Pump Selector - Calpeda Spa

Model NRD 50/125F-60

Family NR

Code 70MC0500001

Speed Fixed speed

Max Flow Rate 33,00 m³/h

H max 13,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 6,00 m

kW 1,10 kW

Power consumption

Efficiency ---

Model NRD 50/125C-60

Family NR

Code 70MC0540001

Speed Fixed speed

Max Flow Rate 33,00 m³/h

H max 18,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 10,20 m

kW 1,50 kW

Power consumption

Efficiency ---

Model NRD 50/125A-60

Family NR

Code 70MC0580001

Speed Fixed speed

Max Flow Rate 39,00 m³/h

H max 23,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 11,70 m

kW 2,20 kW

Power consumption

Efficiency ---

Model NRD 50/160B-60

Family NR

Code 70MC0660001

Speed Fixed speed

Max Flow Rate 39,00 m³/h

H max 25,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 11,20 m

kW 3,00 kW

Power consumption

Efficiency ---

Model NRD 50/160A-60

Family NR

Code 70MC0720001

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 35,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 18,50 m

kW 4,00 kW

Power consumption

Efficiency ---

Model NRD 65/125F-60

Family NR

Code 70MC1020001

Speed Fixed speed

Max Flow Rate 60,00 m³/h

H max 14,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 4,90 m

kW 2,20 kW

Power consumption

Efficiency ---

Model NRD 65/125D-60

Family NR

Code 70MC1060001

Speed Fixed speed

Max Flow Rate 60,00 m³/h

H max 18,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 8,90 m

kW 3,00 kW

Power consumption

Efficiency ---

Model NRD 65/125A-60

Family NR

Code 70MC1120001

Speed Fixed speed

Max Flow Rate 60,00 m³/h

H max 25,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 15,60 m

kW 4,00 kW

Power consumption

Efficiency ---

Model NRD 50/160C-60

Family NR

Code 70MC0620001

Speed Fixed speed

Max Flow Rate 39,00 m³/h

H max 22,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 7,80 m

kW 2,20 kW

Power consumption

Efficiency ---

Model NRD 50/125F

Family NR

Code 70MC0500000

Speed Fixed speed

Max Flow Rate 33,00 m³/h

H max 13,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 4,80 m

kW 1,10 kW

Power consumption

Efficiency ---

Model NRD 50/125C

Family NR

Code 70MC0540000

Speed Fixed speed

Max Flow Rate 39,00 m³/h

H max 17,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 5,90 m

kW 1,50 kW

Power consumption

Efficiency ---

Model NRD 50/125A

Family NR

Code 70MC0580000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 21,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 8,30 m

kW 2,20 kW

Power consumption

Efficiency ---

Model NRD 50/160C

Family NR

Code 70MC0620000

Speed Fixed speed

Max Flow Rate 39,00 m³/h

H max 22,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 7,80 m

kW 2,20 kW

Power consumption

Efficiency ---

Model NRD 50/160B

Family NR

Code 70MC0660000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 25,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 7,50 m

kW 3,00 kW

Power consumption

Efficiency ---

Model NRD 50/160A

Family NR

Code 70MC0720000

Speed Fixed speed

Max Flow Rate 45,00 m³/h

H max 34,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 15,60 m

kW 4,00 kW

Power consumption

Efficiency ---

Model NRD 65/125D

Family NR

Code 70MC1060000

Speed Fixed speed

Max Flow Rate 66,00 m³/h

H max 19,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 4,30 m

kW 3,00 kW

Power consumption

Efficiency ---

Model NRD 65/125A

Family NR

Code 70MC1120000

Speed Fixed speed

Max Flow Rate 69,00 m³/h

H max 25,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 9,90 m

kW 4,00 kW

Power consumption

Efficiency ---

Model NRD 65/125F

Family NR

Code 70MC1020000

Speed Fixed speed

Max Flow Rate 60,00 m³/h

H max 14,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 3,90 m

kW 2,20 kW

Power consumption

Efficiency ---

Model NRD4 50/160C-60

Family NR

Code 70MD0620001

Speed Fixed speed

Max Flow Rate 18,90 m³/h

H max 6,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 5,40 m³/h

Min head 2,80 m

kW 0,37 kW

Power consumption

Efficiency ---

Model NRD4 50/160B-60

Family NR

Code 70MD0660001

Speed Fixed speed

Max Flow Rate 21,00 m³/h

H max 8,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 5,40 m³/h

Min head 3,70 m

kW 0,55 kW

Power consumption

Efficiency ---

Model NRD4 50/160A-60

Family NR

Code 70MD0700001

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 10,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 5,40 m³/h

Min head 4,30 m

kW 0,75 kW

Power consumption

Efficiency ---

Model NRD4 65/125F

Family NR

Code 70MD1020000

Speed Fixed speed

Max Flow Rate 30,00 m³/h

H max 4,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 1,30 m

kW 0,37 kW

Power consumption

Efficiency ---

Model NRD4 65/125F-60

Family NR

Code 70MD1020001

Speed Fixed speed

Max Flow Rate 30,00 m³/h

H max 4,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 1,50 m

kW 0,37 kW

Power consumption

Efficiency ---

Model NRD4 65/125D-60

Family NR

Code 70MD1060001

Speed Fixed speed

Max Flow Rate 33,00 m³/h

H max 4,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 1,80 m

kW 0,55 kW

Power consumption

Efficiency ---

Model NRD4 65/125A-60

Family NR

Code 70MD1120001

Speed Fixed speed

Max Flow Rate 37,80 m³/h

H max 6,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 2,30 m

kW 0,75 kW

Power consumption

Efficiency ---

Model NRD4 50/160C

Family NR

Code 70MD0620000

Speed Fixed speed

Max Flow Rate 18,90 m³/h

H max 5,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 5,40 m³/h

Min head 2,10 m

kW 0,37 kW

Power consumption

Efficiency ---

Model NRD4 50/160B

Family NR

Code 70MD0660000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 7,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 5,40 m³/h

Min head 1,30 m

kW 0,55 kW

Power consumption

Efficiency ---

Model NRD4 65/125A

Family NR

Code 70MD1120000

Speed Fixed speed

Max Flow Rate 37,80 m³/h

H max 6,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 2,00 m

kW 0,75 kW

Power consumption

Efficiency ---

Model NRD4 65/125D

Family NR

Code 70MD1060000

Speed Fixed speed

Max Flow Rate 33,00 m³/h

H max 5,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 1,70 m

kW 0,55 kW

Power consumption

Efficiency ---

Model NRD4 50/160A

Family NR

Code 70MD0700000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 9,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 5,40 m³/h

Min head 2,10 m

kW 0,75 kW

Power consumption

Efficiency ---

Model NRD4 65/160B

Family NR

Code 70MD1180000

Speed Fixed speed

Max Flow Rate 37,80 m³/h

H max 8,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 2,50 m

kW 1,10 kW

Power consumption

Efficiency ---

Model NRD4 65/160B-60

Family NR

Code 70MD1180001

Speed Fixed speed

Max Flow Rate 37,80 m³/h

H max 9,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 3,20 m

kW 1,10 kW

Power consumption

Efficiency ---

Model NRD4 65/160A

Family NR

Code 70MD1220000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 9,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 2,60 m

kW 1,10 kW

Power consumption

Efficiency ---

Model NRD4 65/160A-60

Family NR

Code 70MD1220001

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 10,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 4,00 m

kW 1,10 kW

Power consumption

Efficiency ---

Model NRD 65/160B

Family NR

Code 70MC1200000

Speed Fixed speed

Max Flow Rate 72,00 m³/h

H max 31,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 10,40 m

kW 5,50 kW

Power consumption

Efficiency ---

Model NRD 65/160B-60

Family NR

Code 70MC1200001

Speed Fixed speed

Max Flow Rate 60,00 m³/h

H max 31,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 19,20 m

kW 5,50 kW

Power consumption

Efficiency ---

Model NRD 65/160A-60

Family NR

Code 70MC1240001

Speed Fixed speed

Max Flow Rate 66,00 m³/h

H max 40,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 25,40 m

kW 7,50 kW

Power consumption

Efficiency ---

Model NRD 65/160A

Family NR

Code 70MC1240000

Speed Fixed speed

Max Flow Rate 72,00 m³/h

H max 37,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 18,50 m

kW 7,50 kW

Power consumption

Efficiency ---

Model NR 50/125C/A

Family NR

Code 70MA054100000

Speed Fixed speed

Max Flow Rate 39,00 m³/h

H max 17,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 8,30 m

kW 1,50 kW

Power consumption

Efficiency ---

Model NR 40/160A/A

Family NR

Code 70MA032100000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 32,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 19,40 m

kW 2,20 kW

Power consumption

Efficiency ---

Model NR 50/160A/B

Family NR

Code 70MA072200000

Speed Fixed speed

Max Flow Rate 45,00 m³/h

H max 35,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 19,10 m

kW 4,00 kW

Power consumption

Efficiency ---

Model NR 65/200A/A

Family NR

Code 70MA136100000

Speed Fixed speed

Max Flow Rate 66,00 m³/h

H max 53,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 34,50 m

kW 11,00 kW

Power consumption

Efficiency ---

Model NRM 40/125B

Family NR

Code 70NA024000000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 19,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 8,50 m

kW 1,10 kW

Power consumption

Efficiency ---

Model NR 32/200A

Family NR

Code 70MA015000000

Speed Fixed speed

Max Flow Rate 15,00 m³/h

H max 49,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 3,00 m³/h

Min head 37,90 m

kW 3,00 kW

Power consumption

Efficiency ---

Model NR 32/200B/A

Family NR

Code 70MA017100000

Speed Fixed speed

Max Flow Rate 12,00 m³/h

H max 41,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 3,00 m³/h

Min head 33,40 m

kW 2,20 kW

Power consumption

Efficiency ---

Model NR 40/125C

Family NR

Code 70MA020000000

Speed Fixed speed

Max Flow Rate 21,00 m³/h

H max 15,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 5,80 m

kW 0,75 kW

Power consumption

Efficiency ---

Model NR 40/200B

Family NR

Code 70MA044000000

Speed Fixed speed

Max Flow Rate 21,00 m³/h

H max 40,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 22,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model NR 50/125F/A

Family NR

Code 70MA050100000

Speed Fixed speed

Max Flow Rate 33,00 m³/h

H max 13,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 6,90 m

kW 1,10 kW

Power consumption

Efficiency ---

Model NR 50/125A/B

Family NR

Code 70MA058200000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 21,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 12,00 m

kW 2,20 kW

Power consumption

Efficiency ---

Model NR 50/160C/B

Family NR

Code 70MA062200000

Speed Fixed speed

Max Flow Rate 39,00 m³/h

H max 21,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 10,00 m

kW 2,20 kW

Power consumption

Efficiency ---

Model NR 50/200D/B

Family NR

Code 70MA076200000

Speed Fixed speed

Max Flow Rate 33,00 m³/h

H max 37,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 24,90 m

kW 4,00 kW

Power consumption

Efficiency ---

Model NR 50/250B/A

Family NR

Code 70MA096100000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 67,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 50,00 m

kW 11,00 kW

Power consumption

Efficiency ---

Model NR 65/200B/B

Family NR

Code 70MA132200000

Speed Fixed speed

Max Flow Rate 66,00 m³/h

H max 46,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 28,30 m

kW 9,20 kW

Power consumption

Efficiency ---

Model NR4 50C/A

Family NR

Code 70M1002000000

Speed Fixed speed

Max Flow Rate 8,00 m³/h

H max 3,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,00 m³/h

Min head 2,50 m

kW 0,25 kW

Power consumption

Efficiency ---

Model NR4 100C/B

Family NR

Code 70M0020300000

Speed Fixed speed

Max Flow Rate 60,00 m³/h

H max 6,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 20,00 m³/h

Min head 3,30 m

kW 1,10 kW

Power consumption

Efficiency ---

Model NR4 125C/B

Family NR

Code 70M0028300000

Speed Fixed speed

Max Flow Rate 100,00 m³/h

H max 10,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 4,00 m

kW 2,20 kW

Power consumption

Efficiency ---

Model NR4 125B/A

Family NR

Code 70M0032200000

Speed Fixed speed

Max Flow Rate 110,00 m³/h

H max 12,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 5,10 m

kW 3,00 kW

Power consumption

Efficiency ---

Model NR 65/125S/B

Family NR

Code 70MA116200000

Speed Fixed speed

Max Flow Rate 69,00 m³/h

H max 26,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 14,70 m

kW 4,00 kW

Power consumption

Efficiency ---

Model NR4 32/200A/A

Family NR

Code 70MB015100000

Speed Fixed speed

Max Flow Rate 9,60 m³/h

H max 14,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 1,00 m³/h

Min head 9,10 m

kW 0,75 kW

Power consumption

Efficiency ---

Model NR4 50/200B/B

Family NR

Code 70MB079200000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 12,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 5,40 m³/h

Min head 5,20 m

kW 1,10 kW

Power consumption

Efficiency ---

Model NR4 50/250C/B

Family NR

Code 70MB090200000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 17,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 5,40 m³/h

Min head 5,30 m

kW 1,50 kW

Power consumption

Efficiency ---

Model NR4 50/250B/B

Family NR

Code 70MB094200000

Speed Fixed speed

Max Flow Rate 30,00 m³/h

H max 20,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 5,40 m³/h

Min head 8,50 m

kW 2,20 kW

Power consumption

Efficiency ---

Model NR 50C/B

Family NR

Code 70M0043100000

Speed Fixed speed

Max Flow Rate 18,90 m³/h

H max 16,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,00 m³/h

Min head 5,50 m

kW 0,75 kW

Power consumption

Efficiency ---

Model NR4 65/200B/B

Family NR

Code 70MB130200000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 13,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 5,40 m

kW 1,50 kW

Power consumption

Efficiency ---

Model NR4 65/250A/A

Family NR

Code 70MB152100000

Speed Fixed speed

Max Flow Rate 48,00 m³/h

H max 21,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 12,20 m

kW 4,00 kW

Power consumption

Efficiency ---

Model NR4 32/160A-60/A

Family NR

Code 70MB009101000

Speed Fixed speed

Max Flow Rate 6,60 m³/h

H max 10,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 1,00 m³/h

Min head 7,60 m

kW 0,37 kW

Power consumption

Efficiency ---

Model NRM 50/125C

Family NR

Code 70NA054000000

Speed Fixed speed

Max Flow Rate 39,00 m³/h

H max 17,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 8,30 m

kW 1,50 kW

Power consumption

Efficiency ---

Model NRM 40/125C

Family NR

Code 70NA020000000

Speed Fixed speed

Max Flow Rate 21,00 m³/h

H max 15,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 5,80 m

kW 0,75 kW

Power consumption

Efficiency ---

Model NRM 50/125F

Family NR

Code 70NA050000000

Speed Fixed speed

Max Flow Rate 33,00 m³/h

H max 13,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 6,90 m

kW 1,10 kW

Power consumption

Efficiency ---

Model NR4 50/160C/A

Family NR

Code 70MB062100000

Speed Fixed speed

Max Flow Rate 21,00 m³/h

H max 5,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 5,40 m³/h

Min head 2,30 m

kW 0,37 kW

Power consumption

Efficiency ---

Model NR 65/125F/B

Family NR

Code 70MA102200000

Speed Fixed speed

Max Flow Rate 66,00 m³/h

H max 16,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 5,30 m

kW 2,20 kW

Power consumption

Efficiency ---

Model NR 65/160B/A

Family NR

Code 70MA120100000

Speed Fixed speed

Max Flow Rate 72,00 m³/h

H max 32,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 16,70 m

kW 5,50 kW

Power consumption

Efficiency ---

Model NR 50D/A

Family NR

Code 70M0041000000

Speed Fixed speed

Max Flow Rate 13,20 m³/h

H max 11,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,00 m³/h

Min head 6,00 m

kW 0,45 kW

Power consumption

Efficiency ---

Model NR4 40/160A/A

Family NR

Code 70MB032100000

Speed Fixed speed

Max Flow Rate 15,00 m³/h

H max 9,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,40 m³/h

Min head 3,30 m

kW 0,37 kW

Power consumption

Efficiency ---

Model NR4 50/160A/B

Family NR

Code 70MB070200000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 9,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 5,40 m³/h

Min head 3,10 m

kW 0,75 kW

Power consumption

Efficiency ---

Model NR 50D-60/A

Family NR

Code 70M0041001000

Speed Fixed speed

Max Flow Rate 13,20 m³/h

H max 11,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,00 m³/h

Min head 5,50 m

kW 0,45 kW

Power consumption

Efficiency ---

Model NR 80/125E-60

Family NR

Code 70MA156001000

Speed Fixed speed

Max Flow Rate 108,00 m³/h

H max 17,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 37,80 m³/h

Min head 10,10 m

kW 4,00 kW

Power consumption

Efficiency ---

Model NR4 100C-60/B

Family NR

Code 70M0020301000

Speed Fixed speed

Max Flow Rate 60,00 m³/h

H max 6,75 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 20,00 m³/h

Min head 3,50 m

kW 1,10 kW

Power consumption

Efficiency ---

Model NR4 100B-60/B

Family NR

Code 70M0022301000

Speed Fixed speed

Max Flow Rate 60,00 m³/h

H max 7,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 20,00 m³/h

Min head 4,50 m

kW 1,10 kW

Power consumption

Efficiency ---

Model NR4 100A-60/B

Family NR

Code 70M0024301000

Speed Fixed speed

Max Flow Rate 70,00 m³/h

H max 9,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 20,00 m³/h

Min head 5,00 m

kW 1,50 kW

Power consumption

Efficiency ---

Model NR4 125C-60/B

Family NR

Code 70M0028301000

Speed Fixed speed

Max Flow Rate 90,00 m³/h

H max 10,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 5,70 m

kW 2,20 kW

Power consumption

Efficiency ---

Model NR4 125B-60/A

Family NR

Code 70M0032201000

Speed Fixed speed

Max Flow Rate 100,00 m³/h

H max 12,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 7,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model NR4 125A-60/A

Family NR

Code 70M0038201000

Speed Fixed speed

Max Flow Rate 110,00 m³/h

H max 13,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 7,70 m

kW 4,00 kW

Power consumption

Efficiency ---

Model NR 80/125C-60

Family NR

Code 70MA160001000

Speed Fixed speed

Max Flow Rate 120,00 m³/h

H max 21,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 37,80 m³/h

Min head 12,80 m

kW 5,50 kW

Power consumption

Efficiency ---

Model NR 80/125A-60

Family NR

Code 70MA164001000

Speed Fixed speed

Max Flow Rate 120,00 m³/h

H max 27,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 37,80 m³/h

Min head 18,50 m

kW 7,50 kW

Power consumption

Efficiency ---

Model NR4 50C-60/A

Family NR

Code 70M1002001000

Speed Fixed speed

Max Flow Rate 8,00 m³/h

H max 4,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,00 m³/h

Min head 2,70 m

kW 0,25 kW

Power consumption

Efficiency ---

Model NR4 50B/A

Family NR

Code 70M1004000000

Speed Fixed speed

Max Flow Rate 10,00 m³/h

H max 4,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,00 m³/h

Min head 2,30 m

kW 0,25 kW

Power consumption

Efficiency ---

Model NR4 50A-60/A

Family NR

Code 70M1006001000

Speed Fixed speed

Max Flow Rate 12,00 m³/h

H max 6,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,00 m³/h

Min head 2,60 m

kW 0,25 kW

Power consumption

Efficiency ---

Model NR4 65C/A

Family NR

Code 70M1008000000

Speed Fixed speed

Max Flow Rate 16,00 m³/h

H max 3,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,00 m³/h

Min head 1,90 m

kW 0,25 kW

Power consumption

Efficiency ---

Model NR4 65B/A

Family NR

Code 70M1010000000

Speed Fixed speed

Max Flow Rate 18,00 m³/h

H max 4,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,00 m³/h

Min head 2,50 m

kW 0,33 kW

Power consumption

Efficiency ---

Model NR4 65A-60/A

Family NR

Code 70M1012001000

Speed Fixed speed

Max Flow Rate 20,00 m³/h

H max 6,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,00 m³/h

Min head 3,20 m

kW 0,33 kW

Power consumption

Efficiency ---

Model NR 32/125B-60

Family NR

Code 70MA006001000

Speed Fixed speed

Max Flow Rate 8,40 m³/h

H max 18,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,40 m³/h

Min head 15,20 m

kW 0,55 kW

Power consumption

Efficiency ---

Model NR 32/125A-60

Family NR

Code 70MA008001000

Speed Fixed speed

Max Flow Rate 9,60 m³/h

H max 24,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,40 m³/h

Min head 19,60 m

kW 0,75 kW

Power consumption

Efficiency ---

Model NR 32/160A-60/A

Family NR

Code 70MA009101000

Speed Fixed speed

Max Flow Rate 12,00 m³/h

H max 37,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,40 m³/h

Min head 28,40 m

kW 1,50 kW

Power consumption

Efficiency ---

Model NR 32/160B-60/A

Family NR

Code 70MA011101000

Speed Fixed speed

Max Flow Rate 12,00 m³/h

H max 29,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,40 m³/h

Min head 17,00 m

kW 1,10 kW

Power consumption

Efficiency ---

Model NR 32/200S/A

Family NR

Code 70MA014100000

Speed Fixed speed

Max Flow Rate 16,80 m³/h

H max 57,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 3,00 m³/h

Min head 42,60 m

kW 4,00 kW

Power consumption

Efficiency ---

Model NR 32/200S-60/A

Family NR

Code 70MA014101000

Speed Fixed speed

Max Flow Rate 18,00 m³/h

H max 59,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,40 m³/h

Min head 37,70 m

kW 4,00 kW

Power consumption

Efficiency ---

Model NR 32/200A-60

Family NR

Code 70MA015001000

Speed Fixed speed

Max Flow Rate 16,80 m³/h

H max 51,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,40 m³/h

Min head 29,20 m

kW 3,00 kW

Power consumption

Efficiency ---

Model NR 32/200B-60/A

Family NR

Code 70MA017101000

Speed Fixed speed

Max Flow Rate 15,00 m³/h

H max 43,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,40 m³/h

Min head 24,30 m

kW 2,20 kW

Power consumption

Efficiency ---

Model NR 40/125C-60

Family NR

Code 70MA020001000

Speed Fixed speed

Max Flow Rate 13,20 m³/h

H max 16,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 5,40 m

kW 0,75 kW

Power consumption

Efficiency ---

Model NR 40/125B-60/A

Family NR

Code 70MA024101000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 20,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 7,60 m

kW 1,10 kW

Power consumption

Efficiency ---

Model NR 40/125A-60/A

Family NR

Code 70MA028101000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 25,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 14,20 m

kW 1,50 kW

Power consumption

Efficiency ---

Model NR 40/160A-60/A

Family NR

Code 70MA032101000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 36,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 21,00 m

kW 2,20 kW

Power consumption

Efficiency ---

Model NR 40/160B-60/A

Family NR

Code 70MA038101000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 28,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 11,90 m

kW 1,50 kW

Power consumption

Efficiency ---

Model NR 40/200A-60/A

Family NR

Code 70MA042101000

Speed Fixed speed

Max Flow Rate 21,00 m³/h

H max 52,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 34,50 m

kW 4,00 kW

Power consumption

Efficiency ---

Model NR 40/200B-60

Family NR

Code 70MA044001000

Speed Fixed speed

Max Flow Rate 21,00 m³/h

H max 41,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 20,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model NR 50/125F-60/A

Family NR

Code 70MA050101000

Speed Fixed speed

Max Flow Rate 33,00 m³/h

H max 14,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 5,50 m

kW 1,10 kW

Power consumption

Efficiency ---

Model NR 50/125C-60/A

Family NR

Code 70MA054101000

Speed Fixed speed

Max Flow Rate 33,00 m³/h

H max 17,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 10,10 m

kW 1,50 kW

Power consumption

Efficiency ---

Model NR 50/125A-60/B

Family NR

Code 70MA058201000

Speed Fixed speed

Max Flow Rate 39,00 m³/h

H max 21,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 12,20 m

kW 2,20 kW

Power consumption

Efficiency ---

Model NR 50/160C-60/B

Family NR

Code 70MA062201000

Speed Fixed speed

Max Flow Rate 39,00 m³/h

H max 24,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 9,40 m

kW 2,20 kW

Power consumption

Efficiency ---

Model NR 50/160B-60/A

Family NR

Code 70MA066101000

Speed Fixed speed

Max Flow Rate 39,00 m³/h

H max 29,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 18,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model NR 50/160A-60/B

Family NR

Code 70MA072201000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 36,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 22,00 m

kW 4,00 kW

Power consumption

Efficiency ---

Model NR 50/200C-60/B

Family NR

Code 70MA078201000

Speed Fixed speed

Max Flow Rate 30,00 m³/h

H max 45,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 34,00 m

kW 4,00 kW

Power consumption

Efficiency ---

Model NR 50/200B-60/A

Family NR

Code 70MA080101000

Speed Fixed speed

Max Flow Rate 33,00 m³/h

H max 50,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 37,50 m

kW 5,50 kW

Power consumption

Efficiency ---

Model NR 50/200A-60/A

Family NR

Code 70MA088101000

Speed Fixed speed

Max Flow Rate 37,80 m³/h

H max 57,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 41,40 m

kW 7,50 kW

Power consumption

Efficiency ---

Model NR 50/250C/B

Family NR

Code 70MA092200000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 58,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 39,40 m

kW 9,20 kW

Power consumption

Efficiency ---

Model NR 50/250B-60/A

Family NR

Code 70MA096101000

Speed Fixed speed

Max Flow Rate 37,80 m³/h

H max 73,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 56,90 m

kW 11,00 kW

Power consumption

Efficiency ---

Model NR 50/250A/B

Family NR

Code 70MA100200000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 84,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 65,20 m

kW 15,00 kW

Power consumption

Efficiency ---

Model NR 65/125F-60/B

Family NR

Code 70MA102201000

Speed Fixed speed

Max Flow Rate 60,00 m³/h

H max 16,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 4,80 m

kW 2,20 kW

Power consumption

Efficiency ---

Model NR 65/125D-60/A

Family NR

Code 70MA106101000

Speed Fixed speed

Max Flow Rate 60,00 m³/h

H max 19,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 9,80 m

kW 3,00 kW

Power consumption

Efficiency ---

Model NR 65/125A-60/B

Family NR

Code 70MA112201000

Speed Fixed speed

Max Flow Rate 60,00 m³/h

H max 24,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 17,60 m

kW 4,00 kW

Power consumption

Efficiency ---

Model NR 65/160B-60/A

Family NR

Code 70MA120101000

Speed Fixed speed

Max Flow Rate 60,00 m³/h

H max 35,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 23,70 m

kW 5,50 kW

Power consumption

Efficiency ---

Model NR 65/200S/B

Family NR

Code 70MA140200000

Speed Fixed speed

Max Flow Rate 66,00 m³/h

H max 60,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 42,70 m

kW 15,00 kW

Power consumption

Efficiency ---

Model NR 65/250C/A

Family NR

Code 70MA144100000

Speed Fixed speed

Max Flow Rate 66,00 m³/h

H max 54,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 37,30 m

kW 11,00 kW

Power consumption

Efficiency ---

Model NR 65/250B/B

Family NR

Code 70MA148200000

Speed Fixed speed

Max Flow Rate 66,00 m³/h

H max 67,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 49,70 m

kW 15,00 kW

Power consumption

Efficiency ---

Model NR 65/250A/C

Family NR

Code 70MA152300000

Speed Fixed speed

Max Flow Rate 66,00 m³/h

H max 78,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 62,20 m

kW 18,50 kW

Power consumption

Efficiency ---

Model NR 65/250A-60/C

Family NR

Code 70MA152301000

Speed Fixed speed

Max Flow Rate 66,00 m³/h

H max 86,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 70,30 m

kW 18,50 kW

Power consumption

Efficiency ---

Model NR4 32/160B-60/A

Family NR

Code 70MB011101000

Speed Fixed speed

Max Flow Rate 6,60 m³/h

H max 8,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 1,00 m³/h

Min head 4,80 m

kW 0,37 kW

Power consumption

Efficiency ---

Model NR4 32/200A-60/A

Family NR

Code 70MB015101000

Speed Fixed speed

Max Flow Rate 10,80 m³/h

H max 19,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 1,00 m³/h

Min head 12,20 m

kW 0,75 kW

Power consumption

Efficiency ---

Model NR4 32/200B/A

Family NR

Code 70MB017100000

Speed Fixed speed

Max Flow Rate 9,60 m³/h

H max 13,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 1,00 m³/h

Min head 7,50 m

kW 0,55 kW

Power consumption

Efficiency ---

Model NR4 32/200B-60/A

Family NR

Code 70MB017101000

Speed Fixed speed

Max Flow Rate 9,60 m³/h

H max 15,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 1,00 m³/h

Min head 8,10 m

kW 0,55 kW

Power consumption

Efficiency ---

Model NR4 32/200C/A

Family NR

Code 70MB019100000

Speed Fixed speed

Max Flow Rate 8,40 m³/h

H max 11,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 1,00 m³/h

Min head 5,70 m

kW 0,37 kW

Power consumption

Efficiency ---

Model NR4 32/200C-60/A

Family NR

Code 70MB019101000

Speed Fixed speed

Max Flow Rate 8,40 m³/h

H max 11,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 1,00 m³/h

Min head 5,50 m

kW 0,37 kW

Power consumption

Efficiency ---

Model NR4 40/160A-60/A

Family NR

Code 70MB032101000

Speed Fixed speed

Max Flow Rate 15,00 m³/h

H max 9,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,40 m³/h

Min head 3,00 m

kW 0,37 kW

Power consumption

Efficiency ---

Model NR4 40/160B-60/A

Family NR

Code 70MB038101000

Speed Fixed speed

Max Flow Rate 13,20 m³/h

H max 7,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,40 m³/h

Min head 2,50 m

kW 0,37 kW

Power consumption

Efficiency ---

Model NR4 40/200A/A

Family NR

Code 70MB040100000

Speed Fixed speed

Max Flow Rate 15,00 m³/h

H max 14,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,40 m³/h

Min head 4,90 m

kW 0,75 kW

Power consumption

Efficiency ---

Model NR4 40/200A-60/A

Family NR

Code 70MB040101000

Speed Fixed speed

Max Flow Rate 15,00 m³/h

H max 14,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,40 m³/h

Min head 4,10 m

kW 0,75 kW

Power consumption

Efficiency ---

Model NR4 40/200B-60/A

Family NR

Code 70MB044101000

Speed Fixed speed

Max Flow Rate 13,20 m³/h

H max 13,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,40 m³/h

Min head 4,30 m

kW 0,55 kW

Power consumption

Efficiency ---

Model NR4 50/160C-60/A

Family NR

Code 70MB062101000

Speed Fixed speed

Max Flow Rate 18,90 m³/h

H max 6,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 5,40 m³/h

Min head 3,00 m

kW 0,37 kW

Power consumption

Efficiency ---

Model NR4 50/160B-60/A

Family NR

Code 70MB066101000

Speed Fixed speed

Max Flow Rate 21,00 m³/h

H max 7,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 5,40 m³/h

Min head 4,30 m

kW 0,55 kW

Power consumption

Efficiency ---

Model NR4 50/160A-60/B

Family NR

Code 70MB070201000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 9,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 5,40 m³/h

Min head 3,80 m

kW 0,75 kW

Power consumption

Efficiency ---

Model NR4 50/200B-60/B

Family NR

Code 70MB079201000

Speed Fixed speed

Max Flow Rate 18,90 m³/h

H max 13,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 5,40 m³/h

Min head 7,80 m

kW 1,10 kW

Power consumption

Efficiency ---

Model NR4 50/200A/B

Family NR

Code 70MB086200000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 14,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 5,40 m³/h

Min head 7,30 m

kW 1,10 kW

Power consumption

Efficiency ---

Model NR4 50/200A-60/B

Family NR

Code 70MB086201000

Speed Fixed speed

Max Flow Rate 21,00 m³/h

H max 14,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 5,40 m³/h

Min head 9,00 m

kW 1,10 kW

Power consumption

Efficiency ---

Model NR4 50/250C-60/B

Family NR

Code 70MB090201000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 18,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 5,40 m³/h

Min head 7,20 m

kW 1,50 kW

Power consumption

Efficiency ---

Model NR4 50/250B-60/B

Family NR

Code 70MB094201000

Speed Fixed speed

Max Flow Rate 27,00 m³/h

H max 23,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 5,40 m³/h

Min head 13,00 m

kW 2,20 kW

Power consumption

Efficiency ---

Model NR4 65/125F-60/A

Family NR

Code 70MB102101000

Speed Fixed speed

Max Flow Rate 33,00 m³/h

H max 3,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 1,40 m

kW 0,37 kW

Power consumption

Efficiency ---

Model NR4 65/125D-60/A

Family NR

Code 70MB106101000

Speed Fixed speed

Max Flow Rate 37,80 m³/h

H max 4,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 1,60 m

kW 0,55 kW

Power consumption

Efficiency ---

Model NR4 65/125A-60/B

Family NR

Code 70MB112201000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 6,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 1,90 m

kW 0,75 kW

Power consumption

Efficiency ---

Model NR4 65/160B-60/B

Family NR

Code 70MB118201000

Speed Fixed speed

Max Flow Rate 37,80 m³/h

H max 9,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 4,40 m

kW 1,10 kW

Power consumption

Efficiency ---

Model NR4 65/160A-60/B

Family NR

Code 70MB122201000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 10,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 5,80 m

kW 1,10 kW

Power consumption

Efficiency ---

Model NR4 65/200C-60/B

Family NR

Code 70MB126201000

Speed Fixed speed

Max Flow Rate 33,00 m³/h

H max 10,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 4,30 m

kW 1,10 kW

Power consumption

Efficiency ---

Model NR4 65/200B-60/B

Family NR

Code 70MB130201000

Speed Fixed speed

Max Flow Rate 37,80 m³/h

H max 12,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 4,70 m

kW 1,50 kW

Power consumption

Efficiency ---

Model NR4 65/200A/B

Family NR

Code 70MB134200000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 14,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 7,20 m

kW 2,20 kW

Power consumption

Efficiency ---

Model NR4 65/200A-60/B

Family NR

Code 70MB134201000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 16,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 9,90 m

kW 2,20 kW

Power consumption

Efficiency ---

Model NR4 65/250D/B

Family NR

Code 70MB138200000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 13,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 7,20 m

kW 2,20 kW

Power consumption

Efficiency ---

Model NR4 65/250C/B

Family NR

Code 70MB142200000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 17,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 10,00 m

kW 2,20 kW

Power consumption

Efficiency ---

Model NR4 65/250C-60/B

Family NR

Code 70MB142201000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 19,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 10,40 m

kW 2,20 kW

Power consumption

Efficiency ---

Model NR4 65/250B/A

Family NR

Code 70MB146100000

Speed Fixed speed

Max Flow Rate 48,00 m³/h

H max 20,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 10,80 m

kW 3,00 kW

Power consumption

Efficiency ---

Model NRM 50D-60/A

Family NR

Code 70N0041001000

Speed Fixed speed

Max Flow Rate 13,20 m³/h

H max 11,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,00 m³/h

Min head 5,50 m

kW 0,45 kW

Power consumption

Efficiency ---

Model NRM 50C-60/A

Family NR

Code 70N0043001000

Speed Fixed speed

Max Flow Rate 18,90 m³/h

H max 17,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,00 m³/h

Min head 4,80 m

kW 0,75 kW

Power consumption

Efficiency ---

Model NR4M 50C/A

Family NR

Code 70N1002000000

Speed Fixed speed

Max Flow Rate 8,00 m³/h

H max 3,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,00 m³/h

Min head 2,50 m

kW 0,25 kW

Power consumption

Efficiency ---

Model NR4M 50C-60/A

Family NR

Code 70N1002001000

Speed Fixed speed

Max Flow Rate 6,00 m³/h

H max 2,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,00 m³/h

Min head 1,20 m

kW 0,25 kW

Power consumption

Efficiency ---

Model NR4M 50B/A

Family NR

Code 70N1004000000

Speed Fixed speed

Max Flow Rate 10,00 m³/h

H max 4,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,00 m³/h

Min head 2,30 m

kW 0,25 kW

Power consumption

Efficiency ---

Model NR4M 50A/A

Family NR

Code 70N1006000000

Speed Fixed speed

Max Flow Rate 12,00 m³/h

H max 5,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,00 m³/h

Min head 2,00 m

kW 0,25 kW

Power consumption

Efficiency ---

Model NR4M 50A-60/A

Family NR

Code 70N1006001000

Speed Fixed speed

Max Flow Rate 12,00 m³/h

H max 6,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,00 m³/h

Min head 2,60 m

kW 0,25 kW

Power consumption

Efficiency ---

Model NR4M 65C/A

Family NR

Code 70N1008000000

Speed Fixed speed

Max Flow Rate 16,00 m³/h

H max 3,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,00 m³/h

Min head 1,90 m

kW 0,25 kW

Power consumption

Efficiency ---

Model NRM 32/125B-60

Family NR

Code 70NA006001000

Speed Fixed speed

Max Flow Rate 8,40 m³/h

H max 18,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,40 m³/h

Min head 15,20 m

kW 0,55 kW

Power consumption

Efficiency ---

Model NRM 32/125A-60

Family NR

Code 70NA008001000

Speed Fixed speed

Max Flow Rate 9,60 m³/h

H max 24,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,40 m³/h

Min head 19,60 m

kW 0,75 kW

Power consumption

Efficiency ---

Model NRM 40/125C-60

Family NR

Code 70NA020001000

Speed Fixed speed

Max Flow Rate 21,00 m³/h

H max 16,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 5,40 m

kW 0,75 kW

Power consumption

Efficiency ---

Model NRM 40/160B

Family NR

Code 70NA038000000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 25,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 9,90 m

kW 1,50 kW

Power consumption

Efficiency ---

Model NR 40/125A/A

Family NR

Code 70MA028100000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 23,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 14,20 m

kW 1,50 kW

Power consumption

Efficiency ---

Model NRM 40/125A

Family NR

Code 70NA028000000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 23,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 14,20 m

kW 1,50 kW

Power consumption

Efficiency ---

Model NR 50/200A/A

Family NR

Code 70MA088100000

Speed Fixed speed

Max Flow Rate 39,00 m³/h

H max 54,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 38,80 m

kW 7,50 kW

Power consumption

Efficiency ---

Model NR 65/125A/B

Family NR

Code 70MA112200000

Speed Fixed speed

Max Flow Rate 69,00 m³/h

H max 24,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 12,40 m

kW 4,00 kW

Power consumption

Efficiency ---

Model NR 32/160B/A

Family NR

Code 70MA011100000

Speed Fixed speed

Max Flow Rate 10,80 m³/h

H max 27,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,40 m³/h

Min head 20,00 m

kW 1,10 kW

Power consumption

Efficiency ---

Model NR 32/160A/A

Family NR

Code 70MA009100000

Speed Fixed speed

Max Flow Rate 10,80 m³/h

H max 36,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,40 m³/h

Min head 29,70 m

kW 1,50 kW

Power consumption

Efficiency ---

Model NR4 50/250A/A

Family NR

Code 70MB098100000

Speed Fixed speed

Max Flow Rate 30,00 m³/h

H max 21,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 5,40 m³/h

Min head 11,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model NR 50C-60/B

Family NR

Code 70M0043101000

Speed Fixed speed

Max Flow Rate 18,90 m³/h

H max 17,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,00 m³/h

Min head 4,80 m

kW 0,75 kW

Power consumption

Efficiency ---

Model NR4 65/200C/B

Family NR

Code 70MB126200000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 11,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 3,40 m

kW 1,10 kW

Power consumption

Efficiency ---

Model NRM 50C/A

Family NR

Code 70N0043000000

Speed Fixed speed

Max Flow Rate 18,90 m³/h

H max 16,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,00 m³/h

Min head 5,50 m

kW 0,75 kW

Power consumption

Efficiency ---

Model NR4 32/160A/A

Family NR

Code 70MB009100000

Speed Fixed speed

Max Flow Rate 7,50 m³/h

H max 9,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 1,00 m³/h

Min head 5,60 m

kW 0,37 kW

Power consumption

Efficiency ---

Model NRM 50C/A

Family NR

Code 70N0043100000

Speed Fixed speed

Max Flow Rate 18,90 m³/h

H max 16,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,00 m³/h

Min head 5,50 m

kW 0,75 kW

Power consumption

Efficiency ---

Model NR 40/200A/A

Family NR

Code 70MA042100000

Speed Fixed speed

Max Flow Rate 21,00 m³/h

H max 49,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 34,80 m

kW 4,00 kW

Power consumption

Efficiency ---

Model NR4 65/125F/A

Family NR

Code 70MB102100000

Speed Fixed speed

Max Flow Rate 33,00 m³/h

H max 3,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 1,00 m

kW 0,37 kW

Power consumption

Efficiency ---

Model NR 65/125D/A

Family NR

Code 70MA106100000

Speed Fixed speed

Max Flow Rate 66,00 m³/h

H max 20,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 9,10 m

kW 3,00 kW

Power consumption

Efficiency ---

Model NR4 50A/A

Family NR

Code 70M1006000000

Speed Fixed speed

Max Flow Rate 12,00 m³/h

H max 5,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,00 m³/h

Min head 2,00 m

kW 0,25 kW

Power consumption

Efficiency ---

Model NR 50/160B/A

Family NR

Code 70MA066100000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 27,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 13,60 m

kW 3,00 kW

Power consumption

Efficiency ---

Model NRM 50D/A

Family NR

Code 70N0041000000

Speed Fixed speed

Max Flow Rate 13,20 m³/h

H max 11,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,00 m³/h

Min head 6,00 m

kW 0,45 kW

Power consumption

Efficiency ---

Model NRM 50/125F

Family NR

Code 70NA050100000

Speed Fixed speed

Max Flow Rate 33,00 m³/h

H max 13,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 6,90 m

kW 1,10 kW

Power consumption

Efficiency ---

Model NRM 40/125B

Family NR

Code 70NA024100000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 19,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 8,50 m

kW 1,10 kW

Power consumption

Efficiency ---

Model NRM 40/125C

Family NR

Code 70NA020100000

Speed Fixed speed

Max Flow Rate 21,00 m³/h

H max 15,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 5,80 m

kW 0,75 kW

Power consumption

Efficiency ---

Model NRM 32/125A

Family NR

Code 70NA008100000

Speed Fixed speed

Max Flow Rate 9,60 m³/h

H max 23,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,40 m³/h

Min head 19,10 m

kW 0,75 kW

Power consumption

Efficiency ---

Model NRM 32/125A

Family NR

Code 70NA008000000

Speed Fixed speed

Max Flow Rate 9,60 m³/h

H max 23,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,40 m³/h

Min head 19,10 m

kW 0,75 kW

Power consumption

Efficiency ---

Model NRM 32/125B

Family NR

Code 70NA006100000

Speed Fixed speed

Max Flow Rate 8,40 m³/h

H max 18,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,40 m³/h

Min head 15,00 m

kW 0,55 kW

Power consumption

Efficiency ---

Model NRM 32/125B

Family NR

Code 70NA006000000

Speed Fixed speed

Max Flow Rate 8,40 m³/h

H max 18,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,40 m³/h

Min head 15,00 m

kW 0,55 kW

Power consumption

Efficiency ---

Model NR4 100B/B

Family NR

Code 70M0022300000

Speed Fixed speed

Max Flow Rate 60,00 m³/h

H max 7,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 20,00 m³/h

Min head 4,40 m

kW 1,10 kW

Power consumption

Efficiency ---

Model NR 40/125B/A

Family NR

Code 70MA024100000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 19,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 8,50 m

kW 1,10 kW

Power consumption

Efficiency ---

Model NR4 65/125D/A

Family NR

Code 70MB106100000

Speed Fixed speed

Max Flow Rate 33,00 m³/h

H max 5,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 2,40 m

kW 0,55 kW

Power consumption

Efficiency ---

Model NR4 50/160B/A

Family NR

Code 70MB066100000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 7,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 5,40 m³/h

Min head 2,50 m

kW 0,55 kW

Power consumption

Efficiency ---

Model NR4 40/160B/A

Family NR

Code 70MB038100000

Speed Fixed speed

Max Flow Rate 13,20 m³/h

H max 7,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,40 m³/h

Min head 2,50 m

kW 0,37 kW

Power consumption

Efficiency ---

Model NR4 32/160B/A

Family NR

Code 70MB011100000

Speed Fixed speed

Max Flow Rate 6,00 m³/h

H max 7,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 1,00 m³/h

Min head 4,40 m

kW 0,37 kW

Power consumption

Efficiency ---

Model NR 80/125A

Family NR

Code 70MA164000000

Speed Fixed speed

Max Flow Rate 120,00 m³/h

H max 25,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 37,80 m³/h

Min head 17,70 m

kW 7,50 kW

Power consumption

Efficiency ---

Model NR 80/125C

Family NR

Code 70MA160000000

Speed Fixed speed

Max Flow Rate 120,00 m³/h

H max 20,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 37,80 m³/h

Min head 11,00 m

kW 5,50 kW

Power consumption

Efficiency ---

Model NR 80/125E

Family NR

Code 70MA156000000

Speed Fixed speed

Max Flow Rate 108,00 m³/h

H max 16,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 37,80 m³/h

Min head 9,20 m

kW 4,00 kW

Power consumption

Efficiency ---

Model NR 32/125A

Family NR

Code 70MA008000000

Speed Fixed speed

Max Flow Rate 9,60 m³/h

H max 23,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,40 m³/h

Min head 19,10 m

kW 0,75 kW

Power consumption

Efficiency ---

Model NR 32/125B

Family NR

Code 70MA006000000

Speed Fixed speed

Max Flow Rate 8,40 m³/h

H max 18,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,40 m³/h

Min head 15,00 m

kW 0,55 kW

Power consumption

Efficiency ---

Model NR4 40/200B/A

Family NR

Code 70MB044100000

Speed Fixed speed

Max Flow Rate 13,20 m³/h

H max 12,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,40 m³/h

Min head 4,40 m

kW 0,55 kW

Power consumption

Efficiency ---

Model NR 40/160B/A

Family NR

Code 70MA038100000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 25,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 9,90 m

kW 1,50 kW

Power consumption

Efficiency ---

Model NR4 65/125S/B

Family NR

Code 70MB116200000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 6,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 2,10 m

kW 0,75 kW

Power consumption

Efficiency ---

Model NR4 65A/A

Family NR

Code 70M1012000000

Speed Fixed speed

Max Flow Rate 20,00 m³/h

H max 5,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,00 m³/h

Min head 2,70 m

kW 0,33 kW

Power consumption

Efficiency ---

Model NR4 65/125A/B

Family NR

Code 70MB112200000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 6,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 1,50 m

kW 0,75 kW

Power consumption

Efficiency ---

Model NR4 100A/B

Family NR

Code 70M0024300000

Speed Fixed speed

Max Flow Rate 70,00 m³/h

H max 9,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 20,00 m³/h

Min head 4,80 m

kW 1,50 kW

Power consumption

Efficiency ---

Model NR 65/160A/A

Family NR

Code 70MA124100000

Speed Fixed speed

Max Flow Rate 72,00 m³/h

H max 39,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 25,30 m

kW 7,50 kW

Power consumption

Efficiency ---

Model NR 50/200B/A

Family NR

Code 70MA080100000

Speed Fixed speed

Max Flow Rate 33,00 m³/h

H max 48,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 36,50 m

kW 5,50 kW

Power consumption

Efficiency ---

Model NR4 65/160B/B

Family NR

Code 70MB118200000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 8,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 3,20 m

kW 1,10 kW

Power consumption

Efficiency ---

Model NR4 65/160A/B

Family NR

Code 70MB122200000

Speed Fixed speed

Max Flow Rate 48,00 m³/h

H max 9,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 3,00 m

kW 1,10 kW

Power consumption

Efficiency ---

Model NR4 125A/A

Family NR

Code 70M0038200000

Speed Fixed speed

Max Flow Rate 110,00 m³/h

H max 13,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 30,00 m³/h

Min head 7,20 m

kW 4,00 kW

Power consumption

Efficiency ---

Model NR4 80/200A-60

Family NR

Code 70MB194001000

Speed Fixed speed

Max Flow Rate 96,00 m³/h

H max 14,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 7,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model NR4 80/200A

Family NR

Code 70MB194000000

Speed Fixed speed

Max Flow Rate 96,00 m³/h

H max 14,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 6,70 m

kW 3,00 kW

Power consumption

Efficiency ---

Model NR4 80/200B-60

Family NR

Code 70MB190001000

Speed Fixed speed

Max Flow Rate 96,00 m³/h

H max 12,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 4,00 m

kW 2,20 kW

Power consumption

Efficiency ---

Model NR4 80/200B

Family NR

Code 70MB190000000

Speed Fixed speed

Max Flow Rate 96,00 m³/h

H max 15,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 7,10 m

kW 2,20 kW

Power consumption

Efficiency ---

Model NR4 80/160S-60

Family NR

Code 70MB182001000

Speed Fixed speed

Max Flow Rate 84,00 m³/h

H max 10,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 5,80 m

kW 2,20 kW

Power consumption

Efficiency ---

Model NR4 80/160S

Family NR

Code 70MB182000000

Speed Fixed speed

Max Flow Rate 84,00 m³/h

H max 10,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 5,70 m

kW 2,20 kW

Power consumption

Efficiency ---

Model NR4 80/160A-60

Family NR

Code 70MB178001000

Speed Fixed speed

Max Flow Rate 75,00 m³/h

H max 9,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 5,60 m

kW 1,50 kW

Power consumption

Efficiency ---

Model NR4 80/160A

Family NR

Code 70MB178000000

Speed Fixed speed

Max Flow Rate 75,00 m³/h

H max 8,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 5,20 m

kW 1,50 kW

Power consumption

Efficiency ---

Model NR4 80/160B-60

Family NR

Code 70MB174001000

Speed Fixed speed

Max Flow Rate 66,00 m³/h

H max 7,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 4,40 m

kW 1,10 kW

Power consumption

Efficiency ---

Model NR4 80/160B

Family NR

Code 70MB174000000

Speed Fixed speed

Max Flow Rate 66,00 m³/h

H max 7,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 4,40 m

kW 1,10 kW

Power consumption

Efficiency ---

Model NR4 80/160C-60

Family NR

Code 70MB170001000

Speed Fixed speed

Max Flow Rate 60,00 m³/h

H max 6,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 4,40 m

kW 1,10 kW

Power consumption

Efficiency ---

Model NR4 80/160C

Family NR

Code 70MB170000000

Speed Fixed speed

Max Flow Rate 60,00 m³/h

H max 6,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 4,10 m

kW 1,10 kW

Power consumption

Efficiency ---

Model NR 80/200A-60

Family NR

Code 70MA196001000

Speed Fixed speed

Max Flow Rate 141,00 m³/h

H max 58,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 46,40 m

kW 22,00 kW

Power consumption

Efficiency ---

Model NR 80/200A

Family NR

Code 70MA196000000

Speed Fixed speed

Max Flow Rate 141,00 m³/h

H max 56,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 45,40 m

kW 22,00 kW

Power consumption

Efficiency ---

Model NR 80/200B-60

Family NR

Code 70MA192001000

Speed Fixed speed

Max Flow Rate 141,00 m³/h

H max 50,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 37,70 m

kW 18,50 kW

Power consumption

Efficiency ---

Model NR 80/200B

Family NR

Code 70MA192000000

Speed Fixed speed

Max Flow Rate 141,00 m³/h

H max 48,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 35,20 m

kW 18,50 kW

Power consumption

Efficiency ---

Model NR 80/200C-60

Family NR

Code 70MA188001000

Speed Fixed speed

Max Flow Rate 141,00 m³/h

H max 44,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 30,50 m

kW 15,00 kW

Power consumption

Efficiency ---

Model NR 80/200C

Family NR

Code 70MA188000000

Speed Fixed speed

Max Flow Rate 141,00 m³/h

H max 56,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 45,80 m

kW 15,00 kW

Power consumption

Efficiency ---

Model NR 80/160AR-60

Family NR

Code 70MA184001000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 36,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 28,20 m

kW 15,00 kW

Power consumption

Efficiency ---

Model NR 80/160AR

Family NR

Code 70MA184000000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 36,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 27,80 m

kW 15,00 kW

Power consumption

Efficiency ---

Model NR 80/160A-60

Family NR

Code 70MA180001000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 41,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 33,20 m

kW 15,00 kW

Power consumption

Efficiency ---

Model NR 80/160A

Family NR

Code 70MA180000000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 41,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 33,10 m

kW 15,00 kW

Power consumption

Efficiency ---

Model NR 80/160B-60

Family NR

Code 70MA176001000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 33,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 25,00 m

kW 11,00 kW

Power consumption

Efficiency ---

Model NR 80/160B

Family NR

Code 70MA176000000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 32,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 22,40 m

kW 11,00 kW

Power consumption

Efficiency ---

Model NR 80/160C-60

Family NR

Code 70MA172001000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 29,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 18,50 m

kW 9,20 kW

Power consumption

Efficiency ---

Model NR 80/160C

Family NR

Code 70MA172000000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 28,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 17,00 m

kW 9,20 kW

Power consumption

Efficiency ---

Model NR 80/160D-60

Family NR

Code 70MA168001000

Speed Fixed speed

Max Flow Rate 120,00 m³/h

H max 25,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 17,40 m

kW 7,50 kW

Power consumption

Efficiency ---

Model NR 80/160D

Family NR

Code 70MA168000000

Speed Fixed speed

Max Flow Rate 120,00 m³/h

H max 24,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 16,10 m

kW 7,50 kW

Power consumption

Efficiency ---

Model NR4 50B-60/A

Family NR

Code 70M1004001000

Speed Fixed speed

Max Flow Rate 10,00 m³/h

H max 5,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,00 m³/h

Min head 2,50 m

kW 0,25 kW

Power consumption

Efficiency ---

Model NR4 65C-60/A

Family NR

Code 70M1008001000

Speed Fixed speed

Max Flow Rate 16,00 m³/h

H max 4,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,00 m³/h

Min head 2,40 m

kW 0,25 kW

Power consumption

Efficiency ---

Model NR4 65B-60/A

Family NR

Code 70M1010001000

Speed Fixed speed

Max Flow Rate 18,00 m³/h

H max 5,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,00 m³/h

Min head 2,90 m

kW 0,33 kW

Power consumption

Efficiency ---

Model NR 50/250C-60/B

Family NR

Code 70MA092201000

Speed Fixed speed

Max Flow Rate 33,00 m³/h

H max 65,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 52,50 m

kW 9,20 kW

Power consumption

Efficiency ---

Model NR 50/250A-60/B

Family NR

Code 70MA100201000

Speed Fixed speed

Max Flow Rate 39,00 m³/h

H max 90,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 75,40 m

kW 15,00 kW

Power consumption

Efficiency ---

Model NR 65/160A-60/A

Family NR

Code 70MA124101000

Speed Fixed speed

Max Flow Rate 66,00 m³/h

H max 41,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 30,10 m

kW 7,50 kW

Power consumption

Efficiency ---

Model NR 65/200B-60/B

Family NR

Code 70MA132201000

Speed Fixed speed

Max Flow Rate 66,00 m³/h

H max 50,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 30,90 m

kW 9,20 kW

Power consumption

Efficiency ---

Model NR 65/200A-60/A

Family NR

Code 70MA136101000

Speed Fixed speed

Max Flow Rate 66,00 m³/h

H max 57,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 40,50 m

kW 11,00 kW

Power consumption

Efficiency ---

Model NR 65/250C-60/A

Family NR

Code 70MA144101000

Speed Fixed speed

Max Flow Rate 54,00 m³/h

H max 63,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 49,40 m

kW 11,00 kW

Power consumption

Efficiency ---

Model NR 65/250B-60/B

Family NR

Code 70MA148201000

Speed Fixed speed

Max Flow Rate 60,00 m³/h

H max 73,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 58,40 m

kW 15,00 kW

Power consumption

Efficiency ---

Model NR4 50/250A-60/A

Family NR

Code 70MB098101000

Speed Fixed speed

Max Flow Rate 30,00 m³/h

H max 25,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 5,40 m³/h

Min head 14,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model NR4 65/250B-60/A

Family NR

Code 70MB146101000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 23,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 16,00 m

kW 3,00 kW

Power consumption

Efficiency ---

Model NR4 65/250A-60/A

Family NR

Code 70MB152101000

Speed Fixed speed

Max Flow Rate 42,00 m³/h

H max 24,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 10,80 m³/h

Min head 17,40 m

kW 4,00 kW

Power consumption

Efficiency ---

Model NR4M 50B-60/A

Family NR

Code 70N1004001000

Speed Fixed speed

Max Flow Rate 10,00 m³/h

H max 5,00 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,00 m³/h

Min head 2,50 m

kW 0,25 kW

Power consumption

Efficiency ---

Model NR4M 65C-60/A

Family NR

Code 70N1008001000

Speed Fixed speed

Max Flow Rate 16,00 m³/h

H max 4,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,00 m³/h

Min head 2,40 m

kW 0,25 kW

Power consumption

Efficiency ---

Model NRM 32/160A

Family NR

Code 70NA009000000

Speed Fixed speed

Max Flow Rate 10,80 m³/h

H max 36,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,40 m³/h

Min head 29,70 m

kW 1,50 kW

Power consumption

Efficiency ---

Model NRM 32/160A-60

Family NR

Code 70NA009001000

Speed Fixed speed

Max Flow Rate 12,00 m³/h

H max 37,10 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,40 m³/h

Min head 28,40 m

kW 1,50 kW

Power consumption

Efficiency ---

Model NRM 32/160B

Family NR

Code 70NA011000000

Speed Fixed speed

Max Flow Rate 10,80 m³/h

H max 27,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,40 m³/h

Min head 20,00 m

kW 1,10 kW

Power consumption

Efficiency ---

Model NRM 32/160B-60

Family NR

Code 70NA011001000

Speed Fixed speed

Max Flow Rate 12,00 m³/h

H max 29,20 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,40 m³/h

Min head 17,00 m

kW 1,10 kW

Power consumption

Efficiency ---

Model NRM 32/160B

Family NR

Code 70NA011100000

Speed Fixed speed

Max Flow Rate 10,80 m³/h

H max 27,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 2,40 m³/h

Min head 20,00 m

kW 1,10 kW

Power consumption

Efficiency ---

Model NRM 40/125B-60

Family NR

Code 70NA024001000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 20,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 7,60 m

kW 1,10 kW

Power consumption

Efficiency ---

Model NRM 40/125A-60

Family NR

Code 70NA028001000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 25,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 14,20 m

kW 1,50 kW

Power consumption

Efficiency ---

Model NRM 40/160B-60

Family NR

Code 70NA038001000

Speed Fixed speed

Max Flow Rate 24,00 m³/h

H max 28,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 6,60 m³/h

Min head 11,90 m

kW 1,50 kW

Power consumption

Efficiency ---

Model NRM 50/125F-60

Family NR

Code 70NA050001000

Speed Fixed speed

Max Flow Rate 33,00 m³/h

H max 14,70 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 5,50 m

kW 1,10 kW

Power consumption

Efficiency ---

Model NRM 50/125C-60

Family NR

Code 70NA054001000

Speed Fixed speed

Max Flow Rate 33,00 m³/h

H max 17,80 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 15,00 m³/h

Min head 10,10 m

kW 1,50 kW

Power consumption

Efficiency ---

Model NR 80/250C

Family NR

Code 70MA208000000

Speed Fixed speed

Max Flow Rate 141,00 m³/h

H max 55,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 36,90 m

kW 22,00 kW

Power consumption

Efficiency ---

Model NR 80/250C-60

Family NR

Code 70MA208001000

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 56,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 42,20 m

kW 22,00 kW

Power consumption

Efficiency ---

Model NR4 80/250B

Family NR

Code 70MB200000000

Speed Fixed speed

Max Flow Rate 96,00 m³/h

H max 17,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 7,40 m

kW 4,00 kW

Power consumption

Efficiency ---

Model NR4 80/250B-60

Family NR

Code 70MB200001000

Speed Fixed speed

Max Flow Rate 96,00 m³/h

H max 19,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 9,40 m

kW 4,00 kW

Power consumption

Efficiency ---

Model NR4 80/250A

Family NR

Code 70MB204000000

Speed Fixed speed

Max Flow Rate 96,00 m³/h

H max 21,40 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 12,90 m

kW 5,50 kW

Power consumption

Efficiency ---

Model NR4 80/250A-60

Family NR

Code 70MB204001000

Speed Fixed speed

Max Flow Rate 96,00 m³/h

H max 23,30 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 21,00 m³/h

Min head 15,20 m

kW 5,50 kW

Power consumption

Efficiency ---

Model NRS 80/250B

Family NR

Code 70WA200000003

Speed Fixed speed

Max Flow Rate 141,00 m³/h

H max 70,60 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 55,20 m

kW 30,00 kW

Power consumption

Efficiency ---

Model NRS 80/250B-60

Family NR

Code 70WA200001003

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 72,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 60,10 m

kW 30,00 kW

Power consumption

Efficiency ---

Model NRS 80/250A

Family NR

Code 70WA204000003

Speed Fixed speed

Max Flow Rate 141,00 m³/h

H max 83,90 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 71,50 m

kW 37,00 kW

Power consumption

Efficiency ---

Model NRS 80/250A-60

Family NR

Code 70WA204001003

Speed Fixed speed

Max Flow Rate 132,00 m³/h

H max 85,50 m

Pump casing Cast iron GJL 200 EN 1561

Min Flow Rate 48,00 m³/h

Min head 75,10 m

kW 37,00 kW

Power consumption

Efficiency ---

Filters for

Results NR

Filters for

Filters for
