efficiency ---

Model N 50-160A-60/A G

Family N

Code 5000098005000

Speed Fixed speed

Max Flow Rate 84,00 m³/h

H max 41,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 20,40 m

kW 7,50 kW

Power consumption

Efficiency ---

Model N 50-160A/A G

Family N

Code 5000098004000

Speed Fixed speed

Max Flow Rate 81,00 m³/h

H max 38,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 19,00 m

kW 7,50 kW

Power consumption

Efficiency ---

Model N4 50-160B-60/A G

Family N

Code 5000096005000

Speed Fixed speed

Max Flow Rate 37,80 m³/h

H max 9,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 3,80 m

kW 1,10 kW

Power consumption

Efficiency ---

Model N4 50-160B/A G

Family N

Code 5000096004000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 8,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 3,30 m

kW 1,10 kW

Power consumption

Efficiency ---

Model N 50-160B-60-S/A G

Family N

Code 5000094007000

Speed Fixed speed

Max Flow Rate 75,00 m³/h

H max 35,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 15,10 m

kW 7,50 kW

Power consumption

Efficiency ---

Model N 50-160B-60/A G

Family N

Code 5000094005000

Speed Fixed speed

Max Flow Rate 37,80 m³/h

H max 35,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 33,60 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N 50-160B/A G

Family N

Code 5000094004000

Speed Fixed speed

Max Flow Rate 81,00 m³/h

H max 31,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 9,50 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N4 50-125S/A G

Family N

Code 5000092A04000

Speed Fixed speed

Max Flow Rate 37,80 m³/h

H max 6,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 3,80 m

kW 0,75 kW

Power consumption

Efficiency ---

Model N4 50-125A/A G

Family N

Code 5000092004000

Speed Fixed speed

Max Flow Rate 37,80 m³/h

H max 6,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 2,90 m

kW 0,75 kW

Power consumption

Efficiency ---

Model N 50-125S-S/A G

Family N

Code 5000090A06000

Speed Fixed speed

Max Flow Rate 81,00 m³/h

H max 26,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 11,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N 50-125S/A G

Family N

Code 5000090A04000

Speed Fixed speed

Max Flow Rate 54,00 m³/h

H max 26,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 22,00 m

kW 4,00 kW

Power consumption

Efficiency ---

Model N 50-125A-60-S/A G

Family N

Code 5000090007000

Speed Fixed speed

Max Flow Rate 75,00 m³/h

H max 24,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 13,60 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N 50-125A-60/A G

Family N

Code 5000090005000

Speed Fixed speed

Max Flow Rate 48,00 m³/h

H max 24,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 22,30 m

kW 4,00 kW

Power consumption

Efficiency ---

Model N 50-125A/A G

Family N

Code 5000090004000

Speed Fixed speed

Max Flow Rate 78,00 m³/h

H max 24,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 10,00 m

kW 4,00 kW

Power consumption

Efficiency ---

Model N4 50-125D/A G

Family N

Code 5000088004000

Speed Fixed speed

Max Flow Rate 33,00 m³/h

H max 5,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 2,50 m

kW 0,55 kW

Power consumption

Efficiency ---

Model N 50-125D-60/A G

Family N

Code 5000086005000

Speed Fixed speed

Max Flow Rate 66,00 m³/h

H max 19,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 8,40 m

kW 3,00 kW

Power consumption

Efficiency ---

Model N 50-125D/A G

Family N

Code 5000086004000

Speed Fixed speed

Max Flow Rate 72,00 m³/h

H max 20,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 8,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model N4 50-125F/A G

Family N

Code 5000084004000

Speed Fixed speed

Max Flow Rate 33,00 m³/h

H max 4,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 0,50 m

kW 0,37 kW

Power consumption

Efficiency ---

Model N 50-125F-60/A G

Family N

Code 5000082005000

Speed Fixed speed

Max Flow Rate 60,00 m³/h

H max 16,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 5,80 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N 50-125F/A G

Family N

Code 5000082004000

Speed Fixed speed

Max Flow Rate 66,00 m³/h

H max 15,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 6,00 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N4 40-250A-60/A G

Family N

Code 5000080005000

Speed Fixed speed

Max Flow Rate 30,00 m³/h

H max 25,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 5,40 m³/h

Min head 10,70 m

kW 3,00 kW

Power consumption

Efficiency ---

Model N4 40-250A/A G

Family N

Code 5000080004000

Speed Fixed speed

Max Flow Rate 30,00 m³/h

H max 22,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 5,40 m³/h

Min head 8,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model N 40-250A-60/A G

Family N

Code 5000078005000

Speed Fixed speed

Max Flow Rate 39,00 m³/h

H max 90,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 76,00 m

kW 15,00 kW

Power consumption

Efficiency ---

Model N 40-250A/A G

Family N

Code 5000078004000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 90,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 70,50 m

kW 15,00 kW

Power consumption

Efficiency ---

Model N4 40-250B-60/A G

Family N

Code 5000076005000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 22,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 5,40 m³/h

Min head 10,10 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N4 40-250B/A G

Family N

Code 5000076004000

Speed Fixed speed

Max Flow Rate 30,00 m³/h

H max 21,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 5,40 m³/h

Min head 5,00 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N 40-250B-60/A G

Family N

Code 5000074005000

Speed Fixed speed

Max Flow Rate 37,80 m³/h

H max 71,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 50,00 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N4 40-250C-60/A G

Family N

Code 5000072005000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 18,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 5,40 m³/h

Min head 4,40 m

kW 1,50 kW

Power consumption

Efficiency ---

Model N4 40-250C/A G

Family N

Code 5000072004000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 17,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 5,40 m³/h

Min head 2,80 m

kW 1,50 kW

Power consumption

Efficiency ---

Model N 40-250C-60/A G

Family N

Code 5000070005000

Speed Fixed speed

Max Flow Rate 33,00 m³/h

H max 65,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 49,00 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N 40-250C/A G

Family N

Code 5000070004000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 61,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 33,50 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N4 40-200A-60/A G

Family N

Code 5000068005000

Speed Fixed speed

Max Flow Rate 21,00 m³/h

H max 15,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 5,40 m³/h

Min head 9,30 m

kW 1,10 kW

Power consumption

Efficiency ---

Model N4 40-200A/A G

Family N

Code 5000068004000

Speed Fixed speed

Max Flow Rate 21,00 m³/h

H max 14,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 5,40 m³/h

Min head 10,00 m

kW 1,10 kW

Power consumption

Efficiency ---

Model N 40-200A-60/A G

Family N

Code 5000066005000

Speed Fixed speed

Max Flow Rate 37,80 m³/h

H max 59,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 38,50 m

kW 7,50 kW

Power consumption

Efficiency ---

Model N 40-200A/A G

Family N

Code 5000066004000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 57,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 35,00 m

kW 7,50 kW

Power consumption

Efficiency ---

Model N 40-200AR-60-S/A G

Family N

Code 5000064007000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 56,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 49,00 m

kW 7,50 kW

Power consumption

Efficiency ---

Model N 40-200AR-S/A G

Family N

Code 5000064006000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 55,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 49,00 m

kW 7,50 kW

Power consumption

Efficiency ---

Model N 40-200AR-60/A G

Family N

Code 5000064005000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 56,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 52,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N 40-200AR/A G

Family N

Code 5000064004000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 55,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 51,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N4 40-200B-60/A G

Family N

Code 5000062005000

Speed Fixed speed

Max Flow Rate 18,90 m³/h

H max 13,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 5,40 m³/h

Min head 7,80 m

kW 1,10 kW

Power consumption

Efficiency ---

Model N4 40-200B/A G

Family N

Code 5000062004000

Speed Fixed speed

Max Flow Rate 21,00 m³/h

H max 13,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 5,40 m³/h

Min head 7,00 m

kW 1,10 kW

Power consumption

Efficiency ---

Model N 40-200B-S/A G

Family N

Code 5000060006000

Speed Fixed speed

Max Flow Rate 37,80 m³/h

H max 50,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 30,50 m

kW 7,50 kW

Power consumption

Efficiency ---

Model N 40-200B-60/A G

Family N

Code 5000060005000

Speed Fixed speed

Max Flow Rate 33,00 m³/h

H max 52,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 35,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N 40-200B/A G

Family N

Code 5000060004000

Speed Fixed speed

Max Flow Rate 33,00 m³/h

H max 50,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 37,50 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N 40-200D-S/A G

Family N

Code 5000058016000

Speed Fixed speed

Max Flow Rate 37,80 m³/h

H max 39,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 14,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N 100-200B/A G

Family N

Code 5000240004000

Speed Fixed speed

Max Flow Rate 300,00 m³/h

H max 54,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 108,00 m³/h

Min head 32,00 m

kW 37,00 kW

Power consumption

Efficiency ---

Model N 40-200D/A G

Family N

Code 5000058014000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 39,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 30,50 m

kW 4,00 kW

Power consumption

Efficiency ---

Model N 40-200C-60-S/A G

Family N

Code 5000058007000

Speed Fixed speed

Max Flow Rate 21,00 m³/h

H max 44,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 36,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N 40-200C-S/A G

Family N

Code 5000058006000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 41,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 33,50 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N 40-200C-60/A G

Family N

Code 5000058005000

Speed Fixed speed

Max Flow Rate 21,00 m³/h

H max 44,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 41,00 m

kW 4,00 kW

Power consumption

Efficiency ---

Model N 40-200C/A G

Family N

Code 5000058004000

Speed Fixed speed

Max Flow Rate 21,00 m³/h

H max 41,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 38,00 m

kW 4,00 kW

Power consumption

Efficiency ---

Model N4 40-160A-60/A G

Family N

Code 5000056005000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 9,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 5,40 m³/h

Min head 5,80 m

kW 0,75 kW

Power consumption

Efficiency ---

Model N4 40-160A/A G

Family N

Code 5000056004000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 9,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 5,40 m³/h

Min head 3,50 m

kW 0,75 kW

Power consumption

Efficiency ---

Model N 40-160A-60-S/A G

Family N

Code 5000054007000

Speed Fixed speed

Max Flow Rate 45,00 m³/h

H max 37,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 23,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N 40-160A-S/A G

Family N

Code 5000054006000

Speed Fixed speed

Max Flow Rate 48,00 m³/h

H max 37,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 17,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N 40-160A-60/A G

Family N

Code 5000054005000

Speed Fixed speed

Max Flow Rate 33,00 m³/h

H max 37,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 31,80 m

kW 4,00 kW

Power consumption

Efficiency ---

Model N 40-160A/A G

Family N

Code 5000054004000

Speed Fixed speed

Max Flow Rate 37,80 m³/h

H max 37,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 27,00 m

kW 4,00 kW

Power consumption

Efficiency ---

Model N4 40-160B-60/A G

Family N

Code 5000052005000

Speed Fixed speed

Max Flow Rate 21,00 m³/h

H max 8,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 5,40 m³/h

Min head 4,60 m

kW 0,55 kW

Power consumption

Efficiency ---

Model N4 40-160B/A G

Family N

Code 5000052004000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 7,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 5,40 m³/h

Min head 2,70 m

kW 0,55 kW

Power consumption

Efficiency ---

Model N 40-160B-60/A G

Family N

Code 5000050005000

Speed Fixed speed

Max Flow Rate 39,00 m³/h

H max 31,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 18,10 m

kW 3,00 kW

Power consumption

Efficiency ---

Model N 40-160B/A G

Family N

Code 5000050004000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 29,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 14,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model N4 40-160C-60/A G

Family N

Code 5000048005000

Speed Fixed speed

Max Flow Rate 18,90 m³/h

H max 6,75 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 5,40 m³/h

Min head 3,20 m

kW 0,37 kW

Power consumption

Efficiency ---

Model N4 40-160C/A G

Family N

Code 5000048004000

Speed Fixed speed

Max Flow Rate 21,00 m³/h

H max 6,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 5,40 m³/h

Min head 2,30 m

kW 0,37 kW

Power consumption

Efficiency ---

Model N 40-160C-60-S/A G

Family N

Code 5000046007000

Speed Fixed speed

Max Flow Rate 37,80 m³/h

H max 25,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 10,60 m

kW 3,00 kW

Power consumption

Efficiency ---

Model N 40-160C-60/A G

Family N

Code 5000046005000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 25,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 22,10 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N 40-160C/A G

Family N

Code 5000046004000

Speed Fixed speed

Max Flow Rate 39,00 m³/h

H max 23,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 10,00 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N 40-125A-60/A G

Family N

Code 5000042005000

Speed Fixed speed

Max Flow Rate 39,00 m³/h

H max 22,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 12,90 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N 40-125A/A G

Family N

Code 5000042004000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 22,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 11,50 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N 40-125C-60/A G

Family N

Code 5000038005000

Speed Fixed speed

Max Flow Rate 37,80 m³/h

H max 18,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 6,90 m

kW 1,50 kW

Power consumption

Efficiency ---

Model N 40-125C/A G

Family N

Code 5000038004000

Speed Fixed speed

Max Flow Rate 39,00 m³/h

H max 17,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 6,50 m

kW 1,50 kW

Power consumption

Efficiency ---

Model N 40-125F-60/A G

Family N

Code 5000034005000

Speed Fixed speed

Max Flow Rate 33,00 m³/h

H max 15,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 5,60 m

kW 1,10 kW

Power consumption

Efficiency ---

Model N 40-125F/A G

Family N

Code 5000034004000

Speed Fixed speed

Max Flow Rate 33,00 m³/h

H max 14,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 6,00 m

kW 1,10 kW

Power consumption

Efficiency ---

Model N4 32-200A-60/A G

Family N

Code 5000032005000

Speed Fixed speed

Max Flow Rate 13,20 m³/h

H max 14,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,40 m³/h

Min head 8,50 m

kW 0,75 kW

Power consumption

Efficiency ---

Model N4 32-200A/A G

Family N

Code 5000032004000

Speed Fixed speed

Max Flow Rate 13,20 m³/h

H max 14,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,40 m³/h

Min head 7,50 m

kW 0,75 kW

Power consumption

Efficiency ---

Model N 32-200A-60-S/A G

Family N

Code 5000030007000

Speed Fixed speed

Max Flow Rate 16,80 m³/h

H max 57,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 49,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N 32-200A-S/A G

Family N

Code 5000030006000

Speed Fixed speed

Max Flow Rate 18,90 m³/h

H max 57,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 46,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model N 32-200A-60/A G

Family N

Code 5000030005000

Speed Fixed speed

Max Flow Rate 13,20 m³/h

H max 57,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 53,00 m

kW 4,00 kW

Power consumption

Efficiency ---

Model N 32-200A/A G

Family N

Code 5000030004000

Speed Fixed speed

Max Flow Rate 15,00 m³/h

H max 57,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 51,00 m

kW 4,00 kW

Power consumption

Efficiency ---

Model N4 32-200B-60/A G

Family N

Code 5000028005000

Speed Fixed speed

Max Flow Rate 13,20 m³/h

H max 13,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,40 m³/h

Min head 5,70 m

kW 0,55 kW

Power consumption

Efficiency ---

Model N4 32-200B/A G

Family N

Code 5000028004000

Speed Fixed speed

Max Flow Rate 13,20 m³/h

H max 12,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,40 m³/h

Min head 4,70 m

kW 0,55 kW

Power consumption

Efficiency ---

Model N 32-200C-60/A G

Family N

Code 5000026005000

Speed Fixed speed

Max Flow Rate 16,80 m³/h

H max 45,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 34,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model N 32-200C/A G

Family N

Code 5000026004000

Speed Fixed speed

Max Flow Rate 18,90 m³/h

H max 44,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 32,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model N 32-200D-60-S/A G

Family N

Code 5000024007000

Speed Fixed speed

Max Flow Rate 13,20 m³/h

H max 39,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 32,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model N 32-200D-S/A G

Family N

Code 5000024006000

Speed Fixed speed

Max Flow Rate 18,90 m³/h

H max 37,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 22,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model N 32-200D-60/A G

Family N

Code 5000024005000

Speed Fixed speed

Max Flow Rate 10,80 m³/h

H max 39,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 35,00 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N 32-200D/A G

Family N

Code 5000024004000

Speed Fixed speed

Max Flow Rate 10,80 m³/h

H max 37,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 34,00 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N4 32-160A-60/A G

Family N

Code 5000022005000

Speed Fixed speed

Max Flow Rate 12,00 m³/h

H max 9,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,40 m³/h

Min head 5,40 m

kW 0,37 kW

Power consumption

Efficiency ---

Model N4 32-160A/A G

Family N

Code 5000022004000

Speed Fixed speed

Max Flow Rate 12,00 m³/h

H max 9,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,40 m³/h

Min head 5,10 m

kW 0,37 kW

Power consumption

Efficiency ---

Model N 32-160A-60-S/A G

Family N

Code 5000020007000

Speed Fixed speed

Max Flow Rate 16,80 m³/h

H max 36,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 29,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model N 32-160A-S/A G

Family N

Code 5000020006000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 35,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 15,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model N 32-160A-60/A G

Family N

Code 5000020005000

Speed Fixed speed

Max Flow Rate 12,00 m³/h

H max 36,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 33,00 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N 32-160A/A G

Family N

Code 5000020004000

Speed Fixed speed

Max Flow Rate 16,80 m³/h

H max 35,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 30,00 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N 65-160D/B G

Family N

Code 5000138104000

Speed Fixed speed

Max Flow Rate 120,00 m³/h

H max 24,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 16,30 m

kW 7,50 kW

Power consumption

Efficiency ---

Model N4 32-160B-60/A G

Family N

Code 5000018005000

Speed Fixed speed

Max Flow Rate 10,80 m³/h

H max 7,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,40 m³/h

Min head 4,40 m

kW 0,37 kW

Power consumption

Efficiency ---

Model N4 32-160B/A G

Family N

Code 5000018004000

Speed Fixed speed

Max Flow Rate 10,80 m³/h

H max 7,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,40 m³/h

Min head 4,20 m

kW 0,37 kW

Power consumption

Efficiency ---

Model N 32-160B-60-S/A G

Family N

Code 5000016007000

Speed Fixed speed

Max Flow Rate 16,80 m³/h

H max 31,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 23,00 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N 32-160B-S/A G

Family N

Code 5000016006000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 29,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 12,50 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N 32-160B-60/A G

Family N

Code 5000016005000

Speed Fixed speed

Max Flow Rate 10,80 m³/h

H max 31,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 29,00 m

kW 1,50 kW

Power consumption

Efficiency ---

Model N 32-160B/A G

Family N

Code 5000016004000

Speed Fixed speed

Max Flow Rate 15,00 m³/h

H max 29,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 25,00 m

kW 1,50 kW

Power consumption

Efficiency ---

Model N 32-125S-60/A G

Family N

Code 5000014005000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 25,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 12,00 m

kW 1,50 kW

Power consumption

Efficiency ---

Model N 32-125S/A G

Family N

Code 5000014004000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 23,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 13,00 m

kW 1,50 kW

Power consumption

Efficiency ---

Model N4 32-125A/A G

Family N

Code 5000012004000

Speed Fixed speed

Max Flow Rate 10,80 m³/h

H max 5,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,40 m³/h

Min head 4,30 m

kW 0,25 kW

Power consumption

Efficiency ---

Model N 32-125A-60-S/A G

Family N

Code 5000010007000

Speed Fixed speed

Max Flow Rate 15,00 m³/h

H max 24,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 20,10 m

kW 1,50 kW

Power consumption

Efficiency ---

Model N 32-125A-S/A G

Family N

Code 5000010006000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 23,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 10,00 m

kW 1,50 kW

Power consumption

Efficiency ---

Model N 32-125A-60/A G

Family N

Code 5000010005000

Speed Fixed speed

Max Flow Rate 10,80 m³/h

H max 24,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 22,80 m

kW 1,10 kW

Power consumption

Efficiency ---

Model N 32-125A/A G

Family N

Code 5000010004000

Speed Fixed speed

Max Flow Rate 13,20 m³/h

H max 23,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 20,50 m

kW 1,10 kW

Power consumption

Efficiency ---

Model N4 32-125D/A G

Family N

Code 5000008004000

Speed Fixed speed

Max Flow Rate 10,80 m³/h

H max 4,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,40 m³/h

Min head 2,60 m

kW 0,25 kW

Power consumption

Efficiency ---

Model N 32-125D-60-S/A G

Family N

Code 5000006007000

Speed Fixed speed

Max Flow Rate 15,00 m³/h

H max 18,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 14,40 m

kW 1,10 kW

Power consumption

Efficiency ---

Model N 32-125D-S/A G

Family N

Code 5000006006000

Speed Fixed speed

Max Flow Rate 21,00 m³/h

H max 18,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 8,50 m

kW 1,10 kW

Power consumption

Efficiency ---

Model N 32-125D-60/A G

Family N

Code 5000006005000

Speed Fixed speed

Max Flow Rate 10,80 m³/h

H max 18,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 17,20 m

kW 0,75 kW

Power consumption

Efficiency ---

Model N 32-125D/A G

Family N

Code 5000006004000

Speed Fixed speed

Max Flow Rate 9,60 m³/h

H max 18,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 17,00 m

kW 0,75 kW

Power consumption

Efficiency ---

Model N4 32-125F/A G

Family N

Code 5000004004000

Speed Fixed speed

Max Flow Rate 9,60 m³/h

H max 3,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,40 m³/h

Min head 1,10 m

kW 0,25 kW

Power consumption

Efficiency ---

Model N 32-125F-60/A G

Family N

Code 5000002005000

Speed Fixed speed

Max Flow Rate 15,00 m³/h

H max 12,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 7,00 m

kW 0,55 kW

Power consumption

Efficiency ---

Model N 32-125F/A G

Family N

Code 5000002004000

Speed Fixed speed

Max Flow Rate 16,80 m³/h

H max 12,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 6,00 m

kW 0,55 kW

Power consumption

Efficiency ---

Model N 40-250B/A G

Family N

Code 5000074004000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 69,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 45,00 m

kW 11,00 kW

Power consumption

Efficiency ---

Model N4 50-200A/A G

Family N

Code 5000110004000

Speed Fixed speed

Max Flow Rate 48,00 m³/h

H max 14,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 6,00 m

kW 2,20 kW

Power consumption

Efficiency ---

Model N 100-200A/A G

Family N

Code 5000244004000

Speed Fixed speed

Max Flow Rate 300,00 m³/h

H max 61,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 108,00 m³/h

Min head 42,00 m

kW 45,00 kW

Power consumption

Efficiency ---

Model N4 100-315A/A G

Family N

Code 5000260004000

Speed Fixed speed

Max Flow Rate 210,00 m³/h

H max 36,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 22,20 m

kW 18,50 kW

Power consumption

Efficiency ---

Model N4 200-315A

Family N

Code 5000324000000

Speed Fixed speed

Max Flow Rate 900,00 m³/h

H max 37,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 180,00 m³/h

Min head 20,30 m

kW 75,00 kW

Power consumption

Efficiency ---

Model N4 200-315B

Family N

Code 5000322000000

Speed Fixed speed

Max Flow Rate 810,00 m³/h

H max 33,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 180,00 m³/h

Min head 20,50 m

kW 55,00 kW

Power consumption

Efficiency ---

Model N4 200-315C

Family N

Code 5000320000000

Speed Fixed speed

Max Flow Rate 810,00 m³/h

H max 28,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 180,00 m³/h

Min head 15,70 m

kW 45,00 kW

Power consumption

Efficiency ---

Model N4 200-315A-60

Family N

Code 5000324001000

Speed Fixed speed

Max Flow Rate 900,00 m³/h

H max 38,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 180,00 m³/h

Min head 23,40 m

kW 75,00 kW

Power consumption

Efficiency ---

Model N4 200-315B-60

Family N

Code 5000322001000

Speed Fixed speed

Max Flow Rate 810,00 m³/h

H max 32,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 180,00 m³/h

Min head 21,20 m

kW 55,00 kW

Power consumption

Efficiency ---

Model N4 200-315C-60

Family N

Code 5000320001000

Speed Fixed speed

Max Flow Rate 600,00 m³/h

H max 27,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 180,00 m³/h

Min head 21,30 m

kW 45,00 kW

Power consumption

Efficiency ---

Model N4 200-315C G

Family N

Code 5000320004000

Speed Fixed speed

Max Flow Rate 810,00 m³/h

H max 28,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 180,00 m³/h

Min head 15,70 m

kW 45,00 kW

Power consumption

Efficiency ---

Model N4 200-315C-60 G

Family N

Code 5000320005000

Speed Fixed speed

Max Flow Rate 600,00 m³/h

H max 27,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 180,00 m³/h

Min head 21,30 m

kW 45,00 kW

Power consumption

Efficiency ---

Model N4 200-315B G

Family N

Code 5000322004000

Speed Fixed speed

Max Flow Rate 810,00 m³/h

H max 33,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 180,00 m³/h

Min head 20,50 m

kW 55,00 kW

Power consumption

Efficiency ---

Model N4 200-315B-60 G

Family N

Code 5000322005000

Speed Fixed speed

Max Flow Rate 810,00 m³/h

H max 32,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 180,00 m³/h

Min head 21,20 m

kW 55,00 kW

Power consumption

Efficiency ---

Model N4 200-315A G

Family N

Code 5000324004000

Speed Fixed speed

Max Flow Rate 900,00 m³/h

H max 37,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 180,00 m³/h

Min head 20,30 m

kW 75,00 kW

Power consumption

Efficiency ---

Model N4 200-315A-60 G

Family N

Code 5000324005000

Speed Fixed speed

Max Flow Rate 900,00 m³/h

H max 38,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 180,00 m³/h

Min head 23,40 m

kW 75,00 kW

Power consumption

Efficiency ---

Filters for

Results N

Filters for

Filters for
